This chapter describes how to unpack and assemble your 800S Stepper, how to network two
to eight steppers if you want to be able to use the group race feature, and how to use setup
mode to configure the stepper for your situation.

Assembly Overview

It's easy to assemble the 800S Stepper-it will probably take about 30 minutes. You need
these common tools:
• 3/16" Allen Wrench
• 7/16" Wrench or socket wrench and ratchet
• 1/2" Wrench
Here's an overview of the steps in the assembly:
1. Unpack your 800S Stepper and make sure you have all the parts.
2. Follow the detailed instruction for your stepper.
3. Plug in the power cord.
4. If you have more than one Stepper, connect the communications ports to allow
group racing.

800S Stepper Assembly

Use the 7/16" or 1/2" socket or wrench to remove the clamps and screws or tie straps hold-
ing the chassis base to the pallet. Remove all the other parts from the shipping carton. Make
sure you have all the parts by checking against the parts list.
CAUTION: Do not stand the display console upright tube on its end! Lay it flat instead.
Standing it on end could damage the display ribbon cable.
Parts Lists for the 800S Stepper
Parts that come with your 800S Stepper are shown in Figure 1 and include:
Description
Base Unit
Display Upright Assembly
Handrail Assembly (CT)
Handrail Assembly (non CT)
Collar Cover
Configuration Kit
Hardware Kit for 800S Stepper
Termination Plug*
*: The termination plug is already inserted in one of the communications sockets on the base
of the 800S Stepper.
Chapter 2 - Assembly and Setup
Qty Part Number
1 70367
1 62007
1 62029
1 62046
1 30616W, 36016b & 36016G2
1 varies by country
1 71100
1 61026
Page 2-1
Figure 1 Item #
1
2
3
3
4
5
6
n/a
