Silicon Graphics Rackable C1000 User Manual page 14

007-5716-001
Table 1-1 Front Panel Components (continued)
Component Description
Front-Panel I/O The I/O interface to the motherboard. The configuration of
the various I/O ports is dependent on the motherboard used
in your configuration. For detailed I/O specifications, refer
to the motherboard manual included with the
documentation and accessory kit. Typical I/O includes the
following:
– serial port (RS-232, 9600 baud)
– USB ports
– PS-2 connector for mouse and keyboard
– VGA port
– Ethernet ports (RJ-45, eth0/eth1, 10/100/1000Mb)
Drive area This area is the location of any drive option that is installed
in the server. Depending on the configuration of your
server, a DVD/DVD-RW or CD/CD-RW drive may be
present. Also, in this area is space for an LCD display that
is used with a Roamer remote management module if one
was purchased with the server.
Key Components of Your 1U C1000 Server
5
