Billion BiPAC 7202 Quick Start Manual

(802.11g) adsl2+ modem / router
Hide thumbs Also See for BiPAC 7202:

Advertisement

Quick Links

BiPAC 7202 / 7202G
(802.11g) ADSL2+ Modem / Router
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 7202 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Billion BiPAC 7202

  • Page 1 BiPAC 7202 / 7202G (802.11g) ADSL2+ Modem / Router Quick Start Guide...
  • Page 3: Package Contents

    Do not use the same power source for the BiPAC 7202(G) as other equipment. Do not open or repair the case yourself. If the BiPAC 7202(G) is Warning too hot, turn off the power immediately and have it repaired at a qualified service center.
  • Page 4: The Front Leds

    Quick Start Guide The Front LEDs BiPAC 7202 BiPAC 7202G PPP : ADSL: LAN Port: WLAN : (7202G only) SYS : PWR : Meaning Lit steady when there is a PPPoA / PPPoE connection. Lit when successfully connected to an ADSL DSLAM (“linesync”).
  • Page 5: The Rear Ports

    Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the four LAN ports when connecting to a PC or an office/home network of 10Mbps or 100Mbps. Connect the supplied RJ-11 (“telephone”) cable to this port when connecting to the ADSL/telephone network. BiPAC 7202(G) ADSL2+ Modem/Router Meaning...
  • Page 6 Quick Start Guide Connecting BiPAC 7202 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit.
  • Page 7 BiPAC 7202(G) ADSL2+ Modem/Router Connecting BiPAC 7202G 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR, SYS, and WLAN LEDs are lit steadily and that the relevant LAN LED is...
  • Page 8: Configuring Pc In Windows Xp

    Quick Start Guide Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4.
  • Page 9: Configuring Pc In Windows 2000

    3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. BiPAC 7202(G) ADSL2+ Modem/Router...
  • Page 10: Configuring Pc In Windows 98/Me

    Quick Start Guide Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC.
  • Page 11 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK. BiPAC 7202(G) ADSL2+ Modem/Router...
  • Page 12 Quick Start Guide Configuring Your ADSL Firewall Router To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed Open the web browser and type http://192.168.1.254 address box. This number is the default IP address for this router. Press Enter. 2.
  • Page 13: Product Support And Contact Information

    If you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer where you purchased this product. Contact Billion WORLDWIDE http://www.billion.com Mac OS is a registered Trademark of Apple Computer, Inc. Windows 98, Windows NT, Windows 2000, Windows Me and Windows XP are registered Trademarks of Microsoft BiPAC 7202(G) ADSL2+ Modem/Router...

This manual is also suitable for:

Bipac 7202g
