Side Panel; Front Panel - BeachTek DXA-SLR PURE Operating Manual

10

Side Panel

L and R Inputs
10
Accepts balanced XLR or ¼" unbalanced mono phone jacks
OUT
11
Output jack for connection to the camera
MONITOR IN
12
Input jacks for connecting the AV cable to the camera

Front Panel

9
Side Panel
7
8
10
12
11
3
6
4
4
2
5
1
