- Page 1 BiPAC 5200 Series (802.11g) ADSL2+ Firewall Router Quick Start Guide...
-
Page 2: Package Contents
PLEASE READ THE QUICK START GUIDE AND FOLLOW THE STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER’S MANUAL ON THE CD-ROM. -
Page 3: Hardware Overview
Quick Start Guide Hardware Overview BiPAC 5200G/ 5200GR2/ 5200GR3/ 5200GR4/ 5200GR5 The Front LEDs Lit when power is ON The Rear Ports Connect the detachable antenna Connect the supplied RJ-11 cable to this port when connecting to the ADSL/telephone network Lit green when the wireless connection is established... - Page 4 BiPAC 5200/ 5200R3 The Front LEDs Lit steady when there is a PPPoA / PPPoE The Rear Ports Connect the supplied power adapter to this jack Billion BiPAC 5200 Series ADSL2+ Firewall Router Lit when connected to an Ethernet device Lit when successfully connected to an ADSL DSLAM...
- Page 5 Quick Start Guide BiPAC 5200S/ 5200SR2/ 5200SR3 The Front LEDs The Rear Ports Attention: BiPAC 5200S has not supported the ON/OFF switch Connect the supplied RJ-11 cable to this port when connecting to the ADSL/telephone network Lit when Lit when connected to an power is ON Ethernet device...
-
Page 6: Hardware Connection
Billion BiPAC 5200 Series ADSL2+ Firewall Router Hardware Connection BiPAC 5200G/ 5200GR2/ 5200GR3/ 5200GR4/ 5200GR5 BiPAC 5200/ 5200R3 BiPAC 5200S/ 5200SR2/ 5200SR3... -
Page 7: Hardware Installation
Quick Start Guide Hardware Installation Power Connection Plug the supplied power adapter to the wall jack and the other side to the router. Please note that the plug type may differ according to different countries. 2. LAN Connection Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other side to the PC’s Ethernet interface. -
Page 8: Setup Utility
4. Splitter/ Micro-filter Connection Splitter / Micro-filter are important for ADSL installation. High-frequency signals are directed to the ADSL modem, and low-frequency signals are directed to the telephone or other analog voice-channel device to prevent inter-modulation distortion and also to get good speed and stable ADSL sync rate. a) Splitter connection If the installation has only a single telephone and a single ADSL modem, then a splitter can be employed. -
Page 9: Troubleshooting
Quick Start Guide Troubleshooting 1. None of the LEDs are on when you turn on the router. Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. In this case you should contact technical support. 2.
