Billion BiPAC 8501 Specifications

SHDSL.bis series feature chart
Model
BiPAC 8501 5.7Mbps (2-wire SHDSL.bis)
BiPAC 8521
11.4Mbps (4-wire SHDSL.bis)
BiPAC 8501/8521
5.7/11.4Mbps SHDSL.bis (VPN) Firewall Bridge/Router
Higher symmetric data rates power office productivity!
Small businesses often can maintain competitiveness by using a cost-effective networking solution instead of expensive leased
lines for an online presence. As a substitute for a local leased line, Billion's BiPAC 8501/8521 series offers a perfect solution with
symmetric transmission so SOHO and SME users can enjoy high-speed SHDSL.bis broadband services. Users can also access
bandwidth-consuming applications such as video conferencing with greater ease and speed than previously. The device
supports the latest SHDSL.bis technology with a higher symmetric upstream and downstream data rate of up to 5.7Mbps or
11.4Mbps. The Rate Adaptive feature allows the BiPAC 8501/8521 series to adjust the data rate automatically according to the
quality of the wire connection. The Quality of Service feature ensures a smooth net connection for inbound and outbound data
with minimal traffic congestion. The BiPAC 8501 also supports IPSec VPN for users to create secure data communication
between two or more sites. Rich Firewall security features such as SPI, DoS attack prevention and URL Content Filtering are
also integrated, providing users with unparalleled access protection.
High-speed Internet Access with 2/4-wire SHDSL.bis
The BiPAC 8501/8521 series complies with the latest SHDSL.bis technology standards for worldwide deployment and supports
a symmetric data rate of up to 5.7Mbps/11.4Mbps. With SHDSL.bis technology, the BiPAC 8501/8521 series allows office users
to enjoy high-speed symmetric bandwidth and access multimedia applications such as FTP sharing, video conferencing and
real-time audio with greater ease and speed than ever before.
Smooth, Responsive Net Connection
The Quality of Service (QoS) feature helps users to manage their bandwidth and prioritize data transfer effectively. It gives full
control over the passage of any type of data, ensuring latency-sensitive and bandwidth-consuming applications such as video
conferencing, customer information or FTP sharing, can move through the router at instantaneous speed, even when experiencing
heavy use. The speed for inbound and outbound data passed through the router can be controlled to ensure that users do not
saturate bandwidth with browsing activities.
Firewall Security with DoS Prevention and SPI
Besides having a built-in NAT natural firewall feature, the BiPAC 8501/8521 series also provides advanced hacker pattern-filtering
protection that can automatically detect and block Denial of Service (DoS) attacks, such as IP Spoofing, Ping of Death, etc. The
router is also built with Stateful Packet Inspection (SPI) to determine whether a data packet should be allowed to pass through
the firewall to the private LAN.

Virtual Private Network

The BiPAC 8501 supports embedded Virtual Private Network (VPN) protocols for users to establish private encrypted tunnels
over the public Internet.
BiPAC 8501
Symmetric Data Rate Back-to-back connectivity
BiPAC 8521
IPSec VPN EFM Compliance
- ˇ
ˇ -
LINE CONSOLE
BiPAC 8501 Real Panel
2 LINE 1 CONSOLE
-
ˇ
BiPAC 8521 Real Panel
• Supports Symmetric Data Transfer
up to 5.7Mbps/11.4Mbps
• High-speed Internet Access with
SHDSL.bis, backward compatible
with SHDSL
• Secure Virtual Private Network (VPN)
(BiPAC 8501 only)
• Back-to-back Connectivity
(BiPAC 8521 only)
• Supports EFM and EFM Bonding
(future software upgradeable)
• SOHO Firewall Security with DoS
Prevention and SPI
• Access Control with URL Blocking
and Packet Filtering
• DiffServ Quality of Service Control
• Dynamic Domain Name System
(DDNS)
• Integrated 4-port Ethernet Switch
• Ideal for Office Users
4 3 2 1
PWR
RESET
4 3 2 1
PWR
RESET
