- Page 1 Socket 462 Socket 462 Motherboard Motherboard IN730SE/IN730S IN730SE/IN730S User’s Manual...
-
Page 2: Declaration
Declaration Rights: No part of this manual, including but not limited to the products and software described in it, may be reproduced, transmitted, transcribes, stored in a retrieval system, or translated in any form or by any means without the expressed written permission of the manufacture. -
Page 3: Compliance & Certificate
Compliance & Certificate Compliance & Certificate & & & & ISO 9002 Certificate: ISO 9002 Certificate: This device was produced in our plant with advanced quality system certified by DNV QA Ltd. in according to ISO 9002. This Certificate is valid for: DESIGN &... -
Page 4: Easy Installation
Easy Installation Easy Installation Easy Installation Steps Easy Installation Steps The following “Easy Installation” steps are for users accustomed to the assembly of a computer system. For those individuals requiring more specific information, please refer to the more detailed descriptions located within the latter chapters of this manual. - Page 5 Easy Installation Easy Installation AMD Athlon™ / Duron™ Processor Family As processor technology pushes to faster speeds and higher performance, thermal management becomes increasingly crucial when building computer systems. Maintaining the proper thermal environment is key to reliable, long-term system operation. The overall goal in providing the proper thermal environment is keeping the processor below its specified maximum case temperature.
-
Page 6: Table Of Contents
Contents Contents Declaration ......................2 Compliance & Certificate ................... 3 Easy Installation....................4 Items Introduction....................9 1.1 How To Use This Manual ................9 1.2 Check Your Device Items................9 2. Features ......................10 2.1 Features Of The Motherboard ..............10 3. Installation.....................12 3.1 Motherboard Layout &... - Page 7 Contents Contents 4.3.6 Halt on ....................41 4.3.7 Memory....................41 4.4 Advanced BIOS Features Menu ..............42 4.4.1 Virus Warning ..................43 4.4.2 CPU L1 Cache ..................43 4.4.3 CPU L2 Cache ..................43 4.4.4 Processor Number Feature ..............43 4.4.5 First Boot Device..................43 4.4.6 Second Boot Device................43 4.4.7 Third Boot Device.................43 4.4.8 Other Boot Device................44 This option sets the type of device for the third boot drives that the BIOS attempts to...
- Page 8 Contents Contents 4.6.10 ECP Mode Use DMA................48 4.7 Power Management Setup Menu ...............49 4.7.1 ACPI function ..................49 4.7.2 Video Off Option ..................49 4.7.3 Video Off Method .................50 4.7.4 MODEM Use IRQ.................50 4.7.5 Power Button Function .................50 4.7.6 PM Wake Up Events ................50 Ring Power Up Control .................50 PCIPME Power Up Control ................50 KB Power On Password ................50...
-
Page 9: Items Introduction
The standard package should contain the following items. If you find any of these items be missing or damaged, please contact your retailer. Ø 1 IN730SE/IN730S motherboard Ø 1 CD with drivers for IN730SE/IN730S motherboard CHECK ITEMS Ø 1 Quick-Start guide Ø... -
Page 10: Features
Features Features 2.1 Features Of The Motherboard 2.1 Features Of The Motherboard This product is based on the “ ATX” form factor. It features the advanced Multimedia function and provides support for business PC maker. This motherboard incorporates Intel 82440BX AGP/PCI/ISA chipset and Promise Raid IDE Bus Controller. - Page 11 Features Features 1 Parallel Port (ECP, EPP) 1 Serial Ports and 1 Serial connector (16C550 Fast UART Compatible) 1 PS/2 Keyboard connector 1 PS/2 Mouse connector 2 Standard USB Ports (48MHz) Supports up to 127 USB Devices hardware monitor W83782D Onboard Fan power connectors (has speed monitoring) Ø...
-
Page 12: Installation
Installation 3.1 Motherboard Layout & Main Parts... -
Page 13: Connectors List
Installation Connectors List Front Panel Connectors Reset Refer to Sec. 3.6.5 HDD LED Refer to Sec. 3.6.5 Power Switch Refer to Sec. 3.6.5 Power LED Refer to Sec. 3.6.5 Speaker Refer to Sec. 3.6.5 Back Panel Connectors PS/2-style keyboard and mouse connectors Refer to Sec. -
Page 14: Precaution Before Start
Installation Precaution Before Start Static Electricity Damage: Static electricity can easily damage your motherboard. Observing a few basic precautions can help safeguard against damage that could result in expensive repairs. Follow the simple measures below to protect your equipment from static electricity damage. -
Page 15: Slots And Connectors
Installation 3.2 Slots And Connectors This motherboard requires jumper setting for some features. The following graphic shows you how to set a proper jumper setting. PIN 1 PIN 1 Note: In the following pages, the triangle s mark stands for pin 1 of connectors. 3.3 CPU (Central Processing Unit) This motherboard supports a PGA 462 Slot A AMD Athlon/ Duron PGA processor. -
Page 16: Install Cpu
Installation 3.3.1 Install CPU Please follow the below steps to install your CPU, and configure the types and speed in accordingly to the Processor Jumper Setting List. Step 1: Pull the handling bar of the socket upward to the other end to loosen the socket’s openings. -
Page 17: System Memory (Dram)
Installation 3.4 System Memory (DRAM) 3.4.1 DIMM (Dual Inline Memory Module) The motherboard features four 168-pin DIMM sockets, share memory module. If you have only one DIMM RAM, note that you must insert it into DIMM 1. You can configure the system memory size from 8MB to 512MB in a variety of ways by using different combinations of the two 168-pin DIMM. -
Page 18: Installation Procedure
Installation 3.4.2 Installation Procedure Step1: Make sure Pin 1 of the DIMM match with pin 1 of the DIMM socket. Step2: Insert the DIMM module into the DIMM socket vertically. After inserting the DIMM module completely into the socket, push up on the socket latches securing the DIMM into place. -
Page 19: Expansion Slot
Installation 3.5 Expansion Slot This motherboard contains 3 Bus Mastering PCI 32bit slot , and 1 ANR slot. -
Page 20: Connectors
Installation 3.6 Connectors This motherboard contains IDE, floppy, power input, front panel and additional connectors. S e c o n d a r y I D E S e c o n d a r y I D E P r i m a r y I D E P r i m a r y I D E 3.6.1 Primary IDE Connector (40-pin block, Red) This connector supports two primary channel IDE devices via a ribbon cable. -
Page 21: Floppy Drive Connector (34-Pin Block)
Installation 3.6.3 Floppy Drive Connector (34-pin block) The FDC sub-system can control three types of floppy drives (1.2, 1.44 and 2.88MB) or compatible tape drives. The connection to the floppy drive is via a header (J26). The floppy disk interface includes 48mA drivers and inputs on the drive interface. -
Page 22: Power Input Connector (20-Pin Block)
Installation 3.6.4 Power Input Connector (20-pin block) This connector supports one standard ATX power supply. When connecting, make sure the lock key matches the hook attached on a power supply cable. The power cord should be unplugged when you connect it. -
Page 23: Front Panel Connectors (20-Pin)
Installation 3.6.5 Front Panel connectors (20 3.6.5 Front Panel connectors (20- - pin) pin) Power Switch, Power LED, Reset, Sleep and HDD LED. KeyLock SPEAKER PWR LED RESET Turbo Turbo HDD LED Reset Switch Connector (2-pin) This connector supports the front panel case-mounted reset button. It is advised that the reset switch be used for rebooting the system in order to extend the life of the system’s power supply. -
Page 24: Back Panel Connectors
Installation “Instant-off”, then Power Switch function work as regular power switch. Power/Sleep LED (2-pin) This header can be connected to a 2-color LED that will light yellow or green when the computer is in “Suspend” or “Normal” operation. Speaker Connector (3-pin) It is used to drive a chassis-mounted speaker if desired. - Page 25 Installation Mouse USB2 Printer Port Keyboard USB1 COM1 Speaker Line-In Mic PS/2 Keyboard and Mouse Ports The motherboard offers 1 PS/2 Keyboard and 1 PS/2 Mouse port. Mouse Keyboard...
- Page 26 Installation Universal Serial Bus (USB) Ports The motherboard has two USB connectors. USB devices provide a more convenient operating environment and improve data transferring capacity. True Plug & Play. This new bus technology will support over 127 different peripherals through a Hub. USB1 USB2 Parallel Port (Printer) The motherboard includes a parallel port (EPP/ECP compatible).
- Page 27 Installation Serial/ Video Port (COM1, VGA) The motherboard has two serial ports (one on rear panel, one header on board). The electrical characteristics are compliant with the EIA-232-D Serial Communications Specifications. The serial ports may be remapped over other installable serial ports or disabled through the BIOS. COM1 This product integrates the AGP function via a VGA port beside the COM1.
- Page 28 Installation Audio Port (Line-in, Line-out, MIC-in) The motherboard also provides external sound system through a user accessible stereo jack connector soldered to the PWA.This jack allow the connection of self-amplified speakers, Line-in voice input and MIC-in voice input. Speaker Line-In Mic...
-
Page 29: Additional Connectors
Installation 3.6.7 Additional Connectors 3.6.7 Additional Connectors COM2 Headers (10-pin block): COM2 This board has another serial port COM2, it come with cable providing serial port COM2. Note: Orient the read marking on the Pin 1 COM2 ribbon cable to pin 1 COM2 USB Port Headers (10-pin block): USB1 These headers are used for connecting the additional USB port plug. - Page 30 Installation order to prolong the lift of the system’s power supply. See the figure below. Speaker connector: SPKR This 4-pin connector connects to the case-mounted speaker. See the figure below. Power LED: POWER LED The Power LED is light on while the system power is on. Connect the Power LED from the system case to this pin.
- Page 31 Installation NOTE: This feature requires that Wake On LAN or Ring In Wake up is enabled. W a k e -O n -L A N H e a d e r s FAN Speed Headers (3-pin): CPUFAN, SYSFAN These connectors support cooling fans of 350mA (4.2 Watts) or less, depending on the fan manufacturer, the wire and plug may be different.
- Page 32 Installation IR infrared module Headers (10-pin): IR This connector supports the optional wireless transmitting and receiving infrared module. You must configure the setting through the BIOS setup to use the IR function. C I R V C C IR: (Pin1 Pin5) for Standard IR C I R R X C IR: (Pin6 Pin10) for Consum er IR I R R X...
-
Page 33: Starting Up Your Computer
Installation Starting Up Your Computer After all connection are made, close your computer case cover. Be sure all the switch are off, and check that the power supply input voltage is set to proper position, usually in-put voltage is 220V 240V or 110V 120V depending on your country’s voltage used. - Page 34 Installation During power-on, press <Delete> key to enter BIOS setup. Follow the instructions in BIOS SETUP. Power off your computer: You must first exit or shut down your operating system before switch off the power switch. For ATX power supply, you can press ATX power switching after exiting or shutting down your operating system.
-
Page 35: Ready To Turn On Power
Installation Ready To Turn On Power Check Again Is the CPU installed exactly and firmly into the socket (Sec. 3.3)? Are all the DRAM modules installed properly (Sec. 3.4)? Did you insert the expansion card (VGA, Sound… etc.) already (Sec. 3.5)? Are you sure that all the connectors (described in Sec 3.6) have been connected to their variable devices (Sec. - Page 36 Installation If the power-on-self-test goes well, hold down <Del> button on the keyboard to enter BIOS Setup. Next, follow the instructions in the next chapter, BIOS SETUP.
-
Page 37: Bios Setup
BIOS SETUP The motherboard uses AWARD BIOS, stored in a flash EEPROM. All of the configuration information will be stored in the CMOS. 4.1 BIOS Setup The AWARD BIOS is immediately activated when you first turn on the computer. The BIOS reads system configuration information in CMOS RAM and begins the process of checking the system and configuring it through the Power-On-Self-Test (POST). -
Page 38: Main Setup Menu
BIOS SETUP 4.2 Main Setup Menu When you enter the Award BIOS CMOS Setup Utility, a Main Menu appears on the screen. The Main Menu allows you to select from several Setup functions and two exit choices. Use the arrow keys to select among the items and press <ENTER> key to enter the sub-menu. -
Page 39: Standard Cmos Features Menu
BIOS SETUP Load Optimized Defaults Setup defaults that are factory settings for optimal performance system operations. Set Supervisor Password Change, set, or disable a supervisor password. The supervisor password allows complete access. Set User Password Change, set, or disable an user password. The user password generally allows only power-on access. -
Page 40: Hard Disks
BIOS SETUP 13:00:00. Press the left or right arrow key to move to the desired field. Press the <PgUp> or <PgDn> key to increment the setting, or type the desired value into the field. 4.3.3 Hard Disks The BIOS supports up to four IDE drives. This section does not show information about other IDE devices, such as a CD-ROM drive, or about other hard drive types, such as SCSI drives. -
Page 41: Drive A/B And Floppy 3 Mode Support
BIOS SETUP 4.3.4 Drive A/B and Floppy 3 Mode Support Select the correct specifications for the diskette drive(s) installed in the computer. Floppy Mode 3 Support is for LS-120 disk drives if used. None No diskette drive installed. 360K, 5.25 in 5-1/4 inch AT-type standard drive;... -
Page 42: Advanced Bios Features Menu
BIOS SETUP Base Memory Typically 640 KB. Also called conventional memory. The DOS operating system and conventional applications use this area. Extended Memory Above the 1MB boundary. Early IBM personal computers could not use memory above 1 MB, but current PCs and their software can use extended memory. Total Memory System total memory is the sum of base memory, extended memory, and other memory. -
Page 43: Virus Warning
BIOS SETUP 4.4.1 Virus Warning When enabled, you receive a warning message if a program (specifically a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an anti-virus program. Keep in mind that this feature protects only the boot sector, not the entire hard drive. -
Page 44: Other Boot Device
BIOS SETUP 4.4.8 Other Boot Device This option sets the type of device for the third boot drives that the BIOS attempts to boot from after BIOS Post completes 4.4.9 Swap Floppy Drive Switch the floppy disk drives between beings designated A and B. Default is disabled. 4.4.10 Boot Up Floppy Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. -
Page 45: Os Select For Dram > 64Mb
BIOS SETUP 4.4.17 OS Select for DRAM > 64MB Select OS/2 only if you are running OS/2 operating system with greater than 64MB of RAM on your system. 4.4.18 Report No FDD For Windows Whether report no FDD for Win 95 or not. The settings are Yes or No 4.5 Advanced Chipset Features 4.5.1 DRAM Timing Settings Please refer to section DRAM Timing... -
Page 46: Pci Grant Parking On
BIOS SETUP 4.5.3 PCI Grant Parking On The settings are PME, PCI Master. 4.5.4 Memory Parity Check The function provides parity check of memory. The choice is either Disable or Enabled. 4.5.5 System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM F0000hh-FFFFFh, resulting is better system performance. -
Page 47: Integrated Peripherals
BIOS SETUP 4.6 Integrated Peripherals 4.6.1 On-Chip IDE The chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled to activate the primary IDE interface. Select Disabled to deactivate this interface. The choices are: Enabled, and Disabled. 4.6.2 OnChip Device Function The chipset contains a PCI IDE interface with support for two IDE channels. -
Page 48: Onboard Serial Port 1
BIOS SETUP 4.6.6 Onboard Serial Port 1 This item allows you to determine access onboard serial port 1 controller with which I/O address. The choices are: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, and Auto. 4.6.7 Onboard Serial Port 2 This item allows you to determine access onboard serial port 2 controller with which I/O address. -
Page 49: Power Management Setup Menu
BIOS SETUP 4.7 Power Management Setup Menu The Power Management Setup allows you to configure your system to most effectively save energy while operating in a manner consistent with your own style of computer use. 4.7.1 ACPI function ACPI (Advanced Configuration and Power Interface) evolves the existing motherboard configuration interfaces to support these advanced architectures in a more robust, and potentially more efficient manner. -
Page 50: Video Off Method
BIOS SETUP 4.7.3 Video Off Method Determines the manner in which the monitor is blanked. System turns off vertical and horizontal synchronization ports SYNC+Blank and writes blanks to the video buffer. Select this option if your monitor supports the Display Power Management Signaling (DPMS) standard of the Video DPMS Electronics Standards Association (VESA). -
Page 51: Pnp/Pci Configurations Menu
BIOS SETUP 4.8 PnP/PCI Configurations Menu 4.8.1 Reset Configuration Data Select Enabled to reset Extended System Configuration Date (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot. 4.8.2 Resources Controlled By The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play-compatible devices. -
Page 52: Pc Health Status
BIOS SETUP 4.9 PC Health Status 4.9.1 Shutdown Temperature To enable system shutdown at pre-set temperature, the options are Enable or Disable. 4.9.2 Show PC Health in POST Shows system voltage and temperature at POST, the option are Enable or Disable 4.9.3 Detect CPUFAN in POST Shows system CPU fan speed at POST, the option are Enable or Disable. -
Page 53: Current Sysfan Speed
BIOS SETUP 4.9.7 Current SYSFan Speed Display current system fan speed, the unit is RPM 4.9.8 Vcore Displays current CPU Core voltage value. 4.9.9 Vcc3.3 Displays current Vcc voltage value. 4.9.10 +5V Displays voltage value. 4.9.11 +12V Displays voltage value. 4.9.12 –12V Displays voltage value. -
Page 54: Set User Password
BIOS SETUP completes its cycle. Next time when booting the system, a password prompt will appear if the password function is enabled. 4.13 Set User Password When you select this function, a message appears at the center of the screen “ENTER PASSWORD”. -
Page 55: Troubleshooting
Troubleshooting Troubleshooting 5.1 General Troubleshooting Tips Is your system properly assembled and configured? Make sure the BIOS setup is set to default/optimal settings. Pressing <F2> or <DEL> key to enter the setup, select Default or Optimal settings, then save and exit the setup. For Windows 2000 that require ACPI support, make sure the ACPI option on your BIOS is enable (Some EOL boards will not support it at all). - Page 56 Check your reseller for the warranty and exchange policies. Please note that BCM DO NOT BACK reseller’s warranty if it EXCEEDS BCM’s current warranty policy which is one year from the date of manufacture and the board is PAST BCM’s warranty...
