BCM IN865GV Quick Start Card

BIOS Setup:
Getting Ready to Install OS from a Bootable OS Installation CD:
Step 1: Press <DEL> key to enter the setup, it will get into BIOS Setup Menu.
Step 2: If doesn't show up, press <CTRL>+<ALT>+<DEL> keys simultaneously and after
the system reboots, repeat Step 1.
Step 3: Select "Load Optimized Defaults" by pressing the <↓> key.
Step 4: Press the <ENTER> key and new menu will appear.
Step 5: Press the <Y> key to load the default.
Step 6: Press the <ENTER> key and the menu disappears.
Step 7: Select "Advanced BIOS Features" by pressing the <↓> key and press the
<ENTER> key.
Step 8: New menu appears, select First Boot Device by using the <↓> key and press
the <ENTER> key.
Step 9: New menu appears, select CDROM by using the <↓> key and press <ENTER>
key to accept.
Step 10: Press the <ESC> key to return to "Main" menu.
Step 11: Press the <F10> key to move to "Save & Exit Setup" menu.
Step 12: Press the <ENTER> key since the "Save & Exit Setup" is already selected.
Step 13: New menu appears, press the <ENTER> key to save and exit the setup. The
computer will reboot itself and will start seeking for the installation CD and boot
from there.
Getting Ready to Install OS or Run from a Bootable Floppy Disk:
Step 1: Press <DEL> key to enter the setup, it will get into BIOS Setup Menu.
Step 2: If doesn't show up, press <CTRL>+<ALT>+<DEL> keys simultaneously and after
the system reboots, repeat Step 1.
Step 3: Select "Load Optimized Defaults" by pressing the <↓> key.
Step 4: Press the <ENTER> key and new menu will appear.
Step 5: Press the <Y> key to load the default.
Step 6: Press the <ENTER> key and the menu disappears.
Step 7: Select "Advanced BIOS Features" by pressing the <↓> key and press the
<ENTER> key.
Step 8: New menu appears, select First Boot Device by using the <↓> key and press
the <ENTER> key.
Step 9: New menu appears, select FLOPPY by using the <↑> key and press <ENTER>
key to accept.
Step 10: Press the <ESC> key to return to "Main" menu.
Step 11: Press the <F10> key to move to "Save & Exit Setup" menu.
Step 12: Press the <ENTER> key since the "Save & Exit Setup" is already selected.
Step 13: New menu appears, press the <ENTER> key to save and exit the setup. The
computer will reboot itself and will start seeking for the installation floppy disk and
boot from there.
Getting Ready to Install OS or Run the OS from a Hard Disk Drive:
Step 1: Press <DEL> key to enter the setup, it will get into Setup Menu.
Step 2: If doesn't show up, press <CTRL>+<ALT>+<DEL> keys simultaneously and after
the system reboots, repeat Step 1.
Step 3: Select Defaults tab by pressing the <→> key.
Step 4: Select Load Optimized Defaults by pressing the <↓> key.
Step 5: Press the <ENTER> key and new menu will appear.
Step 6: Press the <Y> key to change the default.
Step 7: Press the <ENTER> key and the menu disappears.
Step 8: Press the <ESC> key to move to Exit menu.
Step 9: Press the <ENTER> key since the Save & Exit Setup is already selected.
Step 10: New menu appears, press the <ENTER> key to save and exit the setup. The
computer will reboot itself and will start seeking for the hard disk drive and boot
from there.
IN865GV
Intel Pentium 4 with 0.13 micron / 90 nm
Process Socket 478 Processors Support
User's Quick Start Card
Version 1.00
Inspect the Package:
One IN865GV Motherboard
One IDE Cable (80 Pins)
One Floppy Cable
One Driver CD
One User's Quick Start Card
Motherboard
Responsibility:
This manual is provided "As-Is" with no warranties of any kind, expressed or implied,
including, but not limited to the implied warranties or conditions of this product's fitness for
any particular purpose. In no event shall we be liable for any loss of profits, loss of
business, loss of data, interruption of business, or indirect, special, incidental, or
consequential damages of any kind, even the possibility of such damages arising from any
defect or error in this manual or product. We reserve the right to modify and update the
user manual without prior notice.
WARNING: CMOS Battery Damage
Replace your system's CMOS RAM battery only with the identical CR-2032 3V Lithium-Ion
coin cell (or equivalent) battery type to avoid risk of personal injury or physical damage to
your equipment. Improper installation might cause battery to explode. Always dispose of
used batteries according to the manufacturer's instructions, or as required by the local
ordinance (where applicable). The damage due to not following this warning will void your
motherboard's manufacturer warranty.
Additional Information:
Additional information on setting this board up can be found in the User's Manual in the
provided CD-ROM. The Online User's Manual and FAQ/Knowledge Base can be found on
our website by visiting our website: http://www.bcmcom.com. If your question is not
answered in our FAQ/Knowledge Base, visit our forums and post your messages or submit
a new FAQ through FAQ Submittal form for us to add your question in our FAQ with our
answer.
ATTENTION: Incorrect BIOS Setup
If you do not know how to handle BIOS setup or how to set it up properly, it is strongly
advisable that you do not modify any of the settings than otherwise instructed in the User's
Quick Start Card. Even a seemingly small incorrect adjustment or modification in the BIOS
setup can render your system unstable or unusable. The incorrect BIOS setup is not
covered by your motherboard's manufacturer warranty.
