Owner's Manual and Instructions
Agricultural Animal Confinement Building Heaters
GUARDIAN
®
Congratulations!
You have purchased the finest agricultural building heater available.
Your new L.B. White heater incorporates the benefits from the most experienced
manufacturer of heating products using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products and
welcome any suggestions or comments you may have...call us, toll-free,
at 1-800-345-7200.
ATTENTION ALL USERS
This heater has been tested and evaluated by C.S.A. International in accordance with
ANSI/IAS U.S. LC2-1996 as well as the Canadian Gas Association Standard for Gas
Fired Brooders, CAN1-2.20-M85 and is listed and approved as a direct gas-fired
circulating heater for the heating of agricultural animal confinement buildings. If you
are considering using this product for any application other than its intended use,
then please contact your fuel gas supplier, or the L.B. White Co., Inc.
MODELS
OUTPUT (Btuh)
AW250
250,000
FUEL
All Models are
available in either
L.P. Gas Vapor
Withdrawal or
Natural Gas
Configurations.
Certification by:
150-24161
