LED does not light up, then your connection speed is 10Mbps.
Link/ACT Green. The Link /ACT LED also serves two purposes. If the LED is continuously lit, the
Router is successfully connected to a device through the corresponding port. If the LED is
flickering, the Router is actively sending or receiving data over that port.
EWAN LED Indicators:
10/100 Green. The 10/100 LED lights up when the corresponding port is 100Mbps connection. If this
LED does not light up, then your connection speed is 10Mbps.
Link/ACT Green. The Link /ACT LED lights up when a successful connection is made between the
Router and your cable or DSL modem. The Link/ACT LED flickers when the Router is
sending or receiving data over the EWAN port.

The Router's Rear Panel

The rear panel of WF514 contains the port connections listed below.
Viewed from left to right, the rear panel contains the following features:
Four local (LAN) 10/100 Ethernet ports for connecting the Router to the local PCs or hub, switch
Ethernet WAN (EWAN) port for connecting the Router to a Cable or DSL modem
Factory Default Reset push button
DC power connector for connecting through an AC power adapter (included as part of the product) to
the wall power outlet
Wireless antenna connector

The Hardware Reset Button

The Reset button can be used in one of two ways:
1. Reboot the Router while keeping all of its settings.
If the Router is having problems connecting to the Internet, press the Reset button for just a moment
with a paper clip or a pencil tip. This clears up any jammed connections.
2. Restore the Router's factory defaults and clear all of its settings, including a new password or wireless
settings.
If you are experiencing extreme problems with the Router and have tried all other troubleshooting
measures, press the Reset button and hold it down for 10 seconds.
