Better Music Builder .com
Professional UHF Wireless Microphone System
VM-62U Beta
Operating Instructions
UHF
Frequency Selectable
AF
SYNC
IR
Better Music Builder VM-62U Beta
MIC 1 VOLUME
RF
2-in-1 Base Module *** 1 Receive Module with 2 Wireless Microphones System
AF
MHz
MHz
SYNC
MANUAL
MANUAL
IR
FREQUENCY
FREQUENCY
UHF
SELECT
SELECT
MIC 2 VOLUME
RF
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
P assi o n at e ab ou t Mu sic
w w w . B e t t e r M u s i c B u i l d e r . c o m
®
Passionate about Music
BAT
POWER
It's what we do!
BAT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Better Music Builder VM-62U Beta
Summary of Contents for Better Music Builder VM-62U Beta
-
Page 1: Operating Instructions
MANUAL MANUAL FREQUENCY FREQUENCY SELECT SELECT Better Music Builder VM-62U Beta MIC 1 VOLUME MIC 2 VOLUME POWER 2-in-1 Base Module *** 1 Receive Module with 2 Wireless Microphones System Thank you for purchasing this unit. To make full and effective use of this unit, please read this Owner's Manual carefully before operating it. -
Page 2: Table Of Contents
CONTENTS INTRODUCTION................1 Intro SYSTEM FEATURES................1 Features PACKAGE ACCESSORIES..............2 Package 2-in-1 BASE MODULE................ 3 • Controls and Functions..............3~4 Base Module • Hardware Setup................5~7 HANDHELD MICROPHONE............... 8 • Controls and Functions..............8~9 handheld OPERATION................10~13 • Selecting Frequency/Channel for the Receiver......10 Operation •... -
Page 3: Introduction
INTRODUCTION Intro The Better Music Builder VM-62U Beta is a Second Generation UHF Dual-Channel Microphone System that uses the latest technologies and engineering. Its light-weight design features two handheld microphones with one 2-in- 1 Base Module, Clear Voice Technology, and Auto Sync System. -
Page 4: Package Accessories
SYNC SYNC MANUAL MANUAL FREQUENCY FREQUENCY SELECT SELECT Better Music Builder VM-62U Beta MIC 1 VOLUME MIC 2 VOLUME POWER HANDHELD MICROPHONE: 2 UNITS RECEIVER ANTENNA: 2 UNITS DC POWER ADAPTER: 1 UNITS AUDIO CABLE AA (1.5V) BATTERY: 4 UNITS... -
Page 5: 2-In-1 Base Module
SYNC MANUAL MANUAL FREQUENCY FREQUENCY SELECT SELECT Better Music Builder VM-62U Beta MIC 1 VOLUME MIC 2 VOLUME POWER FRONT PANEL: 1. MIC 1 VOLUME CONTROL: Controls Microphone 1 volume. 2. MIC 1 SYNC BUTTON: Automatically matches the microphone’s frequency to the receiver’s frequency. -
Page 6: Rear Panel
15. FREQUENCY: Displays current frequency. 16. CHANNEL: Displays current channel. REAR PANEL: Model No.: VM-62U Beta AUDIO OUTPUT CALIFORNIA, UNITED STATES OF AMERICA w w w. B e t t e r M u s i c B u i l d e r. c o m ENGINEERED AND DESIGNED IN U.S.A. -
Page 7: Hardware Setup
MIC 2 shares a single signal. To produce different effects on two microphones, MIC 1 and MIC 2 need independent signals using separate XLR connections. Model No.: VM-62U Beta AUDIO OUTPUT CALIFORNIA, UNITED STATES OF AMERICA w w w. B e t t e r M u s i c B u i l d e r. c o m ENGINEERED AND DESIGNED IN U.S.A. - Page 8 647.600 MIC 1 HANDHELD MICROPHONE MIC 2 HANDHELD MICROPHONE Model No.: VM-62U Beta AUDIO OUTPUT CALIFORNIA, UNITED STATES OF AMERICA w w w. B e t t e r M u s i c B u i l d e r. c o m ENGINEERED AND DESIGNED IN U.S.A.
- Page 9 10 inches SYNC SYNC MANUAL MANUAL FREQUENCY FREQUENCY SELECT SELECT Better Music Builder VM-62U Beta MIC 1 VOLUME MIC 2 VOLUME POWER 5.4 inches 8.2 inches 5.4 inches 19 inches Rack mount kit is not included in package. Dual Receiver Rack Mount Kit...
-
Page 10: Handheld Microphone
HANDHELD MICROPHONE Handheld CONTROLS AND FUNCTIONS ALKALINE ALKALINE BATTERY BATTERY 1. INTERCHANGEABLE MICROPHONE HEAD 2. LCD DIGITAL DISPLAY: Displays frequency and battery status. 3. IR PORT: Infrared port for the Wireless Infrared Auto Sync System. 4. POWER BUTTON 5. BATTERY COMPARTMENT: Insert 2x1.5V AA battery or 2x1.2V rechargeable AA battery. - Page 11 LCD PANEL: After turning on the “POWER”, the LCD screen will light up as below: 1. FREQUENCY: Current value depends on setting. 2. BATTERY STATUS: Indicates battery life. BATTERY STATUS: Full Battery Indicates full battery on the microphone. A full battery lasts up to 8 hours. Low Battery Indicates low battery on the microphone.
-
Page 12: Operation
OPERATION Operation SELECTING FREQUENCY/CHANNEL FOR THE RECEIVER The 2-in- 1 Base Module comes with two handheld microphones and each microphone is preset with 40 frequency channels. 1. MANUAL FREQUENCY SELECT Press “UP ▲ or DOWN ▼” to select the desired frequency. SYNC MANUAL MANUAL... -
Page 13: Syncing Receiver's Frequency With Microphone
MANUAL FREQUENCY FREQUENCY SELECT SELECT MIC 1 VOLUME Better Music Builder VM-62U Beta MIC 2 VOLUME POWER Each unit is fully tested and qualified by the manufacturer. However, due to the nature of wireless connection, interference may occur because of... -
Page 14: Adjusting Microphone Volume
ADJUSTING MICROPHONE VOLUME VOLUME CONTROL: Turn left to decrease the volume and right to increase the volume. SYNC MANUAL MANUAL FREQUENCY FREQUENCY SELECT SELECT MIC 2 VOLUME We recommend setting the microphone volume to a medium level, then control the overall volume from the amplifier/mixer. Recommend TURNING ON/OFF MICROPHONE Press the POWER BUTTON to... -
Page 15: Replacing Batteries
REPLACING BATTERIES STEP 1: Twist open battery cover. STEP 2: Use one hand to hold onto the top of the microphone and the other hand slide two AA batteries into battery compartment. ALKALINE BATTERY Make sure to follow the polarity of the battery according to the diagram on battery compartment. -
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS Specs A. TECHNICAL FEATURE OF THE SYSTEM: • Channel: 40 Channels (Total 80 Channels) • Frequency Range: UHF 627 .000~667 .000 MHz • Frequency Preparation: PLL • Mode: FM • AF Response: 80~15kHz (+/-3dB) • Distortion: ≤0.3% • Operating Temperature Range: - 1 0°C~40°C •... -
Page 17: Body-Pack Microphone (Optional)
BODY-PACK MICROPHONE SYSTEM (Optional) Body-Pack CONTROLS & FUNCTIONS: Body-Pack Microphone System (including Lavalier Mic. and Headset Mic.) SIDE VIEW FRONT VIEW 1. Antenna 2. 4-pin Microphone Input Jack 3. LCD Digital Display 4. IR Port: Receives infrared beam to synchronize frequencies. IR when using multiple systems, only one microphone port should be exposed at a time... - Page 18 REPLACING BODY-PACK BATTERIES STEP 1: Open battery cover. Good STEP 2: Insert 2 AA batteries. 2 ALKALINE BATTERY alkaline batteries are expected to ALKALINE BATTERY last 8 hours. CLOSE Make sure to insert batteries correctly according to diagram. ALKALINE BATTERY When the microphone body-pack light glows red, the batteries should OPEN...
-
Page 19: Troubleshooting
TROUBLESHOOTING Troubleshooting CAUTION: Before troubleshooting any symptoms make sure all devices are powered off. 1. SYMPTOM: NO SOUND COMING FROM MICROPHONE A. CAUSE: There is no signal. REMEDY: • Check if batteries are inserted correctly. • If batteries are inserted correctly but still no power, insert new batteries. •... - Page 20 4. SYMPTOM: THE MICROPHONE SUDDENLY HAS NO SOUND BUT THE RECEIVER SHOWS RF SIGNAL. CAUSE: The microphone wire is damaged or disconnected. REMEDY: Open the microphone head cover to check the wire and reconnect the wire. If it does not work, replace the microphone head. 5.
-
Page 21: Appendix
APPENDIX Appendix VM-62U Beta FCC FREQUENCY: 627.000~667.000 MHz UHF Frequencies Available for Use for Home Electronics in North America The radio frequencies used in the transmission of wireless information are closely regulated in most countries including North America. A lot of countries... - Page 22 VM-62U Beta FREQUENCY: 627.000~667.000 MHz MIC 1 FREQUENCY MIC 2 FREQUENCY 627.000-647.000 MHz 647.600-667.000 MHz FREQUENCY FREQUENCY FREQUENCY FREQUENCY 637 .000 647 .600 657 .600 627 .000 648.000 658.000 627 .500 637 .500 628.000 638.000 648.500 658.500 638.500 649.000 659.000 628.500...
-
Page 23: Warranty
Please also note that our warranty does not cover any shipping cost for the return of defective products to us for inspection, repair and maintenance. Our warranty for Better Music Builder products can only be executed in North America. Our warranty does not cover the battery for wireless microphone products. -
Page 24: Contact Information
CONTACT INFORMATION Contact Us MAILING ADDRESS BETTER MUSIC BUILDER 29300 Kohoutek Way #150 Union City, CA 94587 U.S.A. TELEPHONE NUMBERS USA Region USA Toll Free: 1-800-318-2218 Sales & Marketing: 510-477-9955 Customer Service: 510-477-9955 FAX NUMBERS USA Region Sales & Marketing: 510-477-9922... - Page 25 MAINTENANCE NOTE...
- Page 26 MAINTENANCE NOTE...
- Page 27 MAINTENANCE NOTE...
- Page 28 . B e t t e r M u s i c B u i l d e r . c o m 362161204500 Code: 20170302 Printed on 100% Recycled Paper Comments E-mail to sales@bettermusicbuilder.com Copyright © 2017 Better Music Builder. All rights reserved. Legal trademark.
