Better Music Builder .com
Professional UHF Wireless Microphone System
VM-92U G2

Operating Instructions

UHF
Frequency Selectable
DUAL CHANNEL RECEIVER
MIC 1
UP
725.000
B
SET
RF
AF
CH
FRQ SCAN
DOWN
2-in-1 Base Module *** 1 Receive Module with 2 Wireless Microphones System
110421
2-IN-1 BASE RECEIVER MODULE
UHF
VM-92U G2
750.000
MHZ
B
MHZ
iR
IR
BAT
RF
AF
CH
FRQ SCAN
IR
BAT
POWER
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
P assi o n at e ab ou t Mu sic
w w w . B e t t e r M u s i c B u i l d e r . c o m
®
5mW
725.00
ON/OFF
MIC 2
UP
SET
DOWN
Passionate about Music
5mW
750.00
MHz
MHz
ON/OFF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM-92U G2 and is the answer not in the manual?

Questions and answers

Related Manuals for Better Music Builder VM-92U G2

Summary of Contents for Better Music Builder VM-92U G2

  • Page 1: Operating Instructions

    Better Music Builder .com ® Passionate about Music Professional UHF Wireless Microphone System VM-92U G2 110421 Operating Instructions Frequency Selectable 725.00 750.00 ON/OFF ON/OFF DUAL CHANNEL RECEIVER 2-IN-1 BASE RECEIVER MODULE MIC 1 MIC 2 VM-92U G2 725.000 750.000 FRQ SCAN...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION................1 Intro SYSTEM FEATURES................1 Features PACKAGE ACCESSORIES..............2 Package 2-in-1 BASE MODULE................ 3 • Base Module Controls and Functions..............3~4 • Hardware Setup................5~6 HANDHELD MICROPHONE............... 7 • Controls and Functions..............7~8 hand-held OPERATION................. 9~13 • How to Select Frequencies for the Receiver........9 •...

  • Page 3: Introduction

    INTRODUCTION Intro Better Music Builder VM-92U G2 is a second generation wireless microphone that uses the latest UHF wireless technology. It is a heavy duty design which includes two hand-held microphones with one 2-in- 1 Base Module, built-in LCD panel on both microphones and base units, solid built aluminum alloy handles, and Wireless Infrared Auto Sync System.

  • Page 4: Package Accessories

    750.000 FRQ SCAN FRQ SCAN DOWN DOWN POWER 2-IN-1 BASE MODULE [RECEIVER]: 1 SET UHF WIRELESS SYSTEM VM-92U G2 UHF WIRELESS SYSTEM VM-92U G2 10.2 inches 25.8 cm HANDHELD MICROPHONE: SET of 2 AA (1.5V) BATTERY: 4 UNITS RECEIVER DC POWER ADAPTOR: 1 UNIT...

  • Page 5: 2-In-1 Base Module

    2-in-1 BASE MODULE [RECEIVER] Base Module CONTROLS AND FUNCTIONS DUAL CHANNEL RECEIVER 2-IN-1 BASE RECEIVER MODULE MIC 1 MIC 2 VM-92U G2 750.000 750.000 FRQ SCAN FRQ SCAN DOWN DOWN POWER FRONT PANEL: 1. MIC 1 SELECTOR BUTTONS (UP/SET/DOWN): Allows control of LCD screen and it’s functions...
  • Page 6 14. Frequency: Displays current frequency. 15. Battery Status: Displays microphone battery status. REAR PANEL: MIC 2 BALANCED MIC 1 BALANCED Model No.: VM-92U G2 364130911000 AUDIO OUTPUT ® CALIFORNIA, UNITED STATES OF AMERICA w w w . B e t t e r M u s i c B u i l d e r. c o m Better Music Builder ®...

  • Page 7: Hardware Setup

    MIC 1 BALANCED OUTPUT (BALANCED XLR) (MIC 1 & 2 UNBALANCE) MIC 2 BALANCED OUTPUT (BALANCED XLR) UHF WIRELESS SYSTEM DIAGRAM: UHF WIRELESS SYSTEM VM-92U G2 UHF WIRELESS SYSTEM VM-92U G2 MIC 1 HANDHELD MICROPHONE MIC 2 HANDHELD MICROPHONE MIC 2 BALANCED MIC 1 BALANCED Model No.: VM-92U G2...
  • Page 8 HOW TO CONNECT DC-POWER: MIC 2 BALANCED MIC 1 BALANCED Model No.: VM-92U G2 364130911000 AUDIO OUTPUT ® CALIFORNIA, UNITED STATES OF AMERICA w w w . B e t t e r M u s i c B u i l d e r. c o m Better Music Builder ®...

  • Page 9: Handheld Microphone

    HANDHELD MICROPHONE Hand-held CONTROLS AND FUNCTIONS UHF WIRELESS SYSTEM VM-92U G2 ALKALINE ALKALINE BATTERY BATTERY 1. INTERCHANGEABLE MICROPHONE HEAD 2. LCD DIGITAL DISPLAY 3. POWER ON/OFF BUTTON 4. FREQUENCY SELECTION BUTTON: Press UP/DOWN button to select frequency. 5. IR PORT: Infrared port for the Wireless Infrared Auto Sync Technology.
  • Page 10 3. BATTERY STATUS: Indicates battery life. BATTERY STATUS: Full Battery Indicates full battery on the microphone. The engineering team of Better Music Builder uses 10mW 725.00 the latest technology to indicate the battery status, so you can see the battery strength.

  • Page 11: Operation

    OPERATION Operation HOW TO SELECT FREQUENCIES FOR THE RECEIVER The 2-in- 1 Base Module comes with two handheld microphones and the microphones are preset with 100 frequency channels. The frequency can be selected either automatically or manually. 1. AUTOMATIC FREQUENCY SELECT STEP 1: Press “SET”...

  • Page 12: How To Match Receiver's Frequency With Microphone

    (IR) directly at the receiver’s IR PORT to initiate the syncing process. MICROPHONE AND RECEIVER FREQUENCY MATCHED DUAL CHANNEL RECEIVER 2-IN-1 BASE RECEIVER MODULE MIC 1 MIC 2 10mW VM-92U G2 725.000 750.000 725.00 FRQ SCAN FRQ SCAN DOWN DOWN POWER MIC 2 725.000...

  • Page 13: How To Select Frequency/Channel For The Receiver

    MIC 2 BALANCED MIC 1 BALANCED 364130911000 Model No.: VM-92U G2 AUDIO OUTPUT ® CALIFORNIA, UNITED STATES OF AMERICA w w w. B e t t e r M u s i c B u i l d e r. c o m Better Music Builder ®...

  • Page 14: How To Insert/Change Batteries Of Microphone

    HOW TO INSERT/CHANGE BATTERIES OF MICROPHONE STEP 1: Twist open battery cover. UHF WIRELESS SYSTEM VM-92U G2 STEP 2: Use one hand to hold onto the top of the Microphone, and the other hand to slide 2x1.5V AA batteries into battery slot. Be careful not to drop Microphone while inserting batteries.

  • Page 15: How To Turn On/Off Microphone

    HOW TO TURN ON/OFF MICROPHONE TURN ON: Press the ON/OFF button and release it immediately to turn ON the microphone. Microphone’s LCD panel will display frequency, radio frequency and battery status. TURN OFF: Press and hold the power button for 3 725.00 seconds to turn OFF the microphone.

  • Page 16: Technical Specification

    TECHNICAL SPECIFICATION Spec A. TECHNICAL FEATURE OF THE 2-IN-1 BASE MODULE: 1. Channel: 100 Channels (total 200 Channels) 2. Frequency Range: UHF 725~750 MHz 3. Signal to Noise Ratio: > 90dB 4. Total Harmonic Distortion: < 0.5% 5. Band Width: < 250kHz 6.

  • Page 17: Body-Pack Microphone (Optional)

    BODY-PACK MICROPHONE SYSTEM SPECIFICATION (Optional) Body-Pack NAMES & FUNCTION: Body-Pack Microphone System (including Lavalier Mic. and Headset Mic.) Side-face Outside Picture 1. Antenna Picture 2. 4-pin Microphone Input Jack 3. LCD Digital Display 4. IR Port: Receives infrared beam to synchronize frequencies. IR when using multiple systems, only one microphone port should be exposed at a time...
  • Page 18 HOW TO INSERT BODY-PACK MICROPHONE BATTERIES STEP 1: Open battery cover. Good STEP 2: Insert 2 AA batteries. 2 ALKALINE BATTERY alkaline batteries are expected to ALKALINE BATTERY use for about 8 hours. CLOSE Make sure that you insert batteries correctly, as shown in picture.

  • Page 19: Troubleshooting

    TROUBLESHOOTING Troubleshooting CAUTION: Before troubleshooting any symptoms make sure the equipments are in the “OFF” position. 1. SYMPTOM: NO SOUND COMING FROM MICROPHONE A. CAUSE: There is no indication of signal. a. Turn microphone to “OFF” position. Check if batteries are inserted correctly. b.
  • Page 20 4. SYMPTOM: THE MICROPHONE SUDDENLY HAS NO SOUND AND THE RECEIVER LCD LIGHT IS OFF. Make sure the AC power adapter is securely plugged into the electrical outlet and into the DC input connector on the rear panel of the receiver. Make sure the AC electrical outlet works and is supplying the proper voltage.

  • Page 21: Appendix

    APPENDIX Appendix VM-92U G2 FCC FREQUENCY: 725.000~774.750 MHz UHF Frequencies Available for Use for Home Electronics in North America The RF radio frequencies used in the transmission of wireless information are closely regulated in most countries including North America. A lot of countries...
  • Page 22 MICROPHONE 1 FREQUENCY: 725.000~749.750 MHz FREQUENCY FREQUENCY FREQUENCY FREQUENCY 731.250 737 .500 743.750 725.000 731.500 737 .750 744.000 725.250 731.750 738.000 744.250 725.500 738.250 744.500 725.750 732.000 732.250 738.500 744.750 726.000 732.500 738.750 745.000 726.250 732.750 739.000 745.250 726.500 739.250 745.500 726.750 733.000...
  • Page 23 MICROPHONE 2 FREQUENCY: 750.000~774.750 MHz FREQUENCY FREQUENCY FREQUENCY FREQUENCY 756.250 762.500 768.750 750.000 756.500 762.750 769.000 750.250 756.750 763.000 769.250 750.500 763.250 769.500 750.750 757 .000 757 .250 763.500 769.750 751.000 757 .500 763.750 770.000 751.250 757 .750 764.000 770.250 751.500 764.250 770.500...

  • Page 24: Warranty

    Please also note that our warranty does not cover any shipping cost for the return of defective products to us for inspection, repair and maintenance. Our warranty for Better Music Builder products can only be executed in North America. Our warranty does not cover the battery for wireless microphone products.

  • Page 25: Contact Information

    CONTACT INFORMATION Contact Us MAILING ADDRESS BETTER MUSIC BUILDER 29300 Kohoutek Way #150 Union City, CA 94587 U.S.A. TELEPHONE NUMBERS USA Region USA Toll Free: 1-800-318-2218 Sales & Marketing: 510-477-9955 Customer Service: 510-477-9955 FAX NUMBERS USA Region Sales & Marketing: 510-477-9922...
  • Page 26 MAINTENANCE NOTE...
  • Page 27 MAINTENANCE NOTE...
  • Page 28 . B e t t e r M u s i c B u i l d e r . c o m 364130911000 Code: 20130921 Printed on 100% Recycled Paper Comments E-mail to sales@bettermusicbuilder.com Copyright © 2014 Better Music Builder. All rights reserved. Legal trademark.
