Page 1: Operating Instructions
® ® Unlike any others ... that’s cost & value for you Professional UHF Wireless Microphone System VM-93C G2 Operating Instructions Frequency Selectable VM-93C G2 CHARGER VM-93C G2 VOLUME VOLUME MICROPHONE 1 MICROPHONE 2 2 Wireless Microphone System POWER POWER ACTIVE... -
Page 2: Table Of Contents
CONTENTS INTRODUCTION................1 Intro SYSTEM FEATURES................1 Features PACKAGE ACCESSORIES..............2 Package 2-in-1 BASE MODULE................ 3 • Base Module Controls and Functions..............3~4 • Hardware Setup................5~6 HANDHELD MICROPHONE............... 7 • Controls and Functions..............7 hand-held • Controls and Functions: Rechargeable Charger......7 OPERATION................. -
Page 3: Introduction
With years of experience designing wireless microphone system, we at Better Music Builder understand the problem with short battery life. Well, that’s a thing of the past now. The VM-93C G2 Wireless Microphone can easily last 12 hours! It is our first ever wireless microphone to use rechargeable lithium-ion battery, commonly used in today’s portable electronics such as mobile phones... -
Page 4: Package Accessories
G2 SERIES Generation 2 2-IN-1 BASE RECEIVER MODULE 2-IN-1 BASE MODULE [RECEIVER]: 1 SET 4.3 inches 10.8 cm RECEIVER ANTENNA: 2 UNITS HANDHELD MICROPHONE: SET of 2 AC-POWER CORD: 2 UNITS VM-93C G2 CHARGER HANDHELD MICROPHONE CHARGE BASE: 1 SET... -
Page 5: 2-In-1 Base Module
2-in-1 BASE MODULE [RECEIVER] Base Module CONTROLS AND FUNCTIONS VM-93C G2 VOLUME VOLUME MICROPHONE 1 MICROPHONE 2 2 Wireless Microphone System POWER POWER ACTIVE ACTIVE POWER 2450.00 2456.00 G2 SERIES Generation 2 2-IN-1 BASE RECEIVER MODULE FRONT PANEL: 1. MIC 1 VOLUME CONTROL: Controls volume. When pressed, channel/frequency can be adjusted. - Page 6 MICROPHONE 2 AUDIO OUT MICROPHONE 1 AUDIO OUT G2 SERIES ® Generation 2 Better Music Builder ® Model No.: VM-93C G2 (UHF Microphone) RISK OF ELECTRIC SHOCK DO NOT OPEN CALIFORNIA, UNITED STATES OF AMERICA Taking apart or modifying the ANTENNA-A...
-
Page 7: Hardware Setup
10 feet. The grounding of the balanced XLR Recommend connection delivers better quality signal by reducing noise. UHF WIRELESS SYSTEM DIAGRAM: UHF WIRELESS SYSTEM VM-93C G2 UHF WIRELESS SYSTEM VM-93C G2 MIC 1 HANDHELD MICROPHONE MIC 2 HANDHELD MICROPHONE... - Page 8 MICROPHONE 2 AUDIO OUT MICROPHONE 1 AUDIO OUT G2 SERIES ® Generation 2 Better Music Builder ® Model No.: VM-93C G2 (UHF Microphone) RISK OF ELECTRIC SHOCK DO NOT OPEN CALIFORNIA, UNITED STATES OF AMERICA Taking apart or modifying the ANTENNA-A ANTENNA-B E-MAIL: sales@bettermusicbuilder.com...
-
Page 9: Handheld Microphone
HANDHELD MICROPHONE Hand-held CONTROLS AND FUNCTIONS UHF WIRELESS SYSTEM VM-93C G2 1. INTERCHANGEABLE MICROPHONE HEAD 2. POWER BUTTON: Turns the microphone ON/OFF. Holding the button for 5 seconds to initiate syncing process with the receiver. CONTROLS AND FUNCTIONS: RECHARGEABLE CHARGER... -
Page 10: Operation
32 frequency channels. STEP 1: Press the VOLUME CONTROL on the receiver to go to channel selection. Notice the blinking channel number. VM-93C G2 VOLUME MICROPHONE 2 2 Wireless Microphone System ACTIVE POWER 2400.00... - Page 11 STEP 4: While the ACTIVE INDICATOR light on the receiver is blinking, turn ON the microphone and hold the POWER BUTTON on the microphone for 5 seconds to initiate the syncing process. VM-93C G2 VOLUME VOLUME MICROPHONE 1 MICROPHONE 2...
-
Page 12: How To Adjust Microphone Volume
HOW TO ADJUST MICROPHONE VOLUME Turn VOLUME CONTROL: Turn LEFT to decrease the volume and Turn RIGHT to increase the volume. VM-93C G2 VOLUME MICROPHONE 2 2 Wireless Microphone System ACTIVE POWER 2456.00 We recommend setting the microphone volume to a medium position, then control the overall volume from the amplifier/mixer. -
Page 13: Technical Specification
TECHNICAL SPECIFICATION Spec A. TECHNICAL FEATURE OF THE 2-IN-1 BASE MODULE: 1. Frequency Range: 2400MHz~2462MHz 2. Channels: 32 3. Signal to Noise Ratio: > 95dB 4. Total Harmonic Distortion: < 0.1% 5. Frequency Response: 30Hz ~ 18kHz (±1dB) 6. Dynamic Range: 110dB 7 . -
Page 14: Troubleshooting
TROUBLESHOOTING Troubleshooting CAUTION: Before troubleshooting any symptoms, make sure equipments are turned OFF. 1. SYMPTOM: NO SOUND COMING FROM MICROPHONE CAUSE: There is no indication of signal. REMEDIES: A. Battery may be low and should be recharged by placing the microphone onto the CHARGER BASE. - Page 15 4. SYMPTOM: DISTORTION IS INCREASING GRADUALLY. CAUSE: Battery is running low. REMEDIES: A. Recharge battery as soon as possible. B. Make sure to fully charge battery before use. 5. SYMPTOM: POOR SIGNAL. CAUSE: Objects can be disrupting communication between receiver and microphone.
-
Page 16: Appendix
APPENDIX Appendix VM-93C G2 FCC FREQUENCY: 2400.00~2462.00 MHz UHF Frequencies Available for Use for Home Electronics in North America The RF radio frequencies used in the transmission of wireless information are closely regulated in most countries including North America. A lot of countries... - Page 17 MIC 1 & MIC 2 FREQUENCY: 2400.00~2462.00 MHz Microphone 1 Frequency Microphone 2 Frequency FREQUENCY FREQUENCY FREQUENCY FREQUENCY 2432.00 2400.00 2432.00 2400.00 2434.00 2402.00 2434.00 2402.00 2436.00 2404.00 2436.00 2404.00 2406.00 2438.00 2406.00 2438.00 2440.00 2408.00 2440.00 2408.00 2442.00 2410.00 2442.00 2410.00 2444.00...
-
Page 18: Warranty
Please also note that our warranty does not cover any shipping cost for the return of defective products to us for inspection, repair and maintenance. Our warranty for Better Music Builder products can only be executed in North America. Our warranty does not cover the battery for wireless microphone products. -
Page 19: Contact Information
CONTACT INFORMATION Contact Us MAILING ADDRESS BETTER MUSIC BUILDER 29300 Kohoutek Way #150 Union City, CA 94587 U.S.A. TELEPHONE NUMBERS USA Region USA Toll Free: 1-800-318-2218 Sales & Marketing: 510-477-9955 Customer Service: 510-477-9955 FAX NUMBERS USA Region Sales & Marketing: 510-477-9922... - Page 20 MAINTENANCE NOTE...
- Page 21 MAINTENANCE NOTE...
- Page 22 . B e t t e r M u s i c B u i l d e r . c o m 360110910500 Code: 20111001 Printed on 100% Recycled Paper Comments E-mail to sales@bettermusicbuilder.com Copyright © 2011 Better Music Builder. All rights reserved. Legal trademark.
