2. Alternatively, go to Control Panel, select Programs, and
select Turn Windows features on or off. Wait until the list
gets populated. Then, Click the box next to Telnet Client.
When finished, follow steps 1a or 1b to open Command
Prompt and follow the same steps 2 and 3 from "Windows
XP users" instructions above.
Socket Connection
Socket connection is available for communication via Ethernet (LAN)
interface. The socket port is:
Socket Port: 5025
Users can use this port to open a raw socket connection for sending

remote commands.

4.2 Remote Commands
The instrument supports some SCPI commands and some
instrument specific commands. These commands enable a
computer to remotely communicate and control the power supply
over any of the supported remote interfaces: USB (virtual COM),
RS-232, GPIB, LAN, and RS-485 (specific subset only).
