SWEEX LW055 Manual

Wireless broadband router 54 mbps
Hide thumbs
Table of Contents

Advertisement

Quick Links

English version

Front view

Status
Off
LAN1x t/m 4x
On
Blinking
Off
WAN
On

Rear view

1. Power connector for connecting the power adaptor.
2. WAN port for connecting a modem by means of a RJ-45 UTP Ethernet network cable.
3. AN ports 1, 2, 3 and 4 for connecting computers by means of an RJ-45 UTP Ethernet network cable.
4. Antenna
5. Reset button to return to the factory settings
LW055 Sweex Wireless Broadband Router 54 Mbps
Meaning
No device is connected to this port
A computer or other network device is connected to this port
Data traffic is exchanged between the router and the connected device
The router is not or not correctly connected to the internet modem
The router is connected to the internet modem


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LW055 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWEEX LW055

Summary of Contents for SWEEX LW055

  • Page 1: Front View

    1. Power connector for connecting the power adaptor. 2. WAN port for connecting a modem by means of a RJ-45 UTP Ethernet network cable. 3. AN ports 1, 2, 3 and 4 for connecting computers by means of an RJ-45 UTP Ethernet network cable. 4. Antenna...

  • Page 2: Windows Xp

    2. Switch on the computer and connect it to the rear of the modem using a network cable (RJ-45 UTP). You can select any of the ports 1, 2, 3 and 4.

  • Page 3: Windows 2000

    Select the options “Obtain an IP address automatically” and “Obtain DNS server address automatically”. Confirm the settings by clicking “OK”. The network settings for Windows XP have now been configured correctly. The correct settings for the Internet browser will be discussed later in this manual.
  • Page 4 Select the options “Obtain an IP address automatically” and “Obtain DNS server address automatically”. Click “OK” twice. The network settings for Windows 2000 have now been configured correctly. The correct settings for the Internet browser will be discussed later in this manual.
  • Page 5 Under the tab “IP Address”, select the option “Obtain an IP address automatically”. Under the tab “Gateway”, the list of “Installed gateways” must be empty. If so required, select each gateway and click “Remove”. Under the tab “DNS Configuration”, select the option “Disable DNS”. Click “OK” twice.

  • Page 6: Setting The Wireless Network

    You could compare a wireless network to radio signals. However, the range of a wireless network at home is not as big. Your home wireless network often has a range of 20 to 30 metres. This means that neighbours and passers-by too can make use of your network. As a result they can get away with surfing on your Internet connection, and they may gain access to your shared folders and files on your network.
  • Page 7 An IP address is a unique number required by each network device, including a computer or router, in order to be active within that network. Without an IP address you are unable to make connections within a network. Type the router IP address in the browser address bar. You can now access the router.
  • Page 8 Breedband Router forwards this existing Internet connection to one or more computers in your network. A total of 6 different settings are possible. We have listed these together with instructions on how to enter these. In order to find out which settings correspond to your provider, you can consult the list with providers further down in this manual.
  • Page 9 In order to check whether the Internet connection has been set up successfully, go to the status screen by clicking “Status” left in the column. The “WAN Status” section will display your “WAN IP address”. This must not be 0.0.0.0. It can sometimes take up to 1 minute for this IP address to appear.
  • Page 10 6. Wait 15 seconds and click “Save” in the top right corner. Confirm the message by clicking “OK”. In order to check whether the Internet connection has been set up successfully, go to the status screen by clicking “Status” left in the column.
  • Page 11 In order to check whether the Internet connection has been set up successfully, go to the status screen by clicking “Status” left in the column. The “WAN” section will display your Internet IP address. It can sometimes take up to 1 minute for this IP address to appear. You have now completed the configuration and are ready to surf the Internet.
  • Page 12 7. Click “Connect” to create the Internet connection. Next to this button the message “Connected” appears and your Internet IP address will be displayed under “Internet IP Address”. It can sometimes take up to 1 minute for it to be shown. You have now completed the configuration and are ready to surf the Internet.
  • Page 13 In order to check whether the Internet connection has been set up successfully, go to the status screen by clicking “Status” left in the column. The “WAN” section will display your Internet IP address. It can sometimes take up to 1 minute for this IP address to appear. You have now completed the configuration and are ready to surf the Internet.

  • Page 14: Wireless Settings And Security

    Left in the column, click “Wireless". The default SSID is “Sweex LW055”. We recommend not changing this so you can always recognise the router. Here you can also find other options such as “Channel” and “Radio Mode”. We again recommend maintaining the default values. You can enable or disable the wireless part under “Disabled Wireless”.
  • Page 15 The built-in firewall in this router cannot be disabled. However, ports can be opened for programmes and games which require this. We recommend using a fixed IP address for computers for which ports are opened. This is to ensure that these computers always use the same IP address as registered in the router.

  • Page 16: Virtual Server Set-Up

    English version In some instances, or when a game console is used, you may opt to place a computer or game console entirely outside the firewall. This can be done in the so-called “demilitarized zone” (“DMZ”). This option can be found in the main screen of the port settings (“Port Forwarding”) under (“Advanced”.) Note however, you no longer take advantage of the protection offered by the firewall of the router.
  • Page 17 Method 1: Follow this procedure whilst the router is switched on. The reset button is located on the side of the router. Use a pointy device to press the button. Press and hold the button for 10 seconds. The router will restart.

  • Page 18: Warranty

    Warranty All products under the Sweex brand are warranted for a period of three years. We do not grant support or warranties for any software and/or (rechargeable) batteries included. Settlement of guarantee only takes place via the dealer where you have purchased the product in question.
