SWEEX LW053 Manual

Wireless broadband router 54 mbps
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English version
English version

Introduction

First of all, many thanks for purchasing this Sweex Wireless LAN USB 2.0 Adapter 54 Mbps. This Wireless LAN Adapter enables you to connect to
the wireless network safely, easily and fast.
To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during
installation or operation of this product, go to www.sweex.com and look under the heading service & support.
In order to be able to enjoy the Sweex Wireless LAN USB 2.0 Adapter 54 Mbps without any worries, it is important to observe a number of things:
• Do not expose the Sweex Wireless LAN USB 2.0 Adapter 54 Mbps to extreme temperatures. Do not place the device in direct sunlight or in the
direct vicinity of heating elements.
• Do not use the Sweex Wireless LAN USB 2.0 Adapter 54 Mbps in extremely dusty or moist surroundings.
• Protect the device against powerful shocks or jolts – they may damage the internal electronics.
• Never attempt to open the device yourself – it will cause the warranty to lapse.
Contents of the box
Prior to using Sweex Wireless LAN USB 2.0 Adapter 54 Mbps, check if all required parts are present. The following parts must be present in the box:
• Wireless LAN USB 2.0 Adapter 54 Mbps
• USB extension cable
• CD-ROM with software, driver, manual and Panda Antivirus trial software
If one of the above parts is missing, please contact the retail outlet where you purchased the device.

Specifications

• IEEE802.11b and IEEE802.11g support
• Maximum transfer speed: 54 Mbps
• Auto fallback
• Chipset: Ralink RT2571WF
• Protection: WPA encryption, IEEE802.x encryption, TKIP/AES encryption, 64/128/152-bit WEP encryption
• Supports: Windows 98SE, 2000 and XP
LW053 Sweex Wireless LAN USB 2.0 Adapter 54 Mbps


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LW053 and is the answer not in the manual?

Questions and answers

Related Manuals for SWEEX LW053

Summary of Contents for SWEEX LW053

  • Page 1: Specifications

    & support. In order to be able to enjoy the Sweex Wireless LAN USB 2.0 Adapter 54 Mbps without any worries, it is important to observe a number of things: •...
  • Page 2 CD-ROM you have just inserted. If Windows is unable to detect any drivers, you can also carry out a manual driver search. To that end, select “Install from a list or specific location”...
  • Page 3 A menu will automatically appear. In the event that the autorun menu does not appear, it can also be started manually. In order to do this, open “My computer”and go to X: (X being the letter of your CD-ROM drive). Here you will find the “autorun.exe” file. Double-click to execute.
  • Page 4 By adding a WEP or WPA protection code, you secure your network. This code is also referred to as the network key. Enter this code on each computer that wants to connect to that secured network. You can only be part of that network if you enter this code. If you did not enter the network key into the router or modem yourself, ask the installer, manufacturer, supplier or provider for this code.
  • Page 5 “USBLASTER” networks. In your situation, the detected networks will differ from this picture. In order to let the computer again check any networks it detects, click on “Refresh network list” in the left column. This will always give you the most up-to-date and latest situation.
  • Page 6 Check the network key. Check the wireless router, modem or access point which must provide the computer with an IP address. This is a unique number required for each computer that is part of a network. In most cases, the computer is automatically given an IP address.
  • Page 7 A window appears, indicating the status of the wireless connection. Click on the “Support” tab to view your IP address. If the connection is successful, the IP address shown usually is that of the wireless router or modem. If you need to enter or change the IP address settings, return to the “General” tab and click “Properties”.
  • Page 8 English version Click on the “Site Survey” tab in order to view a list of wireless networks detected by your computer. In our example, the “Sweex” network has been found. In your situation, the detected networks will differ from this picture.
