642 LCD Keypad
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Esprit+ 642 and is the answer not in the manual?

Questions and answers

Related Manuals for Paradox Esprit+ 642

Summary of Contents for Paradox Esprit+ 642

  • Page 1 642 LCD Keypad User Manual...

  • Page 3: Table Of Contents

    Alarm Memory Display ..........11 Regular System Arming ..........12 Stay Arming ..............13 Fast Exit ..............14 Instant Arming ............14 Force Arming .............. 15 Manual Bypass Arming ..........16 Bypass Recall ............. 16 Esprit+ 642 LCD Keypad 1...
  • Page 4 One-Touch Arming ............17 Keyswitch/Push-Button Arming ........18 Timed Auto-Arming ............. 18 No Movement Automatic Arming ........ 19 Fire Alarms ..............19 Additional Features ........22 Chime Zone Selection ..........22 Keypad Muting ............22 Panic Alarms ............... 23 Setting Time and Day ..........24 Quick Function Keys ...........

  • Page 5: Introduction

    1.0 Introduction Thank you for selecting the Esprit+ Security System from Paradox Security Systems. The Esprit+ line of security systems brings together reliable, yet simple products that offer state of the art security options. These options enable you to customize many of the advanced features through a straightforward keypad interface.
  • Page 6 = to indicate a tip. = to indicate a button on the keypad. 4 User Manual...

  • Page 7: Basic Operation

    2.1 Keypad Indicator Lights The state of each light on the Esprit+ 642 keypad represents a specific condition in your system as shown in Figure 2.1. Figure 2.1: Keypad Indicator Lights...

  • Page 8: Auditory Feedback

    While the display will automatically show which zones are open, you can also press the [ ] or [ ] keys to view a specific zone. Figure 2.2: Overview of Esprit+ 642 LCD Keypad The messages on the LCD screen display system status and guide you through operations.

  • Page 9: Info List

    How do I View the Info List? 1) Press the key. INFO 2) Use the [ ] or [ ] keys to scroll through the info list. 3) Press the key to exit. CLEAR Esprit+ 642 LCD Keypad 7...

  • Page 10: Access Codes

    3.0 Access Codes Access codes are personal identification numbers that allow you to enter certain programming modes and arm or disarm the system. In addition to the Master Code the Esprit+ control panel can be programmed to accept up to 48 user codes, each with a unique access code.

  • Page 11: Programming Access Codes

    5) Return to step 3 to include additional entries or press to exit. CLEAR The display will read: none to indicate that an access code is available (does not contain information). Esprit+ 642 LCD Keypad 9...

  • Page 12: Deleting An Access Code

    3.4 Deleting an Access Code How Do I Delete an Access Code? 1) Press the key. The display will briefly read: ENTER enter code to programming mode. 2) Enter the in order to MASTER CODE USER CODE delete access codes. The display will read: programming mode section.

  • Page 13: Arming & Disarming

    When the system is armed, any security breaches will be recorded and stored in memory. This record contains all alarm situations that occurred within the last arming period. Should there be an alarm recorded the display will read: zone(s) memory [mem] to view. Esprit+ 642 LCD Keypad 11...

  • Page 14: Regular System Arming

    How Do I View the Memory Record? 1) Press the key to view the list of zones that were breached during the last arming period. The system will display the zone(s) that were activated. 2) Use the [ ] or [ ] keys to scroll through the record. 3) Press the key to exit.

  • Page 15: Stay Arming

    STAY code to stay arm system. 2) Enter your [ ]. The display will read: ACCESS CODE system in exit. The light will flash followed by a confirmation beep. The display will read: stay armed. Esprit+ 642 LCD Keypad 13...

  • Page 16: Fast Exit

    4.6 Fast Exit This feature allows you to leave a perimeter that is already armed in Stay mode and have the system rearm itself. You can set the system to rearm itself into one of two modes: Stay mode or Regular mode. The system will arm after the exit delay has expired.

  • Page 17: Force Arming

    2) Enter your [ ]. The display will read: ACCESS CODE system in exit. The light will flash indicating the exit delay. After the exit delay the display will read: full armed. Esprit+ 642 LCD Keypad 15...

  • Page 18: Manual Bypass Arming

    4.9 Manual Bypass Arming This feature allows you to deactivate (ignore) specified zones the next time you arm the system. Once armed and then disarmed, the zones are no longer bypassed. For example you may wish to bypass certain zones when workers are renovating part of your establishment.

  • Page 19: One-Touch Arming

    With the light on: Press and hold the key. The keypad will emit a confirmation beep and display: system in exit. The light will flash followed by a confirmation beep. The display will read: full armed. Esprit+ 642 LCD Keypad 17...

  • Page 20: Keyswitch/Push-Button Arming

    4.11.2 One-Touch Stay Arming Refer to “Stay Arming” on page 13 for a full explanation of this feature. How Do I Stay Arm? Press and hold the key. This will automatically Stay STAY arm the system. After the exit delay, the display will read: stay armed.

  • Page 21: No Movement Automatic Arming

    For example, you can use this feature when supervising the elderly, individuals with chronic health problems or a person living alone. 4.15 Fire Alarms In the event of a fire alarm, the bell/siren will operate in pulse Esprit+ 642 LCD Keypad 19...
  • Page 22 mode. To silence/reset a fire alarm, enter a valid access code. In case of fire follow your evacuation plan. If there is no fire condition, contact your monitoring company to avoid an unnecessary response. 4.15.1 Fire Safety in the Home Reasonable fire safety can be achieved following a three point program: 1) Minimizing fire hazards.
  • Page 23 In special circumstances where the life and safety of certain occupant(s) depends upon prompt rescue by others, the fire system provides a means of prompt, automatic notification to those who are depended upon for the rescue. Esprit+ 642 LCD Keypad 21...

  • Page 24: Additional Features

    5.0 Additional Features Several keypad features can be programmed directly by you, without the help of an installer. 5.1 Chime Zone Selection A Chime Zone advises you when a specific zone is opened by emitting a rapid intermittent beep tone. How Do I Chime a Zone? 1) Press and hold the key.

  • Page 25: Panic Alarms

    The panic zones can also communicate specific messages to your monitoring station. For example, you could press the panic sequence to call the police or the fire department. Ask your installer for the exact definition of your system’s panic alarms. Esprit+ 642 LCD Keypad 23...

  • Page 26: Setting Time And Day

    How Do I Use Panic Alarms? Press and hold both the keys to generate a panic signal. The display will read: alarm. Press and hold both the keys to generate a medical alarm signal. The display will read: alarm. Press and hold both the keys keys to generate a fire alarm signal.

  • Page 27: Quick Function Keys

    ENTER CLEAR Table 1 Call PC via Telephone. The display will read: TRBL call to PC. This will initiate communication to the central monitoring station computer. Your installer will indicate when this must be used. Esprit+ 642 LCD Keypad 25...

  • Page 28: Keypad Settings

    Answer PC. The display will read: answer PC. FORCE This will initiate modem communication between your system and a central monitoring station. Your installer will indicate when this must be used. Hang Up. This will cancel modem communication STAY between your system and the central monitoring station computer.

  • Page 29: Event List

    3) Use the [ ] or [ ] keys to scroll through the event list. 4) Press the key to exit. CLEAR Each event generates two event screens (see Figure 5.1). Once you enter the event list, the time and the day the event Esprit+ 642 LCD Keypad 27...

  • Page 30: Partitioning The System

    occurred and what event occurred will scroll on the screen. As you press the [ ] key, the next pair will scroll onto the screen. Figure 5.1: Example of Event Screens 5.8 Partitioning the System Depending on your needs, your installer can program your panel to recognize and control two separate areas (System A and System B) by activating the system’s partitioning feature.
  • Page 31 ACCESS CODE and the exit timer will begin to countdown. The display will read: A+B Armed. 5.8.3 Arming System A and B Separately If your Access Code has access to System A: Esprit+ 642 LCD Keypad 29...

  • Page 32: Disarming System A And B Separately

    How Do I Arm System A? 1) Press the key. STAY 2) Enter your [ . The will flash and the exit ACCESS CODE timer will begin to countdown. The display will read: system in exit. After the exit delay the display will read: a Armed.

  • Page 33: Testing & Maintenance

    2) Press the key. FORCE 3) Enter a valid [ ACCESS CODE 5.10 Testing & Maintenance We recommend that you test your system once a week. Contact your monitoring station before and after testing. Esprit+ 642 LCD Keypad 31...
  • Page 34 How Do I Test the System? With the system disarmed and the light on: 1) Walk in protected areas to activate motion detectors. The display should read: zone open. 2) Open and close protected doors and windows. The display should read: zone open. Your installer can advise you of the best way to test your particular system.

  • Page 35: Trouble Display

    If the battery is not connected to the panel, the display will read: trouble 01 battery failure. The battery connected to the panel should be replaced, because it can no longer provide adequate backup current in the event of a power failure. Esprit+ 642 LCD Keypad 33...
  • Page 36 Power Failure If AC power is not being supplied to the control panel and/or the power supply is unable to charge the battery. The LCD display will read: trouble 02 AC failure. Bell Disconnect If a bell/siren is not connected to the bell/siren output, trouble 04 BELL disconnect appears in the display.

  • Page 37: System Check List

    Silent Audible Not Used Fire or___________________________ Silent Audible Not Used 7.2 Zone Checklist Is this a partitioned system? Yes System A =____________System B = _______________ Zone # and System Zone # and System Description Description Esprit+ 642 LCD Keypad 35...
  • Page 38 Zone # and System Zone # and System Description Description Entry Delay 1 is ________seconds. Entry Delay 2 is ________seconds. Exit Delay is ___________seconds. 36 User Manual...

  • Page 39: User Access Code List

    7.3 User Access Code List User Name System User Name System Esprit+ 642 LCD Keypad 37...
  • Page 40 User Name System User Name System For security reasons, write only user names, and not actual access codes. Other information This alarm system was installed on:____________By:______________. Service is provided by _____________Tel#:_____________. Your monitoring station’s number is:_______________. Your account number is_____________. Your alarm transformer location is_____________and is on circuit#____________.
  • Page 41 All rights reserved. © 2002-2003 Paradox Security Systems. Specifications may change without prior notice. Esprit is a trademark or registered trademark of Paradox Security Systems Ltd. or its affiliates in Canada, the United States and/or other countries. Esprit+ 642 LCD Keypad 39...
  • Page 42 Notes __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ ____________________________________________...
  • Page 44 780 Industriel Blvd., Saint-Eustache (Quebec) J7R 5V3 Canada Tel.: (450) 491-7444 Fax: (450) 491-2313 www.paradox.ca PRINTED IN CANADA 01/2004 642-EU01...
