P4 Socket 478 Motherboard
IN845GVD
User's Manual
http://www.bcmcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN845GVD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BCM IN845GVD

Summary of Contents for BCM IN845GVD

  • Page 1 P4 Socket 478 Motherboard IN845GVD User’s Manual http://www.bcmcom.com...
  • Page 2 (where applicable). References: This manual is created and written by BCM Technical Dept., but not limited, to the information from the IN845GVD External Production Specifications, and IN845GVD Specifications. If any comments, suggestions, or errors for this manual, please write an e-mail to support@bcmcom.com.
  • Page 3 Compliance & Certificate & & ISO 9001 Certificate: This device was produced in our plant with advanced quality system certified by DNV QA Ltd. in according to ISO 9001. This Certificate is valid for: DESIGN & MANUFACTURE OF MOTHERBOARD AND PERSONAL COMPUTERS. CE Declaration: CE marking is a visible declaration by the manufacturer or his authorized representatives that the electrical equipment to which it relates satisfies all the provisions of the 1994 Regulations.

  • Page 4: Easy Installation

    Easy Installation Easy Installation Steps The following “Easy Installation” steps are for users accustomed to the assembly of a computer system. For those individuals requiring more specific information, please refer to the more detailed descriptions located within the latter chapters of this manual. Note: You must keep your power cable unplugged until the following installation steps are completed.

  • Page 5: Table Of Contents

    TABLE OF CONTENT USER’S NOTICE MANUAL REVISION INFORMATION COOLING SOLUTIONS CHAPTER 1 INTRODUCTION OF IN845GVD MOTHERBOARD 1-1 FEATURE OF MOTHERBOARD 1-2 SPECIFICATION 1-3 LAYOUT DIAGRAM & JUMPER SETTING CHAPTER 2 HARDWARE INSTALLATION 2-1 HARDWARE INSTALLATION STEPS 2-2 CHECKING MOTHERBOARD'S JUMPER SETTING...

  • Page 6: User's Notice

    BENEFIT, WITHOUT INTENT TO INFRINGEMENT. Manual Revision Information Reversion Revision History Date First Release Mar. 2005 Item Checklist IN845GVD Mainboard Cable for IDE/Floppy CD for Mainboard Driver Utilities/ Manual IN845GVD Quick Installation Guide ATX I/O Shield □ Cable for USB Port 3/4 (Optional)

  • Page 7: Cooling Solutions

    Intel Pentium 4 Processor Family Cooling Solutions As processor technology pushes to faster speeds and higher performance, thermal management becomes increasingly crucial when building computer systems. Maintaining the proper thermal environment is key to reliable, long-term system operation. The overall goal in providing the proper thermal environment is keeping the processor below its specified maximum case temperature.

  • Page 8: Chapter 1 Introduction Of In845Gvd Motherboard

    With integrated 2D/3D Graphics Accelerator which supports 256 bit graphics core, and supports hardware motion compensation assist for software MPEG/DVD decode, makes this board a low cost alternative to a add on video card. The IN845GVD also provide LVDS DFP support those who wish to use of a digital display.

  • Page 9: Specification

    ∗ Micro ATX form factor 4 layers PCB size: 9.5”(W) x 9(D) Design (24.4x23.0cm) ∗ Intel 845GV Graphics Memory Controller Hub (GMCH) Chipset Chipset for IN845GVD ∗ Intel 82801DB I/O Controller Hub (ICH4) Chipset ∗ Support Intel Pentium 4/Celeron/Celeron D 478 Pin package CPU Socket (mPGA478B Socket)

  • Page 10: Layout Diagram & Jumper Setting

    1-3 Layout Diagram & Jumper Setting GAME/MIDI PORT PRINT PS/2 MOUSE PS/2 Keyboard LINE-IN COM1 LINE-OUT ATX 12V Power Conn. CPU 478 Socket PS2 KB/Mouse Port CPU FAN USB Port ATX P9 Power Conn. /LAN Connector DDR DIMM X2 ATX Power Conn. COM2 Connector Floppy Connector PC99 Back Panel...

  • Page 11: Expansion Sockets

    Jumpers Jumper Name Description Page CMOS RAM Clear 3-pin Block BIOS Protect 4-pin Block LCD P4 Power Select LCD 6-pin Block P.21 P2 Power Select 3-pin Block P.21 Connectors Connector Name Description Page ATXPWR ATX Power Connector 20-pin Block P.13 ATX12V ATX 12V Power Connector 4-pin Block...

  • Page 12: Chapter 2 Hardware Installation

    Chapter 2 Hardware installation 2-1 Hardware installation Steps Before using your computer, you had better complete the following steps: 1. Check motherboard jumper setting 2. Install CPU and Fan 3. Install System Memory (DIMM) 4. Install Expansion cards 5. Connect IDE and Floppy cables, Front Panel /Back Panel cable 6.
  • Page 13 (2) BIOS Protect (4-pin) : JP5 1-2 boot block protect Un-protect (Default) 3-4 all write protect FWH Write Protect Setting...

  • Page 14: Install Cpu

    2-3 Install CPU 2-3-1 Glossary Chipset (or core logic) - two or more integrated circuits which control the interfaces between the system processor, RAM, I/O devises, and adapter cards. Processor slot/socket - the slot or socket used to mount the system processor on the motherboard.

  • Page 15: About Intel Pentium 4 478-Pin Cpu

    2-3-2 About Intel Pentium 4 478-pin CPU This motherboard provides a 478-pin surface mount, Zero Insertion Force (ZIF) socket, referred to as the mPGA478B socket supports Intel Pentium 4 processor in the 478 Pin package utilizes Flip-Chip Pin Grid Array (FC-PGA2) package technology. The CPU should have a cooling FAN attached to prevent overheating.

  • Page 16: Install Memory

    2-4 Install Memory This motherboard provides 184-pin DUAL INLINE MEMORY MODULES (DIMM) sites for memory expansion available from minimum memory size of 64MB to maximum memory size of 2.0GB DDR SDRAM. Valid Memory Configurations Bank 184-Pin DIMM Total Memory Bank 0, 1 (DDR1) DDR333/DDR266 64MB∼1.0GB DDR SDRAM Module...

  • Page 17: Expansion Card

    2-5 Expansion Cards WARNING! Turn off your power when adding or removing expansion cards or other system components. Failure to do so may cause severe damage to both your motherboard and expansion cards. 2-5-1 Procedure For Expansion Card Installation 1. Read the documentation for your expansion card and make any necessary hardware or software setting for your expansion card such as jumpers.

  • Page 18: Interrupt Request Table For This Motherboard

    2-5-3 Interrupt Request Table For This Motherboard Interrupt request are shared as shown the table below: INT A INT B INT C INT D INT E INT F INT G INT H √ Slot 1 √ Slot 2 √ Slot 3 √...
  • Page 19 (2) ATX 12V Power Connector (4-pin block) : ATX12V This is a new defined 4-pins connector that usually comes with ATX Power Supply. The ATX Power Supply which fully support Pentium 4 processor must including this connector for support extra 12V voltage to maintain system power consumption. Without this connector might cause system unstable because the power supply can not provide sufficient current for system.
  • Page 20 Audio and Game Connector : GAME This Connector are 3 phone Jack for LINE-OUT, LINE-IN, MIC and a 15-pin D-Subminiature Receptacle Connector for joystick/MIDI Device. Line-out : Audio output to speaker Line-in : Audio input to sound chip MIC : Microphone Connector Game/MIDI : For joystick or MIDI Device...
  • Page 21 (12) Primary IDE Connector (40-pin block): IDE1 This connector supports the provided IDE hard disk ribbon cable. After connecting the single plug end to motherboard, connect the two plugs at other end to your hard disk(s). If you install two hard disks, you must configure the second drive to Slave mode by setting its jumpers accordingly.

  • Page 22: Headers

    2-6-2 Headers Serial Port2 COM2 Header (9-pin) : COM2 COM2 SIGNAL SIGNAL DCD#1 C DSR#1 C RXD#1 C RTS#1 C TXD1 C CTS#1 C DTR#1 C RI#1 C Pin 1 Note: Orient the read marking on the COM2 ribbon cable to pin 1 Serial Port2 COM2 Header Line-Out, MIC Header (9-pin): AUDIO This header connect to Front Panel Line-out, MIC connector with cable.
  • Page 23 Reset switch lead: RESET This 2-pin connector connects to the case-mounted reset switch for rebooting your computer without having to turn off your power switch. This is a preferred method of rebooting in order to prolong the lift of the system’s power supply. See the figure below. Speaker connector: SPEAKER This 4-pin connector connects to the case-mounted speaker.
  • Page 24 (10) Chassis Intrusion SIGNAL CHASSIS# FAN Speed Headers (3-pin) : SYSFAN, SYSFAN2, CPUFAN These connectors support cooling fans of 350mA (4.2 Watts) or less, depending on the fan manufacturer, the wire and plug may be different. The red wire should be positive, while the black should be ground.
  • Page 25 (13) CD Audio-In Headers (4-pin) : CDIN CDIN are the connectors for CD-Audio Input signal. Please connect it to CD-ROM CD- Audio output connector. CDIN SIGNAL CD Audio-In Headers (13) LCD LVDS Connector (40-pin): J3 SIGNAL SIGNAL EN_BKL LCD-P2 LCD-P4 LCD-P4 LCD-P4 CLK1M...
  • Page 26 (15) LCD P2 Voltage Select 3 pin : JP8 LCD P2 +5V LCD P2 +12V Default=1-2 LCD P2 Voltage Select (16) LCD P4 Pin Voltage Select 6 pin : JP7 LCD-P4=+3.3V LCD-P4=+5V LCD-P4=+12V DEFAULT=1-2 LCD P4 Pin Voltage Select (17) TV-Out 5 pin: J4 SIGNAL FB->GND FB->GND...

  • Page 27: Starting Up Your Computer

    2-7 Starting Up Your Computer 1. After all connection are made, close your computer case cover. 2. Be sure all the switch are off, and check that the power supply input voltage is set to the local voltage, usually in-put voltage is 220V∼240V or 110V∼120V depending on your country’s voltage used.

  • Page 28: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS The BIOS is a program located on a Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When starting the computer, the BIOS program gain control. The BIOS first operates an auto-diagnostic test called POST (power on self test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 29: The Main Menu

    3-3 The Main Menu Once you enter Whizpro ® BIOS CMOS Setup Utility, the Main Menu (Figure 3-1) will appear on the screen. The Main Menu allows you to select from fourteen setup functions and two exit choices. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.
  • Page 30 Enable/Disable peripheral controller, configure serial and parallel ports. Power Management Configure Power Management modes, timers, events, device control… PCI & PnP PnP OS flag, PnP configuration data, ISA memory & IRQ reservation. Hardware Monitor This entry shows your current system health status. Restore Default Settings Load factory default or fail-safe settings.

  • Page 31: General Configuration

    3-4 General Configuration The items in General Configuration Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. Whizpro BIOS SETUP Utility General Configuration Date...
  • Page 32 First/Second/Third/Fourth Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The settings are Floppy, LS/ZIP, HDD-0/HDD-1/HDD-3, SCSI, CDROM, LAD and Disabled. Power Up NumLock Status The default value is On. On (default) Keypad is numeric keys.

  • Page 33: Advanced Configuration

    3-5 Advanced Configuration Whizpro BIOS SETUP Utility Advanced Configuration IDE Drive Delay : Disabled Multi Sector Transfer : Auto Hyper-Threading Technology : Disabled Memory Test : Quick Halt on POST Error : Any error Video BIOS Cacheable : Disabled Typematic Rate Setting : Disabled Typematic Rate : -- Typematic Delay : -- Quiet Boot : Disabled...
  • Page 34 Video BIOS Cacheable Allow to select video BIOS cache enable or disable. Typematic Rate Settings Allow to enable or disable typematic rate. Quiet Boot Enable to display only error messages during boot. Frame Buffer for IGD Allocate a frame buffer for on chip integrate graphics. Internal Display Output Select boot display device.

  • Page 35: Primary Ide Drives/ Secondary Ide Drives

    3-6 Primary IDE Drives/ Secondary IDE Drives Whizpro BIOS SETUP Utility Primary IDE Drives Primary Master Drive Type : None Drive Mode : -- UDMA Mode : -- Cylindre : -- Head : -- Sector : -- Size<MB> : -- Primary Slave Drive Type : None Drive Mode : --...
  • Page 36 Whizpro BIOS SETUP Utility Secondary IDE Drives Secondary Master Drive Type : None Drive Mode : -- UDMA Mode : -- Cylindre : -- Head : -- Sector : -- Size<MB> : -- Secondary Slave Drive Type : None Drive Mode : -- UDMA Mode : -- Cylindre : -- Head : --...

  • Page 37: Integrated Peripherals

    3-7 Peripherals Whizpro BIOS SETUP Utility Peripherals Floppy Controller : Enabled Primary IDE : Enabled Secondary IDE : Enabled Serial Port 1 : Enabled Serial Port 2 : Enabled Mode : -- Parallèle Port : Enabled Mode : ECP DMA : Onboard USB Controller : Enabled USB Legacy Support : -- USB Disk Emulation : --...
  • Page 38 Select an address and corresponding interrupt for the first and the second serial ports. The settings are: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto. UART2 Mode This item allows you to determine which InfraRed(IR) function of the onboard I/O chip, this functions uses.

  • Page 39: Power Management

    3-8 Power Management Setup The Power Management Setup allows you to configure your system to most effectively save energy saving while operating in a manner consistent with your own style of computer use. Whizpro BIOS SETUP Utility Power Management Power Management : Enabled Stand-by Timer : Off Suspend Timer : Off Hard Disk Power Down : Disable...
  • Page 40 Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state. The settings are: Delay 4 Sec, Instant-Off. Modem Use IRQ This determines the IRQ in which the MODEM can use. The settings are: 3, 4, 5, 7, 9, 10, 11, NA. Wake On PME When enabled, BIOS will enable PCI devices to drive PME signal to wake up the system.

  • Page 41: Pci/Pnp Configuration

    3-9 PCI PnP Configuration Whizpro BIOS SETUP Utility PCI & PnP PnP OS Installed : Yes Reset Configure Data : No PCI VGA Palette Snoop : Disabled Reserved ISA Memory Space C800-CC00: No CC00-D000: No D000-D400: No D400-D800: No D800-DC00: No DC00-E000: No IRQ Reserved to ISA Device IRQ: None...

  • Page 42: Hardware Monitor

    3-10 Hardware Monitor This section shows the Status of you CPU, Fan, Warning for overall system status. This is only available if there is Hardware Monitor onboard. Whizpro BIOS SETUP Utility Hardware Monitor Chassis Intrusion Detect: Disabled CPU Voltage : FSB Voltage : 3.3 Volt : 5.0 Volt :...

  • Page 43: Restore Manufacture Settings

    3-11 Restore Manufacture Settings When you press <Enter> on this item, you get confirmation dialog box with a message similar Restore Manufacture Settings (Y/N)? N Pressing <Y> loads the BIOS default values for the most stable, minimal-performance system operations. Restore Fail-Safe Settings When you press <Enter>...

  • Page 44: Mechanical Draw

    Mechanical Draw...
