SWEEX MO251V2 - QUICK_START_GUIDE User Manual

Wireless adsl 2/2+ modem/router 54 mbps annex a
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English version
Introduction
• Do not expose the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A to extreme temperatures. Do not place the device in direct sunlight or in the
direct vicinity of heating elements.
• Do not use the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A in extremely dusty or moist surroundings.
• Protect the device against powerful shocks or jolts – they may damage the internal electronics.
• Never attempt to open the device yourself – it will cause the warranty to lapse.
Front or top view of the modem
LED indicators
PWR
1-4
1-4
WL / ACT
WL / ACT
ADSL
ADSL
ADSL
PPP
MO251V2 Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A
Status
Meaning
Lit
Indicates that the modem is switched on.
Lit
Indicates that a computer is connected to the relevant port.
Blinking
Indicates activity between the relevant computer and the modem.
Lit
Indicates that the wireless modem connection is enabled.
Blinking
Indicates activity between the wireless computer(s) and the modem.
Lit
The connection with the ADSL line is ok.
Regular blinking
The modem is busy setting up a proper connection or no ADSL is connected to the RJ11 port.
Lit and blinking fast
Indicates activity between the computer(s) and the Internet.
Lit
Indicates the use of a PPP connection.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MO251V2 - QUICK_START_GUIDE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWEEX MO251V2 - QUICK_START_GUIDE

Summary of Contents for SWEEX MO251V2 - QUICK_START_GUIDE

  • Page 1 MO251V2 Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A Introduction • Do not expose the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A to extreme temperatures. Do not place the device in direct sunlight or in the direct vicinity of heating elements.

  • Page 2: Side View

    ADSL line is ok. 3. Switch on the computer and connect it to the rear of the modem using a network cable (UTP RJ45). You can select any of the ports 1, 2, 3 and 4. The corresponding LED at the front of the modem will be lit. In the event the LED fails to light up, check whether the network cable is properly connected to the...
  • Page 3 Windows Vista In the bottom left of your screen, go to “Start” (Start) “Control Panel” (Control Panel). Click on “View network status and tasks” (View network status and tasks). Left in the column, click on “Manage network connections” (Manage network connections).
  • Page 4 English version Right-click “LAN Connection” (LAN Connection) or “Wireless Network connection” (Wireless Network connection) and select “Properties” (Properties). The following screen appears: Now select “Internet Protocol Version 4 (TCP/IPv4)” and click “Properties” (Properties).

  • Page 5: Windows Xp

    Select the options “Obtain an IP address automatically” (Obtain an IP address automatically) and “Obtain DNS server address automatically” (Obtain DNS server address automatically). Confirm the settings by clicking “OK”. The network settings have now been configured correctly for Vista. The correct settings for the Internet browser will be discussed later in this manual.

  • Page 6: Windows 2000

    Select the options “Obtain an IP address automatically“ (Obtain an IP address automatically) and “Obtain DNS server address automatically” (Obtain DNS server address automatically). Confirm the settings by clicking “OK” (OK). The network settings for Windows XP have now been configured correctly. The correct settings for the Internet browser will be discussed later in this manual.

  • Page 7: Windows 98Se

    Select the options “Obtain an IP address automatically” (Obtain an IP address automatically) and “Obtain DNS server address automatically” (Obtain DNS server address automatically). Click “OK” (OK) twice. The network settings for Windows 2000 have now been configured correctly. The correct settings for the Internet browser will be discussed later in this manual. Windows 98SE Go to “Start”...
  • Page 8 Under the tab “IP Address” (IP Address), select the option “Obtain an IP address automatically” (Obtain an IP address automatically). Under the tab “Gateway”, the list of “Installed gateways” (Installed gateways) must be empty. If so required, select each gateway and click “Remove”...

  • Page 9: Setting The Wireless Network

    You could compare a wireless network to radio signals. However, the range of a wireless network at home is not as big. Your home wireless network often has a range of 20 to 30 metres. This means that neighbours and passers-by too can make use of your network. As a result they can get away with surfing on your Internet connection, and they may gain access to your shared folders and files on your network.
  • Page 10 We recommend securing the wireless part of the modem. How to do this is described further down in this manual. Once secured, the network will show as “Sweex MO251V2” with a message below detailing “Security-enabled wireless network” (Security-enabled wireless network). When connecting to this secured network you will be prompted for the “Network key”...
  • Page 11 “mysweex”. If this login screen fails to appear, recheck the settings of your Internet browser as described above. Also check the IP address of your computer. In this IP address, only the digits after the last dot may deviate from the IP address of the modem (e.g.: 192.168.251.xxx). Do this as follows: Win2000/WinXP: Click “Start”...

  • Page 12: Wireless Settings And Security

    Under “Country” select the appropriate country and under “ISP”, select the corresponding Internet Provider. The modem will now automatically complete the settings. Then click “Next”. After this, some Internet providers require a user name and password to be filled out. Check this with the list of providers further down in this manual or with the details you received from your Internet provider.

  • Page 13: Securing The Wireless Network

    English version You can enable or disable the wireless part by means of “Enable AP”. This feature is enabled by default. “AP” (Access Point) refers to the wireless part of the modem. The standard SSID is “Sweex MO251V2”. You can change this under “SSID”. We recommend not changing this so you can always recognise the modem. Here you can also find other options such as “Channel”...
  • Page 14 1. You can now see only a single line with options. Select “WPA”. 2. Underneath, select “WPA” or “WPA2”. This depends on the type supported by the wireless card in your computer. Not all wireless adaptors support WPA2. 3. Select “Pre-Shared Key”...
  • Page 15 5. Click on “Add”, then on “Save All” to activate the settings. In some instances, or when a game console is used, you may opt to place a computer or game console entirely outside the firewall. This can be done in the so-called “demilitarized zone”...

  • Page 16: Lan Settings

    LAN settings The network settings (LAN) can be changed as follows. In the main window, go to “Advanced”. The option “LAN” is displayed next to it. Select this option. All settings you will change under “Ethernet” apply to both wired and wireless computers.
  • Page 17 In order to store the settings click “Apply” and then “Save All”. Subsequently, in the next window, click “Apply” once more. Upgrading the firmware of the modem (Update firmware) In order to provide the modem with updates, the so-called ‘firmware’ needs updating. You can do so by going to the menu, then “Tools” and selecting “Update firmware”.

  • Page 18: Warranty

    This Sweex product includes a software code developed by third parties, including a software code that is subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). Most users do not need the GPL source codes at all. It is only required during programming in order to alter the code. The GPL source codes are listed on our website.
