Page 1: User Manual
Kramer Electronics, Ltd. USER MANUAL Rack Adapter Models: RK-2WP RK-22WP RK-121WP RK-WP16... -
Page 2: Table Of Contents
Contents Introduction Getting Started Overview Recommendations for Best Performance Your Rack Adapters Installing Your Kramer Rack Adapters Installing Wall Plates on the RK-121WP Installing Inserts on the RK-WP16 Technical Specifications Figures Figure 1: Installing the RK-121WP Rack Adapter Figure 2: Mounting the RK-WP16 Rack Adapter... -
Page 3: Introduction
Review the contents of this user manual Overview You can mount a combination of Kramer 1 Gang and 2 Gang European wall plates, or wall plate inserts in a 19" 2U rack. 3.1 Recommendations for Best Performance... -
Page 4: Your Rack Adapters
Single wall plate Inserts (10 supplied) 2732-503112 RK-WP16 Installing Your Kramer Rack Adapters This section describes how to install the: RK-121WP , see section 5.1 RK-WP16, see section 5.2 1 The RK-2WP and the RK-22WP are mounted in a similar way KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Installing Wall Plates On The Rk-121Wp
Installing Your Kramer Rack Adapters 5.1 Installing Wall Plates on the RK-121WP The example in Figure 1 shows how to mount wall plates in the 19” 2U RK-121WP rack adapter, including the optional insertion of blank plates. Use the M3x10 flat-head screws (supplied with the unit) to install the required wall plates on the rack adapter. -
Page 6: Installing Inserts On The Rk-Wp16
Installing Your Kramer Rack Adapters 5.2 Installing Inserts on the RK-WP16 The example in Figure 2 shows how to mount single and double inserts in the 19” 2U RK-WP16 rack adapter, including optional insertion of blank inserts. Use the M3x8 screws (supplied with the unit) to install the required inserts on the rack adapter. -
Page 7: Technical Specifications
Table 3 includes the technical specifications: Table 3: Technical Specifications of the Rack Adapters DIMENSIONS: RK-2WP, RK-22WP, RK-121WP: 19-inch (W), 0.39-inch (D) 2U (H) RK-WP16: 19-inch (W), 0.49-inch (D) 2U (H) WEIGHT: RK-2WP, RK-22WP, RK-121WP: 0.6kg (1.32lbs) approx. RK-WP16: 0.5kg (1.1lbs) approx. - Page 8 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 9 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
