Connecting the TP-575 HDMI Line Receiver / DA

To connect the TP-575 together with the PT-571 HDMI Line Transmitter
and the PT-572+ HDMI Line Receiver, as illustrated in the example in
Figure 2, do the following:
1. On the PT-571, connect an HDMI source (for example, a DVD player)
to the HDMI IN connector.
2. Connect the CAT 5 OUT RJ-45 connector on the PT-571 to the CAT 5
LINE IN RJ-45 connector on the TP-575 via a twisted pair cable
section
3. On the TP-575, connect the OUT 2 (HDMI) connector to an HDMI
acceptor (for example, a plasma display).
4. Connect the OUT 1 (LINE) CAT 5 RJ-45 connector on the TP-575 to
the CAT 5 IN RJ-45 connector on the PT-572+ via a twisted pair cable
(see section 5.2).
5. On the PT-572+, connect the HDMI OUT connector to an HDMI
acceptor (for example, a plasma display).
6. Connect the 12V DC power adapter to the power socket
and connect the adapter to the mains electricity (not shown in
7. Press the EDID SETUP button to acquire or change the EDID
information (see section 5.3).
1 Using the Kramer CAT 5 BC-DGKat524, CAT 6 BC-DGKat623 cable or BC-DGKat7a23
2 To power the TP-575 as well as the PT-571 and PT-572+

Using the TP-575 HDMI Line Receiver / DA

5.2 ).
1
(see
1
2
on the TP-575
Figure 2 ).
7
