Robot Coupe R2N Ultra Operation Manual page 18

robot coupe
Index Pièce / Part Description
1 2 7 2 4 3 CUTTER ATTACHMENT
2 1 0 5 2 3 6 CUTTER LID
2 7 0 5 5 STRAIGHT BLADE
3
4 2 7 0 6 1 FINE SERRATED BLADE
5 3 9 7 9 5 CUTTER BOWL ASSEMBLY
7 1 0 0 9 6 4 SPRING
9 2 9 1 8 4 LOCKING PLATES ASSEMBLY
10 1 0 4 0 9 8 PLASTIC SAFETY ROD FOR BOWL H = 109m TYPE 1 3 QT
11 1 0 4 0 5 0 STAINLESS STEEL NUT FOR BOWL H = 109m TYPE 1 3 QT
12 3 9 1 0 9 MOTOR SUPPORT ASSEMBLY
13 5 0 1 0 1 0 SHAFT SEAL
16 3 9 1 0 7 CONTROL PANEL ASSEMBLY
17 4 0 7 6 7 0 FRONT PLATE
18 1 0 1 1 0 3 BOLT COVER
19 1 0 1 1 0 6 POWER CORD CLIP
20 2 0 0 0 0 5 SCREW 3,9 x 19
21 2 7 2 4 2 VEGETABLE SLICER ASSEMBLY
22 3 9 1 0 4 LID + PUSHERS ASSEMBLY
23 1 0 3 2 8 1 ROUND PUSHER
24 1 0 3 2 8 0 VEGETABLE PUSHER
25 1 1 8 5 9 2 VEGETABLE SLICER LID
26 2 9 8 5 8 GREY VEGETABLE SLICER BOWL SAFETY ROD ASSEMBLY
27 1 0 3 2 8 8 SLINGER PLATE
1 0 2 6 9 9 VEGETABLE SLICER BOWL ASSEMBLY
28
29 1 0 4 1 2 4 BASE
30 2 9 9 1 9 MICROSWITCH ASSEMBLY
31 5 0 0 5 2 7 SEAL RING
32 2 0 0 0 0 3 SCREW 3,5 x 12,7
33 1 0 1 0 9 6 VENTILATION BAFFLE
1 0 1 0 9 5 ABSORBER
34
35 3 9 8 6 5 BASE ASSEMBLY
36 3 9 9 2 8 FOOT ASSEMBLY (x4)
3 9 7 6 3 BOWL HANDLE ASSEMBLY
38
39 3 9 7 5 3 LOCKING WASHER ASSEMBLY
40 3 9 7 6 2 SAFETY ROD ASSEMBLY FOR BOWL TYPE 3
41 1 0 4 1 2 2 VENT COVER
42 1 0 1 0 9 8 VENT COVER + RIVETS
43 2 7 1 3 8 SERRATED BLADE
1 1 7 0 5 8 BLADE CAP
44
45 3 9 2 2 0 SAFETY ROD ASSEMBLY FOR BOWL H = 117m TYPE 2 3 QT
46 R 2 8 6 CIRCUIT-BREAKER
47 R 2 5 5 PLATE RACK
48 5 0 2 5 7 9 HONING STONE
49 R 2 7 7 A SCREEN KIT
50 2 9 0 0 7 WHITE VEGETABLE SLICER BOWL SAFETY ROD ASSEMBLY
51 R 2 4 0 POWER CORD
52 R 2 3 9 MOTOR AO SMITH
53 R 2 3 9 D . 3 ADAPTER PLATE FOR EMERSON MOTOR
54 R 2 3 9 D MOTOR EMERSON
55 R 2 2 2 CAPACITOR F/C MOTOR (R2N)
56 R 2 3 7 BEARING 6203 AO SMITH MOTOR
57 R 2 3 9 D . 2 CAPACITOR
58 R V 3 0 2 4 7 BEARING 6203 EMERSON MOTOR
59 R 2 3 9 D . 1 STARTING RELAY EMERSON
22 229
U.S.A., Inc. Serial number
247xxxxx03
R2N Ultra
231xxxxx03
500xxxxx03
1-Speed, 120 Volt, 1 Phase
60Hz, 1 HP, 1725RPM, 7 Amps
Maj: 06/2008 REV : c
