Better Music Builder VM-82U G3 Operating Instructions Manual

G3 series professional uhf wireless microphone system
Hide thumbs
Table of Contents

Advertisement

Quick Links

®
Unlike any others ... that's cost & value for you
Professional UHF Wireless Microphone System
VM-82U G3

Operating Instructions

G3 SERIES
Generation 3
UHF
Frequency Selectable
MICROPHONE 1
IR
PEAK
µV
PEAK
%
100
100
VOLUME
UHF
60
60
25
25
5
5
RF
DEV
MIN
MAX
2-in-1 Base Module *** 1 Receive Module with 2 Wireless Microphones System
®
FREQUENCY SYNC MUTE
FREQUENCY
FREQ
835.500
CHANNEL
SQUELCH
GHz
BOOSTER FREQ
MHz
STANDBY
01
6
CH:
SQ:
ANT
ANT
REMOTE
A
B
SET
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
P as si o na t e a b o u t M u si c
w w w . B e t t e r M u s i c B u i l d e r . c o m
®
Better Music Builder
®
P a s s i o n a t e a b o u t M u s i c
PEAK
µV
PEAK
100
VOLUME
60
25
5
VM-82U G3
RF
DEV
MIN
MAX
2-IN-1 BASE RECEIVER MODULE
MICROPHONE 2
%
FREQUENCY SYNC MUTE
FREQUENCY
FREQ
850.700
100
CHANNEL
60
SQUELCH
GHz
BOOSTER FREQ
25
MHz
STANDBY
5
03
3
CH:
SQ:
ANT
ANT
REMOTE
A
B
SET
POWER
ESC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM-82U G3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Better Music Builder VM-82U G3

Summary of Contents for Better Music Builder VM-82U G3

  • Page 1: Operating Instructions

    ® ® Unlike any others ... that’s cost & value for you Professional UHF Wireless Microphone System VM-82U G3 Operating Instructions G3 SERIES Generation 3 Frequency Selectable MICROPHONE 1 MICROPHONE 2 ® Better Music Builder ® P a s s i o n a t e a b o u t M u s i c PEAK µV...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION................1 Intro SYSTEM FEATURES................1 Features PACKAGE ACCESSORIES..............2 Package 2-in-1 BASE MODULE................ 3 • Base Module Controls and Functions..............3~4 • Hardware Setup................5~6 HAND-HELD MICROPHONE.............. 7 • Controls and Functions..............7~8 hand-held OPERATION..................9 • How to Set Up Microphone Frequency.......... 9 Operation •...

  • Page 3: Introduction

    We are well aware of short battery life among your favorite microphone systems. Through intensive research we have developed a better power management system to give our VM-82U G3 a much needed boost in battery life. It is simply the best solution for home and professional karaoke performance...

  • Page 4: Package Accessories

    STANDBY REMOTE REMOTE VM-82U G3 2-IN-1 BASE RECEIVER MODULE 2-IN-1 BASE MODULE [RECEIVER]: 1 SET UHF WIRELESS SYSTEM VM-82U G3 835. 5 00 HANDHELD MICROPHONE: SET of 2 DC POWER ADAPTOR: 1 UNIT 3.54 inches 9 cm DC-POWER USAGE: This wireless...

  • Page 5: 2-In-1 Base Module

    2-in-1 BASE MODULE [RECEIVER] Base Module CONTROLS AND FUNCTIONS MICROPHONE 1 MICROPHONE 2 ® Better Music Builder ® Pa s s i o n a t e a b o u t M u s i c PEAK µV PEAK...
  • Page 6 ® Better Music Builder ® G3 SERIES MIC 2 MIC 1 + MIC 2 MIC 1 DC-POWER Model No.: VM-82U G3 Generation 3 (UHF Microphone) RISK OF ELECTRIC SHOCK CALIFORNIA, UNITED STATES OF AMERICA DO NOT OPEN E-MAIL: sales@bettermusicbuilder.com 362111109800 Taking apart or modifying the w w w.

  • Page 7: Hardware Setup

    Recommend balanced XLR connection delivers better quality signal and reduces unwanted noise. UHF WIRELESS SYSTEM DIAGRAM: 835. 5 00 UHF WIRELESS SYSTEM VM-82U G3 MIC 1 HANDHELD MICROPHONE MIC 2 HANDHELD MICROPHONE MICROPHONE 2 AUDIO OUT MICROPHONE 1 AUDIO OUT G2 SERIES ®...
  • Page 8 ® Better Music Builder ® G3 SERIES MIC 2 MIC 1 MIC 1 + MIC 2 DC-POWER Model No.: VM-82U G3 Generation 3 (UHF Microphone) RISK OF ELECTRIC SHOCK CALIFORNIA, UNITED STATES OF AMERICA DO NOT OPEN E-MAIL: sales@bettermusicbuilder.com 362111109800 Taking apart or modifying the w w w.

  • Page 9: Handheld Microphone

    HANDHELD MICROPHONE Hand-held CONTROLS AND FUNCTIONS 835. 5 00 835. 5 00 SYNC UHF WIRELESS SYSTEM VM-82U G3 ALKALINE ALKALINE BATTERY BATTERY 1. INTERCHANGEABLE MICROPHONE HEAD 2. LCD PANEL: Displays system status. 3. IR PORT: Broadcasts signal to receiver to allow communication.
  • Page 10 3. BATTERY STATUS: Shows battery level of microphone. BATTERY STATUS: Full Battery Indicates full battery on the microphone. The engineering team of Better Music Builder uses the latest technology to indicate the battery status, so you can see the battery strength. Low Battery Indicates low battery on the microphone.

  • Page 11: Operation

    REMOTE REMOTE VM-82U G3 2-IN-1 BASE RECEIVER MODULE SYNCING PROCESS UHF WIRELESS SYSTEM VM-82U G3 STEP 3: Press SET to initiate the synchronization process. The IR PORT will show red light if it is sync correctly. MICROPHONE 2 PEAK µV...

  • Page 12: How To Lock/Unlock Receiver's Settings

    HOW TO LOCK/UNLOCK RECEIVER’S SETTINGS Do the following when the receiver is POWERED OFF. STEP 1: Press and hold SET on the receiver. Do not release it. MICROPHONE 2 FREQUENCY FREQ CHANNEL VOLUME POWER SQUELCH BOOSTER FREQ STANDBY REMOTE STEP 2: Then Press POWER on the receiver. MICROPHONE 2 FREQUENCY FREQ...

  • Page 13: How To Adjust Microphone Volume

    HOW TO ADJUST MICROPHONE VOLUME Turn VOLUME left to decrease the volume and right to increase the volume on the receiver. MICROPHONE 2 PEAK µV PEAK FREQUENCY SYNC MUTE FREQUENCY FREQ 850.700 CHANNEL VOLUME POWER SQUELCH BOOSTER FREQ STANDBY REMOTE We recommend setting the microphone volume to a medium position, then control the overall volume from the amplifier/mixer.

  • Page 14: How To Insert/Change Batteries Of Microphone

    HOW TO INSERT/CHANGE BATTERIES OF MICROPHONE STEP 1: Twist and slide open the battery cover. UHF WIRELESS SYSTEM VM-82U G3 STEP 2: Hold the top of the microphone with one hand and with the other hand slide two AA batteries into the battery compartment.

  • Page 15: How To Turn On/Off Microphone

    HOW TO TURN ON/OFF MICROPHONE TURN ON: Press the power button and release it immediately to turn ON the microphone. Microphone’s LCD panel will display frequency, and battery status. TURN OFF: Press and hold the power button for 3 seconds to turn OFF the microphone.

  • Page 16: Technical Specification

    TECHNICAL SPECIFICATION Spec A. TECHNICAL FEATURE OF THE 2-IN-1 BASE MODULE: 1. Frequency Range: UHF 820~990 MHz 2. Channels: 60 3. Signal to Noise Ratio: > 90dB 4. Total Harmonic Distortion: ≤ 1% 5. Frequency Response: 80Hz ~ 15KHz (±3dB) 6.

  • Page 17: Body-Pack Microphone (Optional)

    BODY-PACK MICROPHONE SYSTEM (Optional) SPECIFICATION Body-Pack NAMES & FUNCTION: Body-Pack Microphone System (including Lavalier Mic. and Headset Mic.) Side-face Outside Picture 1. Antenna Picture 2. 4-pin Microphone Input Jack 3. LCD Digital Display 4. IR Port: Receives infrared beam to synchronize frequencies. IR when using multiple systems, only one microphone port should be exposed at a time...
  • Page 18 HOW TO INSERT BODY-PACK MICROPHONE BATTERIES STEP 1: Open battery cover. Good STEP 2: Insert 2 AA batteries. 2 ALKALINE BATTERY alkaline batteries are expected to ALKALINE BATTERY use for about 8 hours. CLOSE Make sure that you insert batteries correctly, as shown in picture.

  • Page 19: Troubleshooting

    TROUBLESHOOTING Troubleshooting CAUTION: Before troubleshooting any symptoms, make sure equipments are turned OFF. 1. SYMPTOM: NO SOUND COMING FROM MICROPHONE CAUSE: There is no indication of signal. REMEDIES: A. Battery may be low and should be recharged by placing the microphone onto the CHARGER BASE.
  • Page 20 4. SYMPTOM: DISTORTION IS INCREASING GRADUALLY. CAUSE: Battery is running low. REMEDIES: A. Recharge battery as soon as possible. B. Make sure to fully charge battery before use. 5. SYMPTOM: POOR SIGNAL. CAUSE: Objects can be disrupting communication between receiver and microphone.

  • Page 21: Appendix

    APPENDIX Appendix VM-82U G3 FCC FREQUENCY: 820.000~990.000 MHz UHF Frequencies Available for Use for Home Electronics in North America The RF radio frequencies used in the transmission of wireless information are closely regulated in most countries including North America. A lot of countries...
  • Page 22 MIC 1 & MIC 2 FREQUENCY: 820.000~990.000 MHz MIC 1 FREQUENCY 835~850MHz MIC 2 FREQUENCY 850~865MHz FREQUENCY FREQUENCY FREQUENCY FREQUENCY 849.950 857 .300 842.525 835.500 850.425 857 .875 836.300 842.850 843.450 850.700 858.225 836.650 843.825 8511.00 858.650 837 .250 859.100 844.300 851.500 837 .700...

  • Page 23: Warranty

    Please also note that our warranty does not cover any shipping cost for the return of defective products to us for inspection, repair and maintenance. Our warranty for Better Music Builder products can only be executed in North America. Our warranty does not cover the battery for wireless microphone products.

  • Page 24: Contact Information

    CONTACT INFORMATION Contact Us MAILING ADDRESS BETTER MUSIC BUILDER 29300 Kohoutek Way #150 Union City, CA 94587 U.S.A. TELEPHONE NUMBERS USA Region USA Toll Free: 1-800-318-2218 Sales & Marketing: 510-477-9955 Customer Service: 510-477-9955 FAX NUMBERS USA Region Sales & Marketing: 510-477-9922...
  • Page 25 MAINTENANCE NOTE...
  • Page 26 . B e t t e r M u s i c B u i l d e r . c o m 364110609200 362111109800 Code: 20111122 Printed on 100% Recycled Paper Comments E-mail to sales@bettermusicbuilder.com Copyright © 2012 Better Music Builder. All rights reserved. Legal trademark.
