5000 peak watts / 4600 running watts portable generator

Advertisement

71307
Rev 71307-
20100513
www.championpowerequipment.com
10006 Santa Fe Springs Road
Santa Fe Springs, CA 90670 USA
Made in China
Owner's Manual and Operating Instructions
SAVE THESE INSTRUCTIONS
Important Safety
Instructions are included in
this manual
5000 Peak Watts / 4600 Running Watts
PORTABLE GENERATOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 71307 and is the answer not in the manual?

Questions and answers

Summary of Contents for Champion Power Equipment 71307

  • Page 1 71307 Rev 71307- 20100513 www.championpowerequipment.com 10006 Santa Fe Springs Road Santa Fe Springs, CA 90670 USA Made in China Owner’s Manual and Operating Instructions SAVE THESE INSTRUCTIONS Important Safety Instructions are included in this manual 5000 Peak Watts / 4600 Running Watts...
  • Page 3: Table Of Contents

    Table of Contents Introduction ........1 Storage ........... 16     Portable Power Generator ......1 Engine Storage ........16     Accessories ..........1 Generator Storage ........16     This Booklet ..........1 Specifications ......... 17     Manual Conventions ......
  • Page 5: Introduction

    Champion Power Equipment manufactures Congratulations on your purchase of a and sells accessories designed to help you Champion Power Equipment generator. CPE get the most from your purchase. To find out designs and builds generators to strict more about our covers, power cables and specifications.
  • Page 6: Manual Conventions

    NOTE If you have questions regarding your generator, WARNING we can help. Please call our help line at 1-877- 338-0999. WARNING indicates a potentially hazardous could situation which, if not avoided, result in death or serious injury. Rev 71307-20100513 E...
  • Page 7: Safety Rules

    Maintain at least three feet of clearance on all sides to ensure adequate cooling. DANGER Maintain at least five feet of clearance from combustible materials. Rotating parts can entangle hands, feet, hair, clothing and/or accessories. Traumatic amputation or severe laceration can result. Rev 71307-20100513 E...
  • Page 8: Before Starting The Generator

    Broken bones, fractures, bruises or sprains could result. When starting engine, pull the starter cord slowly until resistance is felt and then pull rapidly to avoid kickback. DO NOT start or stop the engine with electrical devices plugged in. Rev 71307-20100513 E...
  • Page 9: Controls And Features

    (8) Oil Filler Cap – Check and fill engine (4) Recoil Starter – Used to start the oil level. engine (9) Battery – Used to start the engine. (5) Gas Hose and Regulator (10) Power Panel – See “Power Panel” Rev 71307-20100513 E...
  • Page 10: Power Panel

    2300 Watts of 60 Hz loads requiring up to 20 A 0r 2300 power. Protected by a 20 A flip-to-reset Watts of power. circuit breaker (8) Ground Terminal – Consult an electrician for local grounding regulations. Rev 71307-20100513 E...
  • Page 11: Parts Included

    Controls and Features Parts Included Your Model 71307 Gas (LPG) Powered Generator ships with the following parts: Wheel Kit Axle 1 piece 10” Solid Wheel 2 pieces Support Leg 1 piece Vibration Mounts 2 pieces Bolt Kit Wheel Retaining Pins...
  • Page 12: Assembly

    3. Slide a wheel onto the axel. 4. Place a washer on the end. 5. Install the cotter pin through the hole on the end of the axle. 6. Carefully bend the legs of the cotter pin back around the axle. Rev 71307-20100513 E...
  • Page 13: Install The Spark Arrester

    Place the generator on a flat, level surface. 2. Remove oil fill cap/dipstick to add oil. 3. Add 1.16 qt (1.1 L) of oil and replace oil fill cap/dipstick. See “Specifications” for Rev 71307-20100513 E...
  • Page 14: Connect Lpg Cylinder

    Regulators to be used on the cylinders must be of the diameter as the cylinder valve. Regulators should always be in the off position when the cylinder is not in use. Rev 71307-20100513 E...
  • Page 15: Operation

    2. Obtain an Uninterruptible Power Supply (UPS) device. Most UPS devices come with a rechargeable battery between the electronic equipment and power supply source. The device buffers the voltage and protects against virtually all short- duration voltage fluctuations. Rev 71307-20100513 E...
  • Page 16: Stopping The Engine

    2. Surge wattage is the extra burst of power needed to start some electric driven equipment. Following the steps listed under “Power Management” will guarantee that only one device will be starting at a time. Rev 71307-20100513 E...
  • Page 17: Wattage Reference Chart

    Belt Sander 3" 1000 1500 Bench Grinder 6" 1500 Circular Saw 1500 1500 Compressor 1 1/2 HP 2500 2500 Edge Trimmer Hand Drill 1/2" 1000 1000 Lawn Mower 1200 1800 Paint Sprayer 1200 Table Saw 2000 2000 Rev 71307-20100513 E...
  • Page 18: Maintenance

    Remove the oil drain plug with a 15 mm socket and extension. 2. Allow the oil to drain completely. 3. Replace the drain plug. 4. Remove oil fill cap/dipstick to add oil. 5. Add 1.16 qt (1.1 L) of oil and replace oil fill cap/dipstick. Rev 71307-20100513 E...
  • Page 19: Spark Arrester

    Contact our help line at 1-877-338-0999 to Inspect all air vents and cooling slots to locate the nearest Champion Power ensure that they are clean and unobstructed. Equipment certified service dealer for your generator or engine maintenance needs. Rev 71307-20100513 E...
  • Page 20: Storage

    4. Store the unit in a clean, dry area. 2. Clean the engine according to the 5. Store in a clean, dry place out of direct instructions in the Maintenance section. sunlight. 3. Change the oil. Rev 71307-20100513 E...
  • Page 21: Specifications

    Exhaust: 0.11 - 0.13 mm (.004 - .005 in.) Use only an approved LPG cylinder equipped with an OPD valve. Flow rate: ≥2.0 kg/hr Outlet pressure: 2.8 kpa ± 0.5 kpa Oil capacity is 1.16 qt (1.1 L). Rev 71307-20100513 E...
  • Page 22: Parts Diagram

    Specifications Parts Diagram Rev 71307-20100513 E...
  • Page 23: Parts List

    Spring washer φ8 GB5789 M8×35 Flange Bolt M8×35 ST05FD-1151400-1 Bottom rubber 2 ST05FD-1151300-1 Bottom rubber 1 GB6177 M8 Nut M8 Axle ( 27.8 in) GB6177 M10 Nut M10 ST05FD-0127-4 Frame CG500-021700 LPG Switch CG500-000007 Clip CG500-020203 Rubber Tube Rev 71307-20100513 E...
  • Page 24 Muffler inter protector ST02FD-02100008 Brush assembly cover board ST182FD-1742203-UC Handle sheath ST182FD-1742201-UC Handle ST182FD-1742202-UC Handle underlay GB896 8 Uncork baffle φ8 GB896 6 Uncork baffle φ6 ST05FD-03160004 ST02FD-1152010-5 Earth line GB5789 M8X25 Flange Bolt M8×25 ST188FD-1743002-C Vibration mount Rev 71307-20100513 E...
  • Page 25 Flange Bolt M8×50 CG500-040700 Fan cover CG500-600100A1 Gas hose and Regulator GB818 M3×6 Screw M3x6 GB859 3 Spring Washer3 GB5783 M6×22 Bolt M6×22 GB97.1 6 Washerφ6 GB93 6 Spring Washerφ6 GB6175 M6 Nut M6 GB5789 M8×20 Flange Bolt M8×20 Rev 71307-20100513 E...
  • Page 26: Wiring Diagram

    Specifications Wiring Diagram Rev 71307-20100513 E...
  • Page 27: Troubleshooting

    Contact the help line. Generator gallops Engine governor defective Contact the help line Repeated circuit breaker tripping Overload Review load and adjust. See “Power Management” Faulty cords or device Check for damaged, bare or frayed wires. Replace defective device Rev 71307-20100513 E...
  • Page 28: Warranty

    Wear items such as filter elements, o-rings, etc. Accessory parts such as starting batteries, and Warranty Qualifications storage covers. Champion Power Equipment (CPE) will register Failures due to acts of God and other force this warranty upon receipt of your Warranty majeure events beyond the manufacturer’s Registration Card and a copy of your sales receipt control.
  • Page 29 The California Air Resources Board (CARB) and the United States Environment Protection Agency (U.S. EPA.) Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with both the U.S. EPA and state of California Air Resources Board (CARB) emission regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: The California Air Resources Board, US EPA AND CPE are pleased to explain the Federal and California Emission Control Systems Warranty on your 2010 small off-road engine.
  • Page 30 ECS Warranty maintenance or repair and will be provided without charge to the owner. Such use shall not reduce CPE’s warranty obligation. i. Unapproved add-on or modified parts may not be used to modify or repair a CPE Rev 71307-20100513 E...
  • Page 31 Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc. to sell and service that CPE product during his normal business hours. Claims for repair or adjustment found to be caused solely by defects in material or workmanship will not be denied because the engine was not properly maintained and used.
