Billion BiPAC 8500 Quick Install Manual

2.3mb/4.6mb shdsl and 5.7mb shdsl.bis bridge/router vpn firewall 4-port switching hub
Hide thumbs Also See for BiPAC 8500:

Advertisement

Quick Links

Download this manual See also: User Manual
BiPAC 8500/8520/8501
2.3Mb/4.6Mb SHDSL and 5.7Mb SHDSL.bis
Bridge/Router
VPN Firewall
4-Port Switching Hub

Quick Install Guide

This guide covers only the initial
Internet set-up and is based on
the 8500 model. Please refer to
the full User Manual on the CD-
ROM for more advanced
settings. Screen shots may vary
from the actual router.
www.billion.uk.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the BiPAC 8500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billion BiPAC 8500

Summary of Contents for Billion BiPAC 8500

  • Page 1: Quick Install Guide

    BiPAC 8500/8520/8501 2.3Mb/4.6Mb SHDSL and 5.7Mb SHDSL.bis Bridge/Router VPN Firewall 4-Port Switching Hub Quick Install Guide This guide covers only the initial Internet set-up and is based on the 8500 model. Please refer to the full User Manual on the CD- ROM for more advanced settings.
  • Page 2 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
  • Page 3 LINE Port of your Billion 8500 VPN Firewall Bridge/Router. 3. Connect the Ethernet cable (RJ-45) from one of the Ethernet ports of your Billion 8500 VPN Firewall Bridge/Router to the Network Adaptor in your computer.
  • Page 4 as supplied by your Service Provider. No other changes should be necessary. * Standard UK settings are VPI 0, VCI 38, Encapsulation PPPoA, and Annex B for SHDSL. If the modem is not pre-configured for the UK, you will have to make changes to the VPI and VCI settings and check the Encapsulation.
  • Page 5 3. From the Menu on the left select Quick Start. 4. Under PPP add your user name and password as provided by your ISP (only change VPI and VCI settings and Encapsulation if necessary) and click Apply.
  • Page 6 5. Click OK. 6. Now click the blue Save Config button.
  • Page 7 7. Confirm by clicking Apply. 8. Click OK.
  • Page 8 9. Now restart the router by clicking the blue Restart button 10. Confirm restart of the router by clicking Restart.
  • Page 9 11. Wait for the router to finish the restart process. 12. Go to the Status Page which should now show a WAN IP address and your connection status under WAN.
  • Page 10 Provider. For advanced configuration please access the full manual on the CD provided. Telephone Support for Internet Access ONLY is available during office hours from Mon-Fri 10am–5pm on 0870-8501528. If you are successfully connected to the Internet and have a support query please contact www.billion.uk.com/esupport submit a ticket.

This manual is also suitable for:

Bipac 8520Bipac 8501
