The Add Printer Screen

Other Network Printer
Settings
TDS3000C Series Oscilloscope User Manual
The next figure shows the Add Printer screen. The text that follows describes the
screen menu items and controls for entering printer configuration settings.
Add Printer Control
General purpose knob
Enter Character
← and →
Back Space
Delete
Clear
↑ and ↓
OK Accept
Menu Off
To verify that your oscilloscope is set to print to a network printer, follow these
steps:
1. Select a network printer in the Ethernet printer list. You select a printer by
using the general purpose knob to highlight a printer name in the list.
2. Push the Menu Off button to exit from the System I/O menus.
Appendix F: Ethernet Setup
Description
Selects (highlights) an alphanumeric character in the list.
Adds the selected alphanumeric character to the current
printer setting field. You can also use the front panel
Select button. The list of available characters changes
depending on which field is selected.
Moves the cursor left or right in the current field.
Erases the character to the left of the cursor.
Erases the character at the cursor position.
Clears (erases) the current field.
Selects a field to edit.
Closes the Add Printer screen and applies the printer
settings. You can use the new printer immediately.
Closes the Add Printer screen and returns you to the
previous screen without applying changes.
