If the light source where the camera is installed experiences rapid, wide-
variations in lighting, the camera may not operate as intended.
WARNING: To reduce the risk of fire or electronic shock, do not expose the
camera to rain or moisture and do not remove the cover or back.
Product description
Figure 1: Camera UVC-6120-1-P/N
1. Video output
2. Audio output
3. OSD control pad
Figure 2: Camera UVC-6120-1-P2
1. Video output
2. Audio output
3. OSD control pad
UltraView UVC-6120-1 Digital WDR Camera User Manual
4. D/N trigger pin
5. 12 VDC / 24 VAC dual power
4. D/N trigger pin
5. AC96V/AC240 universal power
3
