P4 Socket 478 Motherboard
IN865GVR
User's Manual
http://www.bcmcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN865GVR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BCM IN865GVR

Summary of Contents for BCM IN865GVR

  • Page 1 P4 Socket 478 Motherboard IN865GVR User’s Manual http://www.bcmcom.com...
  • Page 2 (where applicable). References: This manual is created and written by BCM Technical Dept., but not limited, to the information from the IN865GVR External Production Specifications, and IN865GVR Specifications. If any comments, suggestions, or errors for this manual, please write an e-mail to support@bcmcom.com.
  • Page 3 Compliance & Certificate & & ISO 9001 Certificate: This device was produced in our plant with advanced quality system certified by DNV QA Ltd. in according to ISO 9001. This Certificate is valid for: DESIGN & MANUFACTURE OF MOTHERBOARD AND PERSONAL COMPUTERS. CE Declaration: CE marking is a visible declaration by the manufacturer or his authorized representatives that the electrical equipment to which it relates satisfies all the provisions of the 1994...
  • Page 4 Easy Installation Easy Installation Steps The following “Easy Installation” steps are for users accustomed to the assembly of a computer system. For those individuals requiring more specific information, please refer to the more detailed descriptions located within the latter chapters of this manual. Note: You must keep your power cable unplugged until the following installation steps are completed.

  • Page 5: Table Of Contents

    TABLE OF CONTENT USER’S NOTICE MANUAL REVISION INFORMATION COOLING SOLUTIONS CHAPTER 1 INTRODUCTION OF IN865GVR MOTHERBOARD 1-1 FEATURE OF MOTHERBOARD 1-2 SPECIFICATION 1-3 LAYOUT DIAGRAM 1-4 LAYOUT DIAGRAM & JUMPER SETTING CHAPTER 2 HARDWARE INSTALLATION 2-1 HARDWARE INSTALLATION STEPS 2-2 CHECKING MOTHERBOARD'S JUMPER SETTING...

  • Page 6: User's Notice

    AND TO THE OWNER’S BENEFIT, WITHOUT INTENT TO INFRINGEMENT. Manual Revision Information Reversion Revision History Date First Release May. 2004 Item Checklist IN865GVR Cable for IDE/Floppy CD for motherboard utilities □ Cable for USB Port 3/4 (Optional) IN865GVR User’s Manual Digital Format on CD IN865GVR Quick Reference Guide...

  • Page 7: Cooling Solutions

    Intel Pentium 4 Processor Family Cooling Solutions As processor technology pushes to faster speeds and higher performance, thermal management becomes increasingly crucial when building computer systems. Maintaining the proper thermal environment is key to reliable, long-term system operation. The overall goal in providing the proper thermal environment is keeping the processor below its specified maximum case temperature.

  • Page 8: Feature Of Motherboard

    With integrated Intel Extreme2 2D/3D Graphics Accelerator which supports 256 bit graphics core, and supports hardware motion compensation assist for software MPEG/DVD decode, makes this board a low cost solution. The IN865GVR also provide DFP support for those who wish to use of a digital display equip with LVDS TFT panel.

  • Page 9: Specification

    Micro ATX form factor 4 layers PCB size: 9.5”(W) x 9.5”(D) (244 x ∗ Chipset Intel 865GV Graphics Memory Controller Hub (GMCH) Chipset for IN865GVR ∗ Intel 82801ER I/O Controller Hub (ICH5R) Chipset ∗ CPU Socket Support Intel Pentium 4 with 512KB L2 cache on 0.13 micron / 90...

  • Page 10: Layout Diagram

    1-3 System Diagram IN865GVR Mainboard Diagram...

  • Page 11: Layout Diagram & Jumper Setting

    1-4 Jumper & Connector...
  • Page 12 Jumpers Jumper Name Description Page Inverter Power Select 3-pin Block LCD P4 Power Select 6-pin Block LCD P2 Power Select 3-pin Block Password Protect 3-pin Block Clear CMOS 3-pin Block BIOS Protect 4-pin Block Expansion Sockets Socket/Slot Name Description Page CPU 478 Socket 478-pin mPGAB CPU Socket J26,J29...
  • Page 13 Headers Header Name Description Page Line-In/Out, MIC Header 9-Pin Block AUX Header 4-Pin Block System Fan 3-Pin Block CD Audio-In Headers 4-Pin Block LCD Inverter Connector 5-Pin Block TV-Out 4-Pin Block Tel-In 4-Pin Block LVDS LCD Panel Connector 40-Pin Block (Hirose DF13-40DP- 1.25V) USB Port Headers 9-Pin Block...

  • Page 14: Chapter 2 Hardware Installation

    Chapter 2 Hardware installation 2-1 Hardware installation Steps Before using your computer, you had better complete the following steps: 1. Check motherboard jumper setting 2. Install CPU and Fan 3. Install System Memory (DIMM) 4. Install Expansion cards 5. Connect IDE and Floppy cables, Front Panel /Back Panel cable 6.

  • Page 15: Glossary

    2-3 Install CPU 2-3-1 Glossary Chipset (or core logic) – An highly integrated circuits which control the interfaces between the system processor, RAM, I/O devises, and adapter cards. Processor slot/socket - the slot or socket used to mount the system processor on the motherboard.

  • Page 16: About Intel Pentium 4 478-Pin Cpu

    2-3-2 About Intel Pentium 4 478-pin CPU This motherboard provides a 478-pin surface mount ZIF socket (Zero Insertion Force), referred to as the mPGA478B socket supports Intel Pentium 4 processor in the 478 Pin package utilizes Flip-Chip Pin Grid Array (FC-PGA2) package technology. The CPU should have a cooling FAN attached to prevent overheating.

  • Page 17: Install Memory

    2-4 Install Memory This motherboard provides 184-pin DIMM (DUAL INLINE MEMORY MODULES) sites for memory expansion available to maximum memory size of 2.0GB DDR SDRAM. • Support 128Mb, 256Mb, 512Mb technologies implemented as x8, x16 devices. • Non-ECC un-buffered DIMMS only. Valid Memory Configurations Bank 184-Pin DIMM...

  • Page 18: Expansion Card

    2-5 Expansion Cards WARNING! Turn off your power when adding or removing expansion cards or other system components. Failure to do so may cause severe damage to both your motherboard and expansion cards. 2-5-1 Procedure For Expansion Card Installation 1. Read the documentation for your expansion card and make any necessary hardware or software setting for your expansion card such as jumpers.

  • Page 19: Interrupt Request Table For This Motherboard

    2-5-3 Interrupt Request Table For This Motherboard Interrupt request are shared as shown the table below: INT A INT B INT C INT D INT E INT F INT G INT H √ Slot 1 √ Slot 2 √ Slot 3 √...

  • Page 20: Connectors, Headers

    2-6 Connectors, Headers 2-6-1 Connectors Power Connector (20-pin block) : ATXPWR ATX Power Supply connector. This is a new defined 20-pins connector that usually comes with ATX case. The ATX Power Supply allows to use soft power on momentary switch that connect from the front panel switch to 2-pins Power On jumper pole on the motherboard.
  • Page 21 PS/2 Mouse & PS/2 Keyboard Connector: PS2 KB/MOUSE The connectors for PS/2 keyboard and PS/2 Mouse. USB Port connector: USB (USB1) The connectors are 4-pin connector that connect USB devices to the system board. LAN Port connector: LAN This connector is standard RJ45 connector for Network connector. Parallel Port Connector (25-pin female): LPT Parallel Port connector is a 25-pin D-Subminiature Receptacle connector.
  • Page 22 (10) Floppy drive Connector (34-pin block): FDD This connector supports the provided floppy drive ribbon cable. After connecting the single plug end to motherboard, connect the two plugs at other end to the floppy drives. Pin 1 Floppy Drive Connector (11) Primary IDE Connector (40-pin block): IDE1 This connector supports the provided IDE hard disk ribbon cable.
  • Page 23 (12) Secondary IDE Connector (40-pin block): IDE2 This connector connects to the next set of Master and Slave hard disks. Follow the same procedure described for the primary IDE connector. You may also configure two hard disks to be both Masters using one ribbon cable on the primary IDE connector and another ribbon cable on the secondary IDE connector.

  • Page 24: Headers

    2-6-2 Headers Serial Port2 COM2 Header (9-pin) : COM2 COM2 Signal Signal SOUT Pin 1 Serial Port2 COM2 Header Line-Out, MIC Header (9-pin): AUDIO This header connect to Front Panel Line-out, MIC connector with cable. AUDIO Mic VRef Mic In Line Out L Line Out R Line In L...
  • Page 25 IDE Activity LED: IDE LED This connector connects to the hard disk activity indicator light on the case. Reset switch lead: RESET This 2-pin connector connects to the case-mounted reset switch for rebooting your computer without having to turn off your power switch. This is a preferred method of rebooting in order to prolong the lift of the system’s power supply.
  • Page 26 FAN Speed Headers (3-pin) : Chassis FAN, SYSFAN, CPUFAN These connectors support cooling fans, depending on the fan manufacturer, the wire and plug may be different. The red wire should be positive, while the black should be ground. Connect the fan’s plug to the board taking into consideration the polarity of connector.
  • Page 27 (12) LCD Panel Header (40-pin) : LVDS LCD Panel Connector J19 HIROSE DF-13-40DP-1.25V Signal Signal EN_BKL LDCP2 LCD-P4 = +3.3V LCDP4 LCD-P4 = +5V LCDP4 LCD-P4 = +12V LCDP4 Default = 1-2 LCD-P2 = +5V LCD-P2 = +12V Default = 1-2 CLK1M CLK1P Pin 1...

  • Page 28: Starting Up Your Computer

    2-7 Starting Up Your Computer 1. After all connection are made, close your computer case cover. 2. Be sure all the switch are off, and check that the power supply input voltage is set to the local voltage, usually in-put voltage is 220V∼240V or 110V∼120V depending on your country’s voltage used.

  • Page 29: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS The BIOS is a program located on a Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gain control. The BIOS first operates an auto-diagnostic test called POST (power on self test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 30: The Main Menu

    3-3 The Main Menu Once you enter Award  BIOS CMOS Setup Utility, the Main Menu (Figure 3-1) will appear on the screen. The Main Menu allows you to select from fourteen setup functions and two exit choices. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.
  • Page 31 Miscellaneous Control Use this menu to specify your settings for Miscellaneous control. Load Optimized Defaults Use this menu to load the BIOS default values that are settings for optimal performances system operations. Load Standard Defaults Use this menu to load the BIOS default values that are factory settings for the stable performance system operation.

  • Page 32: Standard Cmos Features

    3-4 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 33 If you select Manual, related information is asked to be entered to the following items. Enter the information directly from the keyboard. This information should be provided in the documentation from your hard disk vendor or the system manufacturer. If the controller of HDD interface is SCSI, the selection shall be “None”. If the controller of HDD interface is CD-ROM, the selection shall be “None”...

  • Page 34: Advanced Bios Features

    3-5 Advanced BIOS Features CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Advanced BIOS Features Hard Disk Boot Priority [Press Enter] Virus Warning Disabled Item Help CPU L1 & L2 Cache Enabled CPU L3 Cache Disable Hyper-Threading Technology Enabled Menu Level > Quick Power On Self Test Enabled First Boot Device...
  • Page 35 CPU Internal Cache The default value is Enabled. Enabled (default) Enable cache Disabled Disable cache Note: The internal cache is built in the processor. External Cache Choose Enabled or Disabled. This option enables the Level 2 cache memory. CPU L2 Cache ECC Checking Choose Enabled or Disabled.
  • Page 36 Keystrokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected. The settings are: Enabled/Disabled. Typematic Rate (Chars/Sec) Sets the number of times a second to repeat a keystroke when you hold the key down. The settings are: 6, 8, 10, 12, 15, 20, 24, and 30.

  • Page 37: Advanced Chipset Features

    3-6 Advanced Chipset Features The Advanced Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer. CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Advanced Chipset Features >...

  • Page 38: Dram Timing Settings

    Delay Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1. The settings are: Enabled and Disabled. AGP Transfer Mode In this item you can select AGP transfer mode Auto/4X/1X the Default setting is Auto. 3-6-1 DRAM Timing Settings CMOS Setup Utility –...

  • Page 39: Integrated Peripherals

    3-7 Integrated Peripherals CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Integrated Peripherals > OnChip IDE Device Press Enter > Onboard Device Press Enter Item Help > Super IO Device Press Enter Menu Level > ↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Optimized Defaults...

  • Page 40: Onboard Ide Function

    3-7-1 OnChip IDE Function CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Onboard IDE Function IDE HDD Block Mode Enabled OnChip Primary PCI IDE Enabled Item Help Primary Master Auto Primary Slave Auto Primary Master UDMA Auto Menu Level >> Primary Slave UDMA Auto...
  • Page 41 Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.

  • Page 42: Onboard Device Function

    3-7-2 Onboard Device CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Onboard Device Function USB Controller Enabled USB 2.0 Controller Enabled Item Help USB Keyboard Support Disabled USB Mouse Support Disabled AC97 Audio Auto Menu Level >> Onboard LAN Control Enabled CSA LAN <Giga-LAN>...

  • Page 43: Onboard Super Io Function

    3-7-3 Onboard Super IO Function CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Onboard Super IO Function Onboard FDD Controller Enabled Onboard Serial Port 1 3F8/IRQ4 Item Help Onboard Serial Port 2 2F8/IRQ3 Onboard Parallel Port 378/IRQ7 Parallel Mode Menu Level >> ECP Mode Use DMA PWRON After PWR Fail Midi Port Address...
  • Page 44 To operate the onboard parallel port as Standard Parallel Port only, choose “SPP.” To operate the onboard parallel port in the EPP modes simultaneously, choose “EPP.” By choosing “ECP”, the onboard parallel port will operate in ECP mode only. Choosing “ECP+EPP” will allow the onboard parallel port to support both the ECP and EPP modes simultaneously.

  • Page 45: Power Management Setup

    3-8 Power Management Setup The Power Management Setup allows you to configure your system to most effectively save energy saving while operating in a manner consistent with your own style of computer use. CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Power Management Setup ACPI Function Enable...
  • Page 46 This determines the manner in which the monitor is blanked. DPMS (default) Initial display power management signaling. Blank Screen This option only writes blanks to the video buffer. V/H SYNC+Blank This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the video buffer.

  • Page 47: Pnp/Pci Configuration Setup

    3-9 PnP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 48: Pc Health Status

    3-10 PC Health Status This section shows the Status of you CPU, Fan, Warning for overall system status. This is only available if there is Hardware Monitor onboard. CMOS Setup Utility – Copyright(C) 1984-2001 Award Software PC Health Status Shutdown Temperature Disabled +12V 12.22V...

  • Page 49: Miscellaneous Control

    3-11 Frequency/Voltage Control This section is for setting CPU Frequency/Voltage Control. CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Miscellaneous Control Auto Detect PCI CLK Enable Spread Spectrum Disable Item Help Menu Level > ↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Optimized Defaults...

  • Page 50: Set Supervisor/User Password

    3-13 Set Supervisor/User Password You can set either supervisor or user password, or both of them. The differences are: Supervisor password: Can enter and change the options of the setup menus. User password: Can only enter but do not have the right to change the options of the setup menus.
