LED L P I
IGHT ATTERN NDICATION
Following tables show the LED light pattern indication. The LED shows PHONE1 status only.
T 6: HT–496 LED Definitions
ABLE
RED LED indicates not normal status
Button flashes every 2 seconds.
(if DHCP is configured)
Button flashes every 2 seconds.
(if SIP server is configured)
Button flashes every 2 seconds.
Red light steady.
GREEN LED indicates normal status
Button flashes every 2 seconds.
Button flashes at 1/10 second.
Button flashes every second.
Green light steady.
Grandstream Networks, Inc.
VoIPon www.voipon.co.uk
DHCP Failed or WAN No Cable
HT–496fails to register
Firmware Upgrading
Device Malfunctions
Message Waiting Indication
RINGING
RINGING INTERVAL
In Conversation
