General menu

Select the General
Figure 5: The General menu
Table 3: General menu
Parameter
ID display
Mirror
DNR
Return
Exit & Save

AE/WDR/BLC menu

Select the AE/WDR/BLC
Figure 6: The AE/WDR/BLC menu
Table 4: AE/WDR/BLC menu
Menu item Description
Lens type Defines the lens type used with the camera.
Select
UltraView UVC-6120-1 Digital WDR Camera User Manual
option from the Main menu to enter the General menu.
Description
Displays the camera ID on screen. Default option is Off.
Flips the camera image so that it is correctly orientated for viewing.
Default option is Off.
Digital noise reduction (DNR) improves the image quality in low light
levels.
When enabled, select the Y and C filter strength: Press
to the previous menu or
mode. Default option is On.
Press Enter to return to the previous menu.
Exits the menu and returns to live mode. Saves changes made.
option from the Main menu to enter the AE menu.
Fixed or DC. If DC is enabled, select the DC level and shutter speed
Exit & Save to save changes and return to live
Return to return
