664 User Guide and Technical Information
switching between 6 Channel and 12 Channel Mode, it is recommended to save custom Setup Files
with the desired Input Mode and Meter Views.
The function of the Input Selector switches is altered in 12 Channel Mode: Slide the switch to the right
to PFL and access the Input Settings screen for inputs 7-12, and slide the Input Selector switch left
to PFL and access the Input Settings screen for inputs 1-6. The Input Settings screen for inputs 7-12
is slightly different than the Input Settings screens for inputs 1-6. HPF, Trim, and Fader values are
adjusted using the Select Encoder:
White box indicates selected
parameter . Rotate Select
Encoder to adjust value . Press
Select Encoder to move to
next parameter (HPF, Trim,
Fader) .
Press the Select Encoder to cycle the white highlighter box between HPF, Trim, and Fader. Rotate
the Select Encoder to adjust the value of the highlighted parameter (Acceleration is applied to Trim
and Fader adjustments to enable fast adjustments). To change an input back to a direct output for its
respective 1-6 input, press the Headphone Encoder and select the DIR.OUT option.
The Input Settings screen for inputs 7-12 can be access without engaging PFL for that input by holding
the Select Encoder down while sliding the Input Selector switch.
PFL of multiple inputs simultaneously is disabled in 12 Channel Mode.
Input 7-12 faders can also be adjusted from the Main Screen:
1. Press the Meters button until a Meter View which displays the desired input is visible.
2. Turn the Select Encoder to highlight the input to be adjusted.
3. Press the Select Encoder to access fader adjustment mode for the selected input. The input's
fader value (in dB) will appear in the lower right corner of the LCD.
4. Turn the Select Encoder to adjust the gain. Fader adjustment mode will exit automatically
after 3 seconds.
Channel being adjusted
12
v . 2 .01 Features and specifications are subject to change . Visit www .sounddevices .com for the latest documentation .
See Storing and Recalling Settings
Fader value (during adjustment)
Press Headphone Encoder
to set to Line Input, Direct
Output, or Off .
