Comms/Returns - Sound Devices 664 User Manual And Technical Information

# Parameter Name
Record to SD
2
MP3 Bit Rate
3
4 Sample Freq .
Bit Depth
5
6 Pre-Roll Time

Comms/Returns

# Parameter Name
1 Slate/Com Mic Source
Ext Slate/Com Mic Gain
2
3 Com Send Program
4 Com Send Gain
Com Return Gain
5
6 Program Auto-Mute
Mic Toggle Switch
7
RTN Toggle Left
8
9 RTN Toggle Right
Description
Sets the type of file and which tracks to record to the
SD card .
The bitrate of recorded MP3 files .
The internal sample rate and sample rate of recorded
WAV files .
The bit depth of recorded WAV files .
Adjust the amount of record time to be appended
before each recording . Maximum value is 3 seconds
when recording mono WAV files to any media .
Description
Select internal or external slate microphone . Use Ext
12V setting for external condenser microphones .
Sets the input gain for external slate microphone .
Displays the Com Send Program selection screen
where sources can be chosen for right and left chan-
nel of the Com Send .
Sets the output gain of the COM Send output .
Sets the input gain of the COM RTN input .
Toggle automatic muting of COM Program when COM
communication is activated .
Selects primary and secondary function of the Slate/
Tone Switch .
Selects primary and secondary function of the left
side of the RTN Switch .
Selects primary and secondary function of the right
side of the RTN Switch .
664 User Guide and Technical Information
Options
• Off
» Wav Poly
• Wav Poly (ISOs Only)
• Wav Poly (LR Only)
• Wav Poly (X1X2 only)
• MP3 (LR)
• MP3 (X1X2)
• Wav Mono
• Wav Mono (ISOs only)
» 320kbs
• 192kbs
• 128kbs
• 44 .1k
• 47 .952k
• 47 .952kF
» 48k
• 48 .048k
• 48 .048kF
» 24
• 16
• 0 to 6 seconds (1 s increment)
» 0 s
Options
• OFF
» Int Mic
• Ext Mic
• Ext 12V Mic
• 0-36 dB (1 dB increment)
» 20 dB
• 0-48 dB (1 dB increment)
» 0 dB
• 0-24 dB (1 dB increment)
» 0 dB
» Enabled
• Disabled
» Slate/Com
• Com/Slate
» RTN A/COM RTN
• COM RTN/RTN A
» RTN B/C
• RTN C/B
47
