Unlike any others ... that's cost & value for you
Professional UHF Wireless Microphone System
VM-52U G2

Operating Instructions

UHF
Frequency Selectable
ON
ON
OFF
OFF
®
Better Music Builder UHF Wireless System VM-52U G2 2-in-1 BASE RECEIVER MODULE
CH
CH
RF AF
RF AF
01
02
653.25
556.00
MIN
MAX
MIN
MAX
MHz
MHz
MIC 1 VOLUME
MIC 2 VOLUME
UHF
POWER
2-in-1 Base Module *** 1 Receive Module with 2 Wireless Microphones System
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
P as si o na t e a b o u t M u si c
w w w . B e t t e r M u s i c B u i l d e r . c o m
