Page 1: Rear Seat Entertainment
User’s Manual Rear Seat Entertainment TMX-R1100E Please read before using the equipment. www.alpine-asia.com Designed by Alpine Electronics of Asia Pacific Co., Ltd. Printed in China... -
Page 2: Table Of Contents
Contents TV TUNER (ANALOG) WARNING SYSTEM CONTROL Warning............ 3 Cautions............ 3 Saving to Channel memory......13 Cautions on Usage........ 4 Preset Channel Selection....... 13 TV/DVD TELEVISION BASIC OPERATION TUNER SYSTEM CONTROL Specification..........5 Overhead Monitor........5 DTV (Digital Television) Tuner System Control....Remote Control.......... -
Page 3: Warning
WARNING Warning • Please read this manual carefully for correct usage In case of error, such as no sound or picture, alien object inside, smoked or and keep it for later use when needed. The company strange smell, stop using the product shall not be responsible for any damages from misuse Prohibit immediately and contact your dealer. -
Page 4: Cautions On Usage
Do not mix new batteries with old batteries. Insert with the correct battery polarity. When inserting the batteries, be sure to observe proper polarity (+ and -) as instructed. Rupture and chemical leakage from the battery may cause fire or personal injury. Specific knowledge and experience are needed for installation and wiring. -
Page 5: Basic Operation
Specification optional. • Monitor will memorize the status when turn Structure of Alpine TMX (Monitor) ignition to OFF and will resume the previous • 10.2 Inch Active Matrix TFT Wide VGA status when turn ignition to ON. <It will be Color Liquid Crystal Display (800x480 dpi). -
Page 6: Turning Power On/Off
BASIC OPERATION Sound Volume Adjustment. Turning Power ON/OFF Sound Volume can be adjusted through optional IR Headphone or Radio Head Unit. Sensor Touch Control 1. Touch the POWER to turn on the system. 1. Turn on the POWER of the optional IR Head- 2. -
Page 7: Picture Adjustment
BASIC OPERATION Adjusting Color Density. Picture Adjustment 2. Press on the Remote Control or Brightness, color, tint, contrast and sharpness are on the Sensor Touch Control to select [Color] adjustable. 3. Press or touch to adjust the Color Density. • Each source is independently adjustable. Color can be adjusted between the range of •... -
Page 8: Adjusting The Sharpness
BASIC OPERATION Adjusting the Sharpness. 2. Press on the Remote Control or on the Sensor Touch Control to select [SHARPNESS] 3. Press or touch / to adjust the SHARPNESS. SHARPNESS can be adjusted between the range Remote Control Unit of -15(SOFT) to +15(HARD). 1. -
Page 9: Visual Eq Operation
BASIC OPERATION : Normal Setting (Visual EQ OFF) FLAT : Suitable for movies in which dark NIGHT MOVIE scenes frequently appear. : Suitable for CGs and animated SOFT NORMAL films. Normal image (4:3) : Suitable for rold movies where SHARP images are not clearly shown. - Page 10 BASIC OPERATION Customization of Source Name. 1. Press SEL (SELECT) of the Remote Control for You can define the source name for your favorite at least 2 seconds or touch at Sensor Touch OSD (On Screen Display) for 6 letters. Control for at least 2 seconds to display SETUP MENU.
-
Page 11: Dvd Player System Control
• Please see System Setup Operation at page 9. Press of the Remote Control or touch at • See User’s Manual of your Alpine DVD Player of Sensor Touch Control to stop the DISC. Press / DVD Changer / DVD Head Unit for more once and PRE-STOP will be shown on the screen. -
Page 12: Menu Selection
/ ENT to operate. DVD SETUP OPERATION The following is the method to change setting of Alpine DVD Player. • See Alpine DVD Player / DVD Changer / DVD Head Unit User’s Manual for further details. Remote Control Press from mode for at least 2 seconds. -
Page 13: Tv Tuner (Analog) System Control
Setup Source Name as TV from SYSTEM SETUP to operation optional Alpine TV Tuner. • Please see System Setup Operation at page 9. • See User’s Manual of your Alpine TV Tuner for more details Sensor Touch Control TV TUNER... -
Page 14: Tuner System Control
• Please see System Setup Operation at page 9. CH , : Press (touch) to move up 1 channel • See User’s Manual of your Alpine TV Tuner from the preset. for more details CH , : Press (touch) to move down 1 channel from the preset. -
Page 15: Installation And Connections
INSTALLATION AND CONNECTIONS INSTALLATION AND Specifications CONNECTIONS Picture System PAL/NTSC Display Screen 10.2 Inch Screen Size: Checking Components. 221 mm Width: 132 mm Height: 10.2 Inch WVGA RUE-4155J Universal 16:9 Aspect Ratio: LCD Monitor Remote Control Clear TN LCD LCD: TFT Active Matrix Driving Method: 800 (w) x 480 (h) x 3... -
Page 16: Installation By Bracket, Trim Ring
INSTALLATION AND CONNECTIONS CUTTING TRIM RING. INSTALLATION BY BRACKET, Use TRIM RING to fill the gap when there is a gap between Roof Panel and Monitor. TRIM RING (*1,2) *No need to use TRIM RING if there is no gap. *Cutting POSITION and SHAPE differ from Caution Specific knowledge and experience vehicle, please carefully check before cutting. -
Page 17: Room Lamp Installation
INSTALLATION AND CONNECTIONS Door Switch (+) ROOM LAMP INSTALLATION When door open. the wire provide 12V. VEHICLE VEHICLE DOOR SW ROOM LAMP WIRING (RED) (GREEN) WIRE of ROOM LAMP. DOOR (BLACK) Connect the cable from ROOM LAMP switch of the vehicle to the MONITOR internal ROOM LAMP. -
Page 18: Connecting Diagram
INSTALLATION AND CONNECTIONS Connecting Diagram The below power sources are necessary for Alpine TMX-R1100E to operate properly. TMX-R1100E ACC Power Line. Connect this line to ACC Power Line of (RED) the vehicle. (Switching 12V, Ignition) DIN CABLE Ground Line. Align the arrow when... -
Page 19: System Connection Sample
SYSTEM CONNECTION SAMPLE • Connection with OEM Navigation and Other Brand Navigation, DVE-5207 Navigation Unit TMX-R1100E • ACC POWER LINE • GND LINE BLACK • REMOTE WHITE OUT 2 Not connect with this connection. YELLOW YELLOW YELLOW YELLOW • PIN CONNECT... -
Page 20: Other
OTHER Troubleshooting Are you misunders- Are installation and If the problem is still Please check the tanding, miss-usage wiring correctly exists,please contact your list below again. as system malfunction? completed? nearest dealer. • If you encounter a problem such as sudden system shut down or the screen becomes dimmed, please turn the power off, then on again. -
Page 21: Remote Control Battery Replacement
OTHER Remote Control Battery Replacement Battery type: CR2025 or equivalent. 1. Opening the battery case. Pull up the battery cover while pressing in the direction of the arrow. 2. Replacing the battery. Put the battery in the case with the (+) indication upward as shown in the illustration.
