OWNER'S MANUAL
Installation and Operation
Model:
41I-ACC
•
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire - If heater or chimney con-
nector glows, you are overfiring. Overfiring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
www.quadrafire.com
41-I ACC WOOD INSERT
Automatic Combustion Control (ACC)
DO NOT DISCARD THIS MANUAL
• Read, understand and
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
CAUTION
follow these instructions
for safe installation and
operation.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
7045-178
R
• Leave this manual with
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
Installation and service of this appliance should
be performed by qualified personnel. Hearth &
Home Technologies recommends NFI certified
professionals, or technicians supervised by an
NFI certified professional.
September 15, 2011
Advertisement
Table of Contents
Related Manuals for Quadra-Fire 41I-ACC
Summary of Contents for Quadra-Fire 41I-ACC
-
Page 1: Installation And Operation
41-I ACC WOOD INSERT Automatic Combustion Control (ACC) OWNER’S MANUAL Installation and Operation Model: 41I-ACC CAUTION DO NOT DISCARD THIS MANUAL • • Read, understand and • Leave this manual with Important operating follow these instructions party responsible for a n d m a i n t e n a n c e for safe installation and use and operation. - Page 2 41I ACC Wood Insert and Welcome to the Quadra-Fire Family Hearth & Home Technologies welcomes you to our tradition of our stoves, inserts and fireplaces. And yet we are old- of excellence! In choosing a Quadra-Fire appliance, you fashioned when it comes to craftsmanship. Each unit is have our assurance of commitment to quality, durability, and meticulously fabricated and gold and nickel surfaces are performance.
-
Page 3: Table Of Contents
41I ACC Wood Insert Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury. • NOTICE: Indicates practices which may cause damage to the appliance or to property. TABLE OF CONTENTS Installer’s Guide Congratulations ...............2 Sample of Safety/Serial Number Label ......2 Warranty Policy ...............4-5 Section 6: Getting Started A. Design, Installation & Location Section 1: Listing and Code Approvals Considerations ..........26 A. Appliance Certifications........6 B. Draft ..............26 B. Mobile Home Approved........6 C. Negative Pressure..........27... - Page 4 41I ACC Wood Insert Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance...
- Page 5 41I ACC Wood Insert WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
-
Page 6: Section 1: Listing And Code Approvals
Max Wood Length: 18 inches Fuel: Cord Wood NOTE: This installation must conform with local codes. In the Shipping Weight: absence of local codes you must comply with the UL1482, (UM) 345 lbs 84-HUD and NPFA211 in the U.S.A. and the ULC S628-93 and CAN/CSA-B365 Installation Codes in Canada. WARNING The Quadra-Fire 41I Wood Insert (ACC) meets the U.S. Environmental Protection Agency’s 1990 particulate emis- sion standards. Fire Risk. Hearth & Home Technologies disclaims any B. Mobile Home Approved responsibility for, and the warranty will be voided by, the following actions: • This appliance is approved for mobile home installa- • Installation and use of any damaged appliance. tions when not installed in a sleeping room and when • Modification of the appliance. -
Page 7: Section 2: Operating Instructions
41I ACC Wood Insert User Guide Operating Instructions WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • DO NOT touch glass until it is cooled • NEVER allow children to touch glass • Keep children away • CAREFULLY SUPERVISE children in same room as appliance. • Alert children and adults to hazards of high temperatures. High temperatures may ignite clothing or other flammable materials. • Keep clothing, furniture, draperies and other flammable materials away. If you expect that children may come into contact with this appli- ance, we recommend a barrier such as a decorative screen. -
Page 8: Fire Safety
41I ACC Wood Insert B. Fire Safety Hearth & Home Technologies WILL NOT warranty stoves To provide reasonable fire safety, the following should be that exhibit evidence of over-firing. Evidence of over-firing given serious consideration: includes, but is not limited to: 1. Install at least one smoke detector on each floor of • Warped air tube your home to ensure your safety. They should be located away from the heating appliance and close • Deteriorated refractory brick retainers to the sleeping areas. Follow the smoke detector... -
Page 9: Burning Process
2. Second Stage F. Burning Process In the secondary stage wood gives off flammable gases which burn above the fuel with bright flames. In recent years there has been an increasing concern about air quality. Much of the blame for poor air quality has been During this stage of burning: placed on the burning of wood for home heating. • The flames must be maintained and not allowed to go out In order to improve the situation, we at Quadra-Fire have to ensure the cleanest possible fire. developed cleaner-burning wood appliances that surpass • If the flames tend to go out, it is set too low for your burn- the requirements for emissions established by our governing ing conditions. agencies. The air control located at the upper right hand corner is used to These wood appliances must be properly operated in order adjust for burn rates. This is called the Burn Rate Air Control. to ensure that they perform the way they are designed to Figure 10.1 on page 10. -
Page 10: Automatic Combustion Control (Acc)
41I ACC Wood Insert G. Automatic Combustion Control (ACC) Typically, when you build a fire, you open the air controls fully and monitor the fire to prevent it from going into an overfire situation and/or burning your wood up too quickly before you shut down the air controls to the desired burn rate. When using the Automatic Combustion Control (ACC) system, Burn Rate Control you do not have to continually monitor the fire. Once you set the ACC system it will control the fire for you. Follow the instructions below to learn how to operate your stove with ease. H. Air Controls 1. Start-Up Air Control The Start-Up Air Control has two primary functions. The first function is to activate the Automatic Combustion Control system (ACC). -
Page 11: Burn Rates And Operating Efficiency
41I ACC Wood Insert 3. Burn Rate Air Control • The air supply enters at the upper front of the firebox, 5. Low Burn Rate - Below 10,000 BTU/hr* near the top of the glass door. • Leave the Burn Rate Air Control at the bottom marker. • This preheated air supplies the necessary fresh oxygen • Push the Start-Up Air Control all the way back until it to mix with the unburned gases, helping to create the stops and then pull forward until it stops. -
Page 12: Correct Baffle & Blanket Placement
41I ACC Wood Insert J. Correct Baffle & Blanket Placement INCORRECT POSITIONS WARNING Fire Risk Improper baffle placement may cause: • Overheating of firebox • Overheating the chimney Baffle must be placed properly (see instructions) Replace baffle if damaged or missing. NOTE: A missing, damaged or improperly positioned baffle Ceramic Blanket and Baffle Board are NOT is dangerous and may cause damage and poor efficiency. in contact with the back of the firebox. It will also void your warranty. Note: This are generic drawings and may not represent your specific model. CORRECT POSITION Back of Firebox Ceramic Blanket Ceramic Blanket is NOT in contact with the back of the firebox and NOT even with the Baffle Board in the front. -
Page 13: Building A Fire
41I ACC Wood Insert K. Building A Fire • Open door slowly so that ash or smoke does not exit ap- pliance through opening. WARNING • Large logs burn slowly, holding a fire longer. • Small logs burn fast and hot, giving quick heat. 9. As long as there are hot coals, repeating steps 6 through Fire Risk. 8 will maintain a continuous fire. Keep combustible materials, gasoline and other flammable vapors and liquids clear of appliance. • Do NOT store flammable materials in the appliance’s vicinity. NOTE: • DO NOT USE GASOLINE, LANTERN FUEL, • Build fire on brick firebox floor. KEROSENE, CHARCOAL LIGHTER FLUID OR SIMILAR LIQUIDS TO START OR “FRESHEN UP” A • Do NOT use grates, andirons or other methods to support FIRE IN THIS HEATER. fuel. It will adversely affect emissions. • Keep all such liquids well away from the heater while it is in use. -
Page 14: Wood Fuel
41I ACC Wood Insert L. Wood Fuel Moisture WARNING WARNING Fire Risk. • Do NOT burn wet or green wood. Fire Risk. • Store wood in dry location. • DO NOT BURN GARBAGE OR FLAMMABLE • Stack wood so both ends are exposed to air. FLUIDS SUCH AS GASOLINE, NAPTHA OR Wet, unseasoned wood can cause accumulation of ENGINE OIL. creosote. • DO NOT USE CHEMICALS OR FLUIDS TO START A The majority of the problems appliance owners experience FIRE. are caused by trying to burn wet, unseasoned wood. • Do NOT burn treated wood or wood with salt (driftwood). • Wet, unseasoned wood requires energy to evaporate the • May generate carbon monooxide if burn material other water instead of heating your home, and than wood. May result in illness or possible death. • Causes evaporating moisture which cools your chimney, accelerating formation of creosote. -
Page 15: Blower Operating Instructions
41I ACC Wood Insert M. Operating the Blower Control Box with Snap Disc 1. The blower will turn on/off automatically when set to AUTO. Figure 15.1. 2. When set to MANUAL, the fan will turn on/ off only when you turn it on or off. This setting over-rides the internal snap disc. 3. Adjust the speed of the fan by turning the HIGH/LOW knob to the desired setting. N. Blower Operating Instructions 1. Initial (cold) startup: Open both controls fully by rais- ing the Burn Rate Air Control all the way up until it stops... -
Page 16: Clear Space
41I ACC Wood Insert Q. Opacity (Smoke) O. Clear Space Opacity is the measure of how cleanly your appliance is • Do NOT place combustible objects within 4 ft (1.2 m) of burning. the front of appliance. Figure 16.1. Opacity is measured in percent: • 100% opacity is when an object is totally obscured by WARNING the smoke column from a chimney, and Fire Risk. • 0% opacity means that no smoke column can be seen. • Do NOT place combustible objects within 48 As you become familiar with your appliance, you should inches in front of the appliance. -
Page 17: Quick Start Guide
41I ACC Wood Insert Note: These are generic drawings and may not represent R. Quick Start Guide your specific model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR CONTROLS ADD NEWSPAPER LOAD WOOD BURN HIGH RATE Upper right corner START-UP Lower right corner Push In and then Pull Out ADD KINDLING WARNING! Risk of Fire Close and securely latch the door after... -
Page 18: Section 3: Maintenance And Service
41I ACC Wood Insert Maintenance and Service Creosote - Formation and Need for Removal A. Disposal of Ashes • When wood is burned slowly, it produces tar and other • Frequency: When ash is within 1-3/4 inch (44mm) of organic vapors, which combine with expelled moisture firebox lip. Leave 1/4 to 1/2 inch (6-13mm) of ash in the to form creosote. bottom of the firebox. • The creosote vapors condense in the relatively cool •... -
Page 19: Glass Cleaning
41I ACC Wood Insert F. Inspect Firebrick E. Glass Cleaning • Frequency: After each ash removal • Frequency: As desired • By: Homeowner • By: Homeowner Replace the firebrick if they become crumbly and/or if • Clean glass with a non-abrasive glass cleaner. Abrasive there is a 1/4 inch (6.35mm) gap between the bricks. cleaners may scratch and cause glass to crack. The firebox is lined with firebrick, which has exceptional • If the deposits on the glass are not very heavy, normal insulating properties. Do not use a grate; simply build glass cleaners work well. Heavier deposits may be a fire on the firebox floor. Do not operate appliance removed by using a damp cloth dipped in wood ashes or without firebrick. -
Page 20: Quick Reference Maintenance Guide
41I ACC Wood Insert G. Quick Reference Maintenance Guide Start the first inspection after the first 2 months of use, or if performance changes, and adjust your schedule CAUTION! accordingly. Maintenance is required for safe operation Allow the appliance to completely cool and must be performed to maintain your warranty. down before performing any cleaning or maintenance. Frequency Task Baffle & Blanket Baffle and blanket placement is critical to MONTHLY heat output, efficiency and overall life of the Blanket unit. Make sure the baffle is pushed all of the After Every... -
Page 21: Section 4: Troubleshooting Guide
41I ACC Wood Insert Troubleshooting Guide With proper installation, operation, and maintenance your woodstove will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken. Start Fire Problems Possible Cause Solution Can not get fire started Not enough kindling/paper or no Use dry kindling, more paper. Arrange kindling & Excessive smoke or spillage kindling/paper wood for air movement. Burns too slowly Not enough heat output Check for restricted termination cap Check for blockage of outside air kit (if installed). Check for flue blockage. Pre-warm flue before starting fire (refer to Building a Fire Section). Not enough air for fire to ignite Check for adequate vent height (refer to Chimney Height Section). Open window below the appliance towards the wind. Wood condition is too wet, too Use dry, seasoned wood (refer to Seasoned Wood large Section). Bed of coals not established Start with paper & kindling to establish bed of before adding wood coals (refer to Building a Fire Section). -
Page 22: Section 5: Service Parts Replacement
Blower Housing Assembly CAUTION! Handle glass with care. • Inspect the gasket to ensure it is undamaged. • Do NOT strike, slam or scratch glass. • Do NOT operate appliance with glass & door assembly removed. • Do NOT operate with glass cracked, broken or scratched. Figure 22.1 Quadra-Fire appliances are equipped with ceramic super heat-resistant glass, which can only be broken by impact or misuse. CAUTION Shock Risk. • Do NOT remove grounding prong from plug. • Plug directly into properly grounded 3 prong receptacle. • Route cord away from appliance. • Do NOT route cord under or in front of appliance. Page 22... -
Page 23: Blower Replacement
41I ACC Wood Insert CAUTION C. Blower Replacement Shock Risk. • Do NOT remove grounding prong from plug. 1. Remove the 2 screws from the Blower Housing Assem- • Plug directly into properly grounded 3 prong bly using a 5/32 allen wrench. Figure 23.1. receptacle. 2. Disconnect the wires from the blower. • Route cord away from appliance. 3. Remove the 2 screws from the hold down bracket and • Do NOT route cord under or in front of appliance. pull the blower and bracket forward. 4. Remove the blower from the hold down bracket. WARNING 5. Re-install in reverse order. Be certain that the hold down Fire Risk. bracket’s screws are completely seated in the grom- Do NOT allow hot coals or embers to overflow ash lip ments. Insert the locating tab in the hold down bracket... -
Page 24: Baffle Removal
41I ACC Wood Insert D. Baffle Removal E. Door Handle Assembly 1. Remove all ash from the firebox, and extinguish all hot CAUTION! Do not overtighten lock nut. The door handle embers before disposal into a metal container. needs to move smoothly. 2. The baffle board has 2 pieces. With the ceramic blanket Hook Door Latch still in place, slide one baffle piece over the top of other one but still keep it all components inside the firebox. Figure Washer Door Handle 24.1. 3. It is easier to remove both baffle boards and ceramic blanket after the tube channel assembly has been partially disassembled. Follow steps 1 through 4 on page 25 for removal of the tube channel assembly. It is not necessary... -
Page 25: Tube Channel Assembly Replacement
41I ACC Wood Insert F. Tube Channel Assembly Replacement it is off the threads. Drop the right side down, then slide the assembly back to right. Removing Tube Channel Assembly 5. The ceramic blanket and both baffle boards can be removed at the same time you remove the tube channel 1. Remove the right side bricks (3 pieces). assembly. 2. Remove the baffle protection channel by rolling forward 6. When the tube channel assembly is free of the left side and out of the firebox. support, rotate clockwise and pull assembly, blanket and 3. Locate the 2 channel nuts and 2 channel bolts inside of baffles out through the front opening. chamber and remove. 7. Re-install in reverse order. NOTE: S oak the bolts with penetrating oil for at least 15 min- utes before trying to remove them. 4. Slide the tube channel assembly all the way to left until 2 Tube Channel Nuts 2 Tube Channel bolts Rotate and remove from... -
Page 26: Installer's Guide
41I ACC Wood Insert Installer’s Guide Getting Started B. Draft A. Design and Installation Considerations Draft is the pressure difference needed to vent appliances CAUTION successfully. When a appliance is drafting successfully, all combustion byproducts are exiting the home through the Check building codes prior to installation. chimney. • Installation MUST comply with local, regional, state and Considerations for successful draft include: national codes and regulations. -
Page 27: Negative Pressure
41I ACC Wood Insert C. Negative Pressure WARNING Asphyxiation Risk. • Negative pressure can cause spillage of com- bustion fumes, soot and carbon monoxide. • Appliance needs to draft properly for safety. Negative pressure results from the imbalance of air available for the appliance to operate properly. It can be strongest in lower levels of the house. Causes include: • Exhaust fans (kitchen, bath, etc.) • Range hoods • Combustion air requirements for furnaces, water heaters and other combustion appliances • Clothes dryers • Location of return-air vents to furnace or air conditioning • Imbalances of the HVAC air handling system • Upper level air leaks such as: - Recessed lighting - Attic hatch - Duct leaks To minimize the effects of negative air pressure: • Install the outside air kit with the intake facing prevailing winds during the heating season... -
Page 28: Chimney Termination Requirements
41I ACC Wood Insert D. Locating Your Stove & Chimney • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. Location of the appliance and chimney will affect perfor- mance. As shown in Figure 28.1 the chimney should: • Locate termination cap away from trees, adjacent structures, uneven roof lines and other obstruc- • Install through the warm space enclosed by the build- tions. -
Page 29: 2-10-3 Rule
41I ACC Wood Insert F. 2-10-3 Rule These are safety requirements and are not meant to assure proper flue draft. This appliance is made with a 6 inch (152mm) diameter chimney connector as the flue collar on the unit. • Changing the diameter of the chimney can affect draft and cause poor performance. • It is not recommended to use offsets and elbows at altitudes above 4000 feet above sea level and or when there are other factors that affect flue draft. Less than 10 ft. (305cm) 2 ft. (61cm) 3 ft. (91cm) 2 ft. (61cm) Minimum 10 ft. (305cm) To Nearest Roofline 3 ft. (91cm) Minimum Pitched Roof Figure 29.1 10 ft. (305cm) or more Less than 10 ft. -
Page 30: Tools And Supplies Needed
41I ACC Wood Insert Pre-Burn Check List G. Tools And Supplies Needed Before beginning the installation be sure the following tools Place the appliance in a location near the final and building supplies are available: installation area and follow the procedures below: Open the appliance and remove all the parts and Reciprocating saw Framing material articles packed inside the Component Pack. Inspect Pliers High temp caulking material all the parts and glass for shipping damage. Contact your dealer if any irregularities are noticed. Hammer Gloves All safety warnings have been read and followed. Phillips screwdriver Framing square This Owner’s Manual has been read. Flat blade screwdriver Electric drill and bits Floor protection requirements have been met. Plumb line Safety glasses Venting is properly installed per vent manufacturing instructions. Level Tape measure The proper clearances from the appliance and chim- 1/2-3/4 in. length, #6 or #8 self-drilling screws ney to combustible materials have been met. -
Page 31: Section 7: Dimensions And Clearances
41I ACC Wood Insert Dimensions and Clearances NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) A. Appliance Dimensions 30 in. 762 mm 24 in. 610 mm 16 1/4 in. 413mm 10 9/16 in. 269 mm Figure 31.1 Top View Figure 31.2 Front View 11 1/2 in. -
Page 32: Minimum Clearances To Combustible Material
41I ACC Wood Insert B. Clearances to Combustibles, United States and Canada (UL and ULC) Minimum Clearances to Combustible Material TOP TRIM 32-1/8 22-5/8 816mm 575mm 42-1/8 1070mm USA 18-1/8 HEARTH CANADA EXTENSION 22-1/8 (562mm) 12in max MANTEL USA 23-1/8 CANADA 25-1/8 (638mm) 44-1/8 1121mm... -
Page 33: Clearances To Combustibles (Ul And Ulc)
41I ACC Wood Insert B. Clearances to Combustibles, United States and Canada (UL and ULC) (cont.) WARNING Thermal Protection Fire Risk. • Comply with all minimum clearances to combustibles as specified. USA and CANADA • Failure to comply may cause house fire. Floor height 0” to 1-3/4” 1/2 inch (13mm) of (0 to 44mm) below insert R=2.38 NOTE: Clearances may only be reduced by base. -
Page 34: Section 8: Chimney Systems
41I ACC Wood Insert Chimney Systems D. Masonry Chimney A. Venting Systems • Must meet minimum standards of NFPA 211. Chimney Connector: • Must have at least 5/8 inch (16mm) fireclay lining joined It is also known as flue pipe or stove pipe. It must be with refractory cement. (Installations into a clay flue 6 inches (152mm) minimum diameter stainless steel without a stainless steel liner may reduce draw which affects connector pipe. - Page 35 41I ACC Wood Insert Masonry Chimney (Cont’d) NOTE: In Canada, this fireplace insert must be installed with a continuous chimney liner of a 6 inch (152mm) diam- This insert conforms with the UL 1482 and ULC S628 eter extending from the fireplace insert to the the top of the (Canada) in all respects, and is approved to UL & ULC chimney. The chimney liner must conform to the Class 3 safety standards for installation and use within a fireplace requirements of CAN/ULC-S635, Standard for Lining Sys- with a masonry chimney in accordance with NFPA 211 and tems for Existing Masonry or Factory-Built Chimneys and...
-
Page 36: Prefabricated Metal Chimney
41I ACC Wood Insert E. Metal Heat Circulating Masonry •The original factory-built clearance fireplace chimney cap must be re-installed after installing the approved This insert conforms with the safety standard UL-1482 and chimney liner meeting type UL 103 HT requirements ULC S628 (Canada) in all respects and is approved to UL & (2100°F) per UL 1777. ULC safety standards for installation and use within a fire- •If the chimney is not listed as meeting HT requirements, place with masonry chimney, in accordance with NFPA 211, or if the factory built fireplace was tested prior to 1998, a with a direct flue collar connection. full height listed chimney liner must be installed from the appliance flue collar to the chimney top. -
Page 37: Securing Chimney Components
41I ACC Wood Insert Prefabricated Metal Chimney (Cont’d) H. Altering the Fireplace Inches Millimeters The following modifications of factory-built fireplaces are Minimum Width of Cavity Opening - Front permissible: Minimum Width of Cavity Opening - Rear The following parts may be removed: Minimum Height Minimum Depth from Front to Rear 16-1/4 Damper Smoke Shelf or Baffle Ember Catches Fire Grate NOTE: Refer to chimney liner manufacturer for recom- Viewing Screen/Curtain Doors mendations on supporting the liner. -
Page 38: Ovalizing Round Stainless Steel Liners
Inspect the existing fireplace and chimney for any damage K. Chimney Height / Rise and Run or flaws such as burnouts, metal or refectory warping. To be sure that your Quadra-Fire insert burns properly, the chimney draft (static pressure) should be approximately -0.07 Inspection to a minimum of NFPA 211 Level II is recom- inches water column (W.C.) during a high burn and -0.04 mended. All repairs must be made prior to installing an inches W.C. during a low burn, measured 6 inches (152mm) -
Page 39: Section 9: Appliance Set-Up
41I ACC Wood Insert Appliance Set-up A. Outside Air Kit Installation WARNING A source of air (oxygen) is necessary in order for combustion to Fire Risk. take place. Whatever combustion air is consumed by the fire must be replaced. Air is replaced via air leakage around win- Asphyxiation Risk. dows and under doors. In homes that have tightly sealed doors Do not draw outside combustion air from: and windows, an outside air source is needed. An optional Out- • Wall, floor or ceiling cavity side Air Kit is available. • Enclosed space such as an attic or garage Items Needed for Installation (not supplied) • Close proximity to exhaust vents or chimneys • Phillips head screw driver Fumes or odor may result • Silicone sealant • (Optional Outside Air Kit) 4 inch flex aluminum pipe, or if WARNING using alternate material, then it shall be made from durable,... -
Page 40: Securing Stove Pipe/Liner To Flue Collar
Optional use of a Simpson Duravent 15° Universal Elbow 1. There are 4 pre-drilled holes in the flue collar 90 degrees Part Number 4615 may be purchased directly through your apart. Attach the flue collar to the stove pipe/liner. If the local Simpson Durvent Pipe Distributor or from your local seal is questionable use high temperature sealant such Quadra-Fire dealer, Part Number 15DEGADAPT. as stove mastic Figure 39.1. Figure 39.2 shows a vertical installation and also how to 2. Attach gasket to bottom side of flue collar with a thin coat create an optional 30° elbow installation. of silicone. The 15° elbow may be secured directly to the flue collar. -
Page 41: Leveling Legs
41I ACC Wood Insert E. Securing Appliance to Stove Pipe/Liner D. Leveling Legs 1. Once you have the appliance in place and secured, reach 1. Remove the 2 screws already installed on each leg. up through the flue opening and grab the attachment bar 2. Move legs to the desired height. and pull down inside flue opening. Figure 40.2. 3. Re-install the screws to secure in place. 2. Insert the 5/16 bolts inside the cast flue and through the chimney mounting bar. Securely tighten the nuts. Fas- teners are provided. 3. Re-install the tube channel assembly, baffle board, ceramic blanket and baffle protection channel. Remove 2 screws from both sides. Adjust the legs up or down to level appliance. -
Page 42: Surround & Trim Installation
41I ACC Wood Insert F. Surround & Trim Kit Installation 1. Lay surround face down on a protected surface to pre- vent scratching. Secure 2 Side Surrounds to Top Surround 2. Using a Phillips head screw driver attach the side sur- rounds to the top surround using 2 #8 sheet metal screws provided with the kit. Figure 41.1 3. Lay the trim face down and place the corner brackets into position. 4. Using a standard flat screw driver tighten the corner brackets. Figure 41.2. -
Page 43: Blower Cord Installation - Left Side
41I ACC Wood Insert G. Blower Cord Installation on Left Side The blower cord is shipped on the right side of the appli- ance. You may relocate the cord so it is on the left side. Relocating Blower Cord to Left Side 1. Remove the convection blower housing from the appli- ance by removing two 5/32 allen head bolts. 2. Remove Blower assembly from appliance by remov- ing two 8/32 phillips head screws located under ashlip. Figure 42.1. 3. Using phillips head screw driver, remove snap disc bracket and cord restraint bracket from right side. Figure 42.2 4. Re-install snap disc bracket and cord restraint bracket to Figure 42.2 left side of blower housing. Figure 42.3. -
Page 44: Zero-Clearance Adjustable Trim Support
41I ACC Wood Insert H. Zero Clearance Adjustable Trim Support, EXPLODED VIEW OF SCISSORS 2” to 10” Part No. 841-0990, size 9” x 45” and Part No. ADJSPT-12, size 12” x 50” SCREWS ARE CIRCLED Included in Kit: ( 1) Trim Top, (1) Trim Front, (2) Trim Sides, Double-Sided Tape (already installed) DOUBLE-SIDED TAPE DOUBLE-SIDED TAPE... -
Page 45: Mobile Home Installation
41I ACC Wood Insert Mobile Home Installation 1. An outside air inlet must be provided for combustion and 8. Burn wood only. Other types of fuels may generate must remain clear of leaves, debris, ice and/or snow. It poisonous gases (e.g., carbon monoxide). must be unrestricted while unit is in use to prevent room 9. If unit burns poorly while an exhaust blower is on in air starvation which can cause smoke spillage and an home, (i.e., range hood), increase combustion air. inability to maintain a fire. Smoke spillage can also set off smoke alarms. 10. Installation shall be in accordance with the Manufacturers Home & Safety Standard (HUD) CFR 3280, Part 24. -
Page 46: Section 11: Reference Materials
41I ACC Wood Insert Reference Materials 41I-ACC-BK Service Parts Beginning Manufacturing Date: Sept 2011 Wood Insert Appliance Ending Manufacturing Date: Active Part number list on following page. 09/11 Page 46 7045-178 September 15, 2011... -
Page 47: Service Parts & Accessories
41I ACC Wood Insert 41I-ACC-BK Service Parts Beginning Manufacturing Date: Sept 2011 B. Service Parts & Accessories Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Flue Attach Ring SRV7044-154 Outer Top 435-0300 Rear Channel Assembly SRV7045-001 Screw Hwh Ms 1/4-20 X 34 Ns 220-0080/25... -
Page 48: Service Parts
41I ACC Wood Insert 41I-ACC-BK Service Parts Beginning Manufacturing Date: Sept 2011 Ending Manufacturing Date: Active #10 Door Assembly w/Glass 10.1 10.2 10.3 10.4 10.7 10.5 10.6 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Door Assembly w/Glass SRV7045-018 10.1... -
Page 49: Blower Assembly
41I ACC Wood Insert 41I-ACC-BK Service Parts Beginning Manufacturing Date: Sept 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Tube Channel Assembly SRV7045-006 Nut, Ser Flange Small 1/4-20 226-0130/24 Screw Hwh Ms 1/4-20 X 34 Ns 220-0080/25 Baffl e Board 2 pieces SRV7045-160 Door Latch Bracket Assembly SRV7045-021... -
Page 50: Service And Maintenance Log
41I ACC Wood Insert C. Service And Maintenance Log Date of Service Performed By Description of Service Page 50 7045-178 September 15, 2011... -
Page 51: Homeowner's Notes
41I ACC Wood Insert D . Homeowner’s Notes Page 51 7045-178 September 15, 2011... -
Page 52: Contact Information
Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer, log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL •...
