BLOOD GLUCOSE MONITORING SYSTEM
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLOOD GLUCOSE MONITORING SYSTEM and is the answer not in the manual?

Questions and answers

Related Manuals for Bayer HealthCare BLOOD GLUCOSE MONITORING SYSTEM

Summary of Contents for Bayer HealthCare BLOOD GLUCOSE MONITORING SYSTEM

  • Page 1 BLOOD GLUCOSE MONITORING SYSTEM USER GUIDE...
  • Page 2 Capillary samples may be drawn from alternate site testing locations. The C ONTOUR blood glucose monitoring system may also be used by healthcare professionals to monitor hypoglycaemia in neonates diagnosed with laboratory glucose methods. Additional Materials ®...

  • Page 3: Table Of Contents

    Table of Contents Your Testing Tools Your Meter Display Your Meter Features Symptoms of High or Low Blood Sugar Important Things to Know Before You Begin Testing Getting Ready to Test Getting the Blood Drop Testing Your Blood Set-up for Basic (L-1) and Advanced (L-2) Modes Setting the Date, Time and Sound Setting Advanced Mode (L-2) Features Using Advanced Mode...

  • Page 4: Your Testing Tools

    ® Your Meter: ONTOUR Display Up/Down Memory Button Scroll Buttons (On/Off, Memory Recall, Enter) Test Strip Port ® Your Test Strip: ONTOUR Gray End Insert this end into the test strip port. Sample Tip Blood sample pulled in here. ® Your Lancing Device: ICROLET...

  • Page 5: Your Meter Display

    Your Meter Display: The picture below shows all the symbols that appear on your meter display. To view, with the meter off, press and hold ▲ or ▼. All dis- play segments will appear for 10 seconds. If you need more than 10 seconds to check the display, press and hold ▲...

  • Page 6: Your Meter Features

    Your Meter Features: ® Easy: The C blood glucose monitoring system is ONTOUR about simplicity. You will notice its uncomplicated approach the first time you see it. Simple things like the use of three large buttons and a clear display are sure to make this your favorite meter right from the start.

  • Page 7: Symptoms Of High Or Low Blood Sugar

    Symptoms of High or Low Blood Sugar: You can better understand your test results by being aware of the symptoms of high or low blood sugar. Some of the most common symptoms are:* High blood sugar Low blood sugar (Hyperglycaemia): (Hypoglycaemia): •...

  • Page 8: Important Things To Know

    Important Things to Know: Always keep the test strips in the original bottle. Tightly close the bottle immediately after remov- ing a test strip. The bottle is designed to keep the test strips dry. Exposure to room humidity from leaving the bottle open or not storing them in the original bottle can damage your test strips.

  • Page 9: Before You Begin Testing

    IMPORTANT NOTE: • Your meter has been preset and locked to display results in mmol/L (millimoles of glucose per liter). In some countries, the meters are preset to display units in mg/dL (milligrams of glucose per deciliter); • Results in mmol/L will always have a decimal point; •...

  • Page 10: Getting Ready To Test

    The following steps (pages 8–13) are shown in the proper order for performing a blood glucose test. Getting Ready to Test: ® Read the M 2 insert for complete instructions. ICROLET For testing sites other than fingertip, see page 28. Wash and dry your hands thoroughly before testing.
  • Page 11 Replace the endcap prior to getting your blood drop. Remove a test strip from the bottle. Tightly close the bottle lid immediately after you have removed the test strip. NOTE: Check the expiration and discard dates on the bottle. Make sure the test strip does not appear torn or damaged. Hold the test strip with the gray end facing up.

  • Page 12: Getting The Blood Drop

    Getting the Blood Drop: The puncture depth Fingertip depends on the endcap testing—Use setting and the amount of the Gray endcap pressure applied to the puncture site. You will determine which combination works best for you. Shallow Deep Puncture Puncture Press the endcap firmly against the puncture site and press the blue release button...

  • Page 13: Testing Your Blood

    Testing Your Blood: Immediately touch the tip of the test strip to the drop of blood. The blood is pulled into the test strip through the tip. Hold the tip of the test strip in the blood drop until the meter beeps. Do not press the tip against the skin or place the blood on...
  • Page 14 You can set your meter to use special marker options by using Advanced Mode (L-2). See pages 18–23. Expected Values: Blood glucose values will vary depend- ing on food intake, medication dosages, health, stress, or exercise. Consult your healthcare professional for the target value that is appropriate for you.
  • Page 15 Removing the used lancet: In one hand, hold the lancing device with your thumb on the grip indent, with your other hand, hold the gray endcap dial as shown, and gently snap off the endcap. Place the round protective lan- cet cap on a flat surface with the Bayer logo facing down.

  • Page 16: Set-Up For Basic (L-1) And Advanced (L-2) Modes

    Set-up for Basic (L-1) and Advanced (L-2) Modes: ® Your new C meter is pre-set for the Basic Mode ONTOUR and offers the same easy test procedure in either the Basic or Advanced Mode. BASIC MODE (L-1) ADVANCED MODE (L-2) •...

  • Page 17: Setting The Date, Time And Sound

    Setting the Date, Time and Sound: Your C meter allows you to set the date, time, and ONTOUR sound as you like them. You can view 12 or 24 hour time; • month/day or day.month, and; • choose to have your meter beep or not. •...
  • Page 18 Setting the Month and Day Format: m/d will now flash on the display. Press ▲ or ▼ to select the format you wish (m/d for month/day format or d.m for day.month format). Press M to set. Setting the Date: The year will be flashing. Press ▲...
  • Page 19 Setting the Sound: The flashing bell symbol will now appear on the display along with the word “ ”. This option controls whether you want to hear the beep sound during testing. To turn the beep sound off during testing, press ▲ or ▼ to display “...

  • Page 20: Setting Advanced Mode (L-2) Features

    Setting Advanced Mode (L-2) Features: If you selected Advanced Mode (L-2 on your display) you can change your meter’s personal low and high blood glucose settings. By person- alizing these settings, your meter will help you ONTOUR track these HI and LO results. The LO setting will flash (default 4.0).

  • Page 21: Using Advanced Mode

    You have now completed your meter set-up for ONTOUR Advanced Mode! Using the Markers: If you have set-up your meter in Advanced Mode, your meter will display three markers after you test your blood. Pre-meal = Marks a test result that was taken before a meal.
  • Page 22 If you do not want to mark the test result: Remove the used test strip to automatically save the test result in the meter memory with no markers. Dispose of the used test strip and lancet properly. This will also turn the meter off.
  • Page 23 Using the Alarm: When the alarm sounds, the meter will automatically turn on. The alarm will beep 20 times, and the display will show the pre-meal test result you marked when you set the alarm. Pressing any button will silence the alarm. You can now run another test by placing a test strip in the test strip port and following the testing instructions (page 8).
  • Page 24 To Cancel an Alarm: When the meter is off, press M to turn on the meter. The date and time will appear along with the Press ▲ or ▼ two times and the alarm icon will disappear. Press M to cancel the alarm. After performing a test: TO MARK RESULTS YOU WILL SEE...
  • Page 25 YOU WILL SEE WHAT IT MEANS Result is marked as a pre-meal test. You can now set an alarm. Alarm is set to go off in the amount of time you have set (1.0 –2.5 hours) to remind you to run a post-meal test.

  • Page 26: Viewing Stored Results

    Viewing Basic Mode Results: Press M to turn your meter on. Press M again to view the memory. The 14 day average will appear in the center of the display with the number of results shown at the top of the display.
  • Page 27 When appears on the display, you have viewed all of the results in the memory. NOTES: • Averages include the specified time period plus the current day. • The meter will hold 480 results in the memory. When the maximum is reached, the oldest test result will be removed as a new test is completed and saved to the memory.
  • Page 28 Viewing Advanced Mode Results: In Advanced Mode (L-2), you have all of the options described in Basic Mode plus additional items available. Press M to turn your meter on. Briefly press M again to view the 14 day average in- cluding the number of results used to obtain the average.
  • Page 29 Press ▲ to view the 7 day average. You will see the average in the center of the display and the number of results along the top. Press ▲ to view the 30 day average. This will display the average in the center and the number of readings along the top.

  • Page 30: Alternative Site Testing (Forearm Or Palm)

    Alternative Site Testing (AST): Use AST only when it has been Alternative more than two hours after any one Site of the following: a meal, diabetes Testing — medication, or exercise. To receive Use the Clear endcap a clear AST endcap please call the Bayer Diabetes Care Helpline: 1-800-268-7200.
  • Page 31 For palm testing, For forearm it is not necessary to testing only, rub the skin or pump rub the testing the device. area vigorously until it feels warm to increase blood flow. Press the clear endcap firmly against the puncture site and then press the blue release Press the clear...

  • Page 32: Control Solution Testing

    Control Solution Testing: ® Use only Bayer’s C control solutions (Normal, ONTOUR Low, or High) to practice on the system or to run a check to make sure the meter and the test strips are working properly. Using anything other than C ONTOUR control solution could present incorrect results.
  • Page 33 NOTE: Gently rock the control bottle before opening to ensure it is mixed well. Squeeze a small drop of control solution on a clean nonabsorbent surface (such as a piece of wax paper). Do not apply control solution to the test strip directly from the bottle.
  • Page 34 Compare your control test result with the Normal Control Range printed on the test strip bottle label or on the bottom of the test strip box. NOTE: Low and High control range values can be found on the bottom of the test strip box.

  • Page 35: Transferring Results To A Computer

    Transferring Results to a Computer: You can transfer test results from the C meter to a ONTOUR computer, where they can be summarized in a report with graphs and tables. To make use of this feature, you need Bayer’s diabetes management software and a data cable from Bayer.

  • Page 36: Error Codes And Symbols

    Error Codes and Symbols: If you do not resolve the problem, contact Bayer WHAT YOU SEE WHAT IT MEANS WHAT YOU SHOULD DO Low batteries. Replace the batteries as soon as (will remain on possible. the display) Dead batteries. Replace the batteries. (will flash for 10 seconds and then the meter...
  • Page 37 Diabetes Care Helpline at 1-800-268-7200. WHAT YOU SEE WHAT IT MEANS WHAT YOU SHOULD DO Incorrect sensor Remove the test strip and retest type. using a new test strip. Make certain that you are using a ® test strip from Bayer. ONTOUR Invalid date or time.
  • Page 38 If you do not resolve the problem, contact Bayer Diabetes Care Helpline at 1-800-268-7200. WHAT YOU SEE WHAT IT MEANS WHAT YOU SHOULD DO Control test result • Test strip or control • Check all expiration dates and is out of range solution is past the discard dates.

  • Page 39: Changing The Batteries

    Changing the Batteries: Batteries should be replaced when the meter continually displays or the meter briefly shows and then turns off (See Error Codes and Symbols, page 34). Turn off your meter before changing your batteries. Press firmly on the battery cover and slide in the direction of the arrow.
  • Page 40 Place new batteries under the prongs and into the battery compartment with the “+” side up. Slide the battery cover back into place, lining up with the open slots, and close firmly. WARNING: Keep batteries away from children. Lithium batteries are poisonous. If swallowed, im- mediately contact your physician or poison control center.

  • Page 41: Caring For The System

    Caring for the System: • Store meter in the carrying case provided whenever possible. • Wash hands and dry them thoroughly before handling to keep the meter and test strips free of oils and other contaminants. • Handle the meter carefully to avoid damaging the electronics or causing other malfunctions.

  • Page 42: Technical Information

    Technical Information: ® Please refer to your C blood glucose test strip ONTOUR package insert or contact the Bayer Diabetes Care Helpline at 1-800-268-7200 for additional performance data. Need Help? Bayer Diabetes Care Helpline: 1-800-268-7200...

  • Page 43: Specifi Cations

    Potential Biohazard Healthcare professionals or persons using this sys- tem on multiple patients should follow the infection control procedure approved by their facility. All prod- ucts or objects which come in contact with human blood, even after cleaning, should be handled as if capable of transmitting viral diseases.

  • Page 44: Warranty

    Warranty: Important: Bayer Inc. (“Bayer”) has no knowledge of the perform- ® ance of the C blood glucose meter when used with any ONTOUR ® test strip other than C and therefore this warranty is ONTOUR ® invalid if the C meter is used with any test strip than the ONTOUR ®...
  • Page 45 THIS WARRANTY IS EXPRESSLY LIMITED TO THE METER AND MADE IN LIEU OF ANY AND ALL OTHER WARRANTIES EXPRESS OR IMPLIED (EITHER IN FACT OR BY OPERATION OF LAW) INCLUDING THE WARRANTIES OF MERCHANT- ABILITY AND FITNESS FOR USE WHICH ARE EXPRESSLY EXCLUDED, UNLESS PROHIBITED BY LAW, AND IS THE ONLY WARRANTY GIVEN BY BAYER.

  • Page 46: Service And Supplies

    Service Information: If you have a problem and none of the problem solving steps in this user guide help, call Bayer Diabetes Care Helpline at 1-800-268-7200. We have trained specialists to help you. Important: Speak to a Bayer Diabetes Care Helpline Representative before returning your meter for any reason.
  • Page 47 Supplies: When calling or writing for supplies be sure to include the num- ber with the name of the replacement part or accessory item. REPLACEMENT PARTS Part Number* Item 40030030 Two 3-volt Lithium Batteries DL2032 or CR2032 ® 99C71529 User Guide ONTOUR 40453276 Bayer’s Serial Data Cable...
  • Page 48 Manufactured for: Distributed by: Bayer HealthCare LLC Bayer Inc. Mishawaka, IN 46544 USA Toronto, Ontario M9W 1G6 Canada www.bayerdiabetes.ca Bayer and Bayer Cross are registered trademarks of Bayer AG, used under license by Bayer Inc. C ONTOUR No Coding logo and M are trademarks of ICROLET Bayer HealthCare LLC, used under license by Bayer Inc.
