Casablanca Ceiling Fan Owner's Manual

Hide thumbs Also See for Ceiling Fan:
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual , Installation Manual
™
C
O
'
M
APISTRANO
WNER
S
ANUAL
Casablanca
13

Advertisement

Table of Contents
loading

Related Manuals for Casablanca Ceiling Fan

Summary of Contents for Casablanca Ceiling Fan

  • Page 1 ™ ’ APISTRANO WNER ANUAL Casablanca...

  • Page 2: Safety First

    • This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling installations.

  • Page 3: Mounting Recommendations

    MOUNTING RECOMMENDATIONS Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air circulation, and fan size are all important factors to consider before installation. Location Ceiling fans have practical uses in almost every room in your home. We suggest you follow these mount- ing recommendations as you decide where to install your Casablanca fan.

  • Page 4: Preparation Instructions

    Casablanca PREPARATION INSTRUCTIONS Unpacking: Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them against the parts listed here. Before discarding packaging material, be certain that all parts have been removed. PERMA • LOCK™ HARDWARE LOCKING BOLT DOWNROD &...

  • Page 5: Crossbar Mounting Bracket Installation

    APISTRANO Casablanca CROSSBAR MOUNTING BRACKET INSTALLATION Proceed with installation as follows: CEILING FAN APPROVED Step 1. Route the wires from the ceiling outlet box through OUTLET BOX the crossbar mounting bracket center hole. Attach the bracket, with ground wire and ridges down, to the ceiling fixture out- let box with the mounting hardware included with the outlet box.

  • Page 6: Hanging The Fan

    APISTRANO Casablanca HANGING THE FAN Step 3. To hang the fan body in the canopy, hold the fan body firmly and in- sert the ball into the canopy opening. Check that no wires were pinched. Ro- tate the fan body until the slot in the ball fits into the pin opposite the canopy opening.
  • Page 7 APISTRANO Casablanca INSTALLING THE BLADE/BLADE HOLDER TO FAN MOTOR PREPARATION Step 8. To reach the blade holder mounting holes in the fan motor the dummy switch housing must be removed. Take out the two 5-32 X ” screws secur- ing the dummy switch housing and remove.

  • Page 8: Blade Installation

    APISTRANO Casablanca BLADE INSTALLATION Step 10. Attach each blade to a blade holder securing it with the four blade screws provided. Using the screwdriver, tighten securely BLADE SCREW by hand only. (4 PER BLADE) BLADE BLADE HOLDER REMOVE SHIPPING BLOCKS Step 11.

  • Page 9: Completing Installation

    APISTRANO Casablanca COMPLETING INSTALLATION SWITCH HOUSING SWITCH HOUSING MOUNT SCREW (REMOVED IN STEP 8) 5-32 X ASSEMBLY PREPARATION SWITCH HOUSING Step 13. Locate the switch housing/cap CONNECTOR SWITCH assembly and remove the two 8-32 X (SOCKET) HOUSING screws holding the cap onto the switch housing.
  • Page 10 APISTRANO Casablanca INSTALLING THE SWITCH HOUSING ASSEMBLY Step 15. Line up the two inner clear- ance holes in the cap with the two threaded holes in the switch mounting plate standoffs. CAUTION! Before continuing to the next step check that a wire or com- ponent inside the switch housing will not be pinched as it is installed.
  • Page 11 3-SPEED W-4/W-411 WALL CONTROL OF THE FAN • The W-4 allows the choice of four (4) different speed settings. • No light fixture is used. • Set the FAN pull chain switch to the HIGH speed setting. • No changes in household or fan wiring are required.

  • Page 12: Speed Operation

    3-SPEED OPERATION Pull-chain switches on the fan control the fan and lights. FAN & SPEED Using the fan control pull-chain switch: Fan off at start. CONTROL First pull: fan ON, low speed PULL CHAIN SWITCH Second pull: medium speed Third pull: high speed Fourth pull: fan OFF Using the optional light pull-chain switch: Light off at start.

  • Page 13: Troubleshooting

    Never Lubricate this Fan! should be used to prevent scratching the finish. A vacuum cleaner The precision motor at the heart of your Casablanca fan features brush nozzle can remove heavier dust. Surface smudges or an accu- sealed bearings that are lubricated for life. Do not attempt to oil mulation of dirt and dust can easily be removed by using a mild the motor.
  • Page 14 7 6 1 C • P , C A 9 1 7 6 8 • 8 0 0 - 7 5 9 - F A N S ( 3 2 6 7 ) O R P O R A T E E N T E R R I V E O M O N A...
