(2) Grating Operation: Again, prepare the product
as to allow insertion into the feed chute. Consider
which chute will be used. As an example, placement
of carrots horizontally in the large chute will result in
a long grated product, while vertical insertion in the
smaller chute will result in a short grated product. It
is recommended that chilled cheese be used when
grated cheese is desired, otherwise a gumminess may
result. A fine coating of cornstarch applied to the
cheese before grating will aid in keeping the finished
product separated. A fine coating of cornstarch will
not be visible and is tasteless. Grating cheese is one
of the most trying processes and may cause over-
heating of the motor if not done in the recommended
manner. It is recommended that a slight pulsating
pressure be applied with the pusher while grating,
alternating slight pressure on the pusher—no pres-
sure—continuing in this manner until the block of
cheese is completely grated. It is recommended that
the cheese be prepared to fit the opening in volumes
which will permit motor cool-down time during long
production runs.
(3) Julienne Operation: Insertion of the product to
be cut must be horizontal if a long stick is to be
achieved, e.g., squash sticks. Vertical insertion will
result in finely chopped products, e.g., chopped cel-
ery. A finely chopped onion product may also be
obtained with this operation.
Plate Utilization
The Robot Coupe food processor will perform a vari-
ety of functions: slicing, grating, French fry, and
julienne. There are a total of 25 different plates avail-
able to perform these functions to meet individual
tastes. The 21 discs consists of:

7 slicing discs

8 grating discs
6 julienne discs
The standard Robot Coupe comes with two (2) discs.
Check your most current price list for the discs which
are included as standard. The number and type of
plates will vary depending upon the use of the ma-
chine.
SLICING DISCS
The seven (7) slicing discs range from 1mm (approxi-
mately 3/64") to 6.5mm (approximately 1/4"):
Part Number MM Slicing
27051 1mm
27621 2mm(waved)
27555 2mm
27086 3mm
27566 4mm
27087 5mm
27786 6mm
R2N and R2N Ultra
Operation Manual
Inches (Approx.)
1/32 in.
5/64 in.
5/64 in.
1/8 in.
5/32 in.
3/16 in.
1/4 in.
