Grandstream Networks HT801 Administration Manual

Analog telephone adaptors
Hide thumbs Also See for HT801:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Grandstream Networks, Inc.
HT801/HT802
Analog Telephone Adaptors
Administration Guide

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks HT801

Summary of Contents for Grandstream Networks HT801

  • Page 1 Grandstream Networks, Inc. HT801/HT802 Analog Telephone Adaptors Administration Guide...
  • Page 2 Grandstream Networks, Inc. is not permitted. The latest electronic version of this user manual is available for download here: http://www.grandstream.com/support Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc. in the United States, Europe and other countries. CAUTION Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other than as detailed by this User Manual, could void your manufacturer warranty.

  • Page 3: Gnu Gpl Information

    GNU GPL INFORMATION HT801/HT802 firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license.

  • Page 4: Table Of Contents

    Connecting HT801/HT802 ........................15 HT801/HT802 LEDs Pattern ........................ 15 CONFIGURATION GUIDE .................... 17 Obtain HT801/HT802 IP Address via Connected Analogue Phone............. 17 Understanding HT801/HT802 Interactive Voice Prompt Response Menu .......... 17 Configuration via Web Browser ......................19 Accessing the Web UI ........................19 Web UI Access Level Management ....................
  • Page 5 Status Page Definitions ........................ 22 Basic Settings Page Definitions ....................23 Advanced Settings Page Definitions .................... 24 FXS Port for HT801 and Port (1,2) for HT802 Pages Definitions ..........29 NAT Settings ............................41 DTMF Methods ............................ 41 Preferred Vocoder (Codec) ........................42 Configuring HT801/HT802 Through Voice Prompts ................
  • Page 6 Table of Tables Table 1: HT801/HT802 Features at a Glance ..................... 10 Table 2: HT801/HT802 Technical Specifications ..................11 Table 3: Definition of the HT801/HT802 Connectors .................. 14 Table 4: HT801/HT802 LEDs Pattern Description ..................16 Table 5: Voice Prompt Menu ........................17 Table 6: Status Page Definitions .........................

  • Page 7: Document Purpose

    DOCUMENT PURPOSE This document describes the basic concept and tasks necessary to use and configure your HT801/HT802. And it covers the topic of connecting and configuring the HT801/HT802, making basic operations and the call features. Please visit http://www.grandstream.com/support to download the latest “HT801/HT802 User Guide”.

  • Page 8: Change Log

    CHANGE LOG This section documents significant changes from previous versions of administration guide for HT801/HT802. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. Firmware Version 1.0.3.2 •...

  • Page 9: Gui Interface Examples

    1. Screenshot of Login Page. 2. Screenshots of Status Page. 3. Screenshots of Basic Settings Page. 4. Screenshots of Advanced Settings Page. 5. Screenshots of FXS Port 1 Page. 6. Screenshots of FXS Port 2 Page. P a g e HT801/HT802 Administration Guide...

  • Page 10: Welcome

    The HT801/HT802 analog telephone adaptors provide transparent connectivity for analog phones and faxes to the world of internet voice. Connecting to any analog phone, fax or PBX, the HT801/HT802 are an effective and flexible solution for accessing internet-based telephone services and corporate intranet systems across established LAN and internet connections.

  • Page 11: Product Overview

    PRODUCT OVERVIEW The HT801 is a one-port analog telephone adapter (ATA) while the HT802 is a 2-port analog telephone adapter (ATA) that allows users to create a high-quality and manageable IP telephony solution for residential and office environments. Its ultra-compact size, voice quality, advanced VoIP functionality, security protection and auto provisioning options enable users to take advantage of VoIP on analog phones and enables service providers to offer high quality IP service.

  • Page 12: Table 2: Ht801/Ht802 Technical Specifications

    Table 2: HT801/HT802 Technical Specifications Interfaces HT801 HT802 Telephone Interfaces One (1) RJ11 FXS port Two (2) RJ11 FXS ports. Network Interface One (1) 10/100Mbps auto-sensing Ethernet port (RJ45). POWER, INTERNET, PHONE1, POWER, INTERNET, PHONE LED Indicators PHONE2. Factory Reset Button Yes.
  • Page 13 Weight 102g 114g (without package). Compliance HT801 HT802 FCC Part15B EN55032, EN55024, 15B, AS/NZS CISPR22, EN61000-3-2, EN61000-3-3, AS/NZS60950, EN55022, EN55024, Compliance EN60950-1, AS/NZS CISPR22, EN60950, EN61000-3-2, EN61000-3- AS/NZS60950.1, S003 3, UL (Power supply). P a g e HT801/HT802 Administration Guide...

  • Page 14: Getting Started

    GETTING STARTED This chapter provides basic installation instructions including the list of the packaging contents and information for obtaining the best performance with the HT801/HT802. Equipment Packaging The HT801 ATA package contains: 1x HT801 1x 5V Power Adapter 1x Quick Installation Guide...

  • Page 15: Ht801/Ht802 Ports Description

    HT801/HT802 Ports Description The following figure describes the different ports on the back panel of the HT801. Internet Micro USB Phone Port Power DC (RJ-11 FXS Port) Figure 3: HT801 Back Panel The following figure describes the different ports on the back panel of the HT802.

  • Page 16: Connecting Ht801/Ht802

    HT802 Figure 5: Connecting the HT801/HT802 HT801/HT802 LEDs Pattern There are 3 LED buttons on HT801 and 4 LED buttons on HT802 that help you manage the status of your Handy Tone. Figure 6: HT801/HT802 LEDs Pattern P a g e...

  • Page 17: Table 4: Ht801/Ht802 Leds Pattern Description

    Table 4: HT801/HT802 LEDs Pattern Description LED Lights Status Power LED The Power LED lights up when the HT801/HT802 is powered on and it flashes when the HT802 is booting up The Ethernet LED lights up when the HT801/HT802 is connected to your Internet LED network through the Ethernet port and it flashes when there is data being sent or received.

  • Page 18: Configuration Guide

    Obtain HT801/HT802 IP Address via Connected Analogue Phone HT801/HT802 is by default configured to obtain the IP address from DHCP server where the unit is located. To know which IP address is assigned to your HT801/HT802, you should access to the “Interactive Voice...
  • Page 19 Automatically returns to main menu “Device not registered” This prompt will be played immediately after off hook If the device is not registered and the option “Outgoing Call without Registration” is in NO P a g e HT801/HT802 Administration Guide...

  • Page 20: Configuration Via Web Browser

    Configuration via Web Browser The HT801/HT802 embedded Web server responds to HTTP GET/POST requests. Embedded HTML pages allow a user to configure the HT801/HT802 through a web browser such as Google Chrome, Mozilla Firefox and Microsoft’s IE. Accessing the Web UI 1.

  • Page 21: Web Ui Access Level Management

    Update or Apply button on the bottom of the page. After submitting the changes in all the Web GUI pages, reboot HT801/HT802 to have the changes take effect if necessary; most of the options under the Advanced Settings and FXS Port (x) pages require reboot.

  • Page 22: Changing Http Web Port

    5. Press Apply at the bottom of the page to save your new settings. Figure 9: Web HTTP Port Web Configuration Pages Definitions This section describes the options in the HT801/HT802 Web UI. As mentioned, you can log in as an administrator or an end user. •...

  • Page 23: Status Page Definitions

    Core: Specifies Core version. Current is 1.0.3.2 • Base: Specifies Base version. Current is 1.0.3.2 • CPE: Specifies CPE version. CPE version is displayed only when HT801/HT802 is connected to an ACS using TR-069 protocol. Software Status Indicates actual software status.

  • Page 24: Basic Settings Page Definitions

    Customizes HTTP port used to access the HT801/HT802 web UI. Default is 80. Telnet Server Enables / Disables access via telnet. Default is Yes (activated). Specifies IP Address to use on HT801/HT802. There are three modes to operate the HT801/HT802: •...

  • Page 25: Advanced Settings Page Definitions

    Sets values for 802.1Q/VLAN Tag. Default is 0. Valid range is 0-4094. Layer 2 QoS SIP 802.1p. Default is 0. Valid range is 0-7. RTP 802.1p. Default is 0. Valid range is 0-7. P a g e HT801/HT802 Administration Guide...
  • Page 26 Sets IP address or FQDN of configuration server. The URL of the server that hosts the Config Server Path configuration file to provision HT801/HT802. Default is fm.grandstream.com/gs. XML Config File Decrypts XML configuration file when encrypted. The password used for encrypting the Password XML configuration file using OpenSSL.
  • Page 27 (0-6)”. (Day of week is starting from Sunday). Default is No. Configures the HT801/HT802 to always search for the new firmware at boot up. During Always Check for the boot stage, the HT801/HT802 will contact the firmware upgrade server to search for...
  • Page 28 Enable Periodic Inform Sets frequency that the inform packets will be sent out to ACS. Interval Connection Enters username for ACS to connect to the HT801/HT802. Request Username Connection Enters password for ACS to connect to the HT801/HT802. Request Password CPE SSL Configures the Cert File for the phone adapter to connect to the ACS via SSL.
  • Page 29 Obtains NTP server address from a DHCP server using DHCP Option 42; it will Allow DHCP Option override configured NTP Server. If set to “No”, the HT801/HT802 will use configured 42 to NTP Server NTP server to synchronize time and date even if a NTP server is provided by DHCP server.

  • Page 30: Fxs Port For Ht801 And Port (1,2) For Ht802 Pages Definitions

    GS_LOG: [device MAC address] [error code] error message. Example: May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000] Ethernet link is up Configures the HT801/HT802 to send a replicate of the SIP packets on the syslog. Send SIP Log Default is No Download Device Downloads actual device configuration file in .xml format.
  • Page 31 Default is No. Specifies IP address or domain name of outbound Proxy, or media gateway, or session border controller. Used by HT801/HT802 for firewall or NAT penetration in different Outbound Proxy network environments. If symmetric NAT is detected, STUN will not work and only outbound proxy can correct the problem.
  • Page 32 DNS SRV will use first SRV instead of the registered IP. Indicates E.164 number in “From” header by adding “User=Phone” parameter or using “Tel:” in SIP packets, if the HT801/HT802 has an assigned PSTN Number. •...
  • Page 33 Local SIP Port Default value for FXS 1 is 5060 and 5062 for FXS 2. Defines the local RTP-RTCP port pair the HT801/HT802 will listen and transmit. It is the Local RTP Port HT801/HT802 RTP port for channel 0. The default value for FXS port is 5004.
  • Page 34 Default is No. Checks SIP User ID in the Request URI of incoming INVITE; if it doesn't match the Check SIP User ID HT801/HT802 SIP User ID, the call will be rejected. Direct IP calling will also be for Incoming disabled.
  • Page 35 It is an estimate of the round-trip time between the client and server transactions. For example, the HT801/HT802 will attempt to send a request to a SIP server. The time it takes between sending out the request to the point of getting a response is the SIP SIP T1 Timeout T1 timer.
  • Page 36 Off Hook Auto Dial Specifies the auto-dial delay after off hook. Delay Determines a SIP Extension to notify the SIP server that the HT801/HT802 is behind a Proxy-Require NAT/Firewall. Defines NAT IP address used in SIP/SDP messages. It should only be used if required Use NAT IP by ITSP.
  • Page 37 Default is Yes. Dial Plan Rules: 1. Accept Digits: 1,2,3,4,5,6,7,8,9,0 , *, #, A,a,B,b,C,c,D,d Dial Plan 2. Grammar: x - any digit from 0-9; a. xx+ - at least 2 digits number; P a g e HT801/HT802 Administration Guide...
  • Page 38 An example dial plan will be: { *x+ } which allows the user to dial * followed by any length of numbers. Sends SUBSCRIBE periodically (depends on “Register Expiration” parameter) for SUBSCRIBE for message waiting indication. Default is No. P a g e HT801/HT802 Administration Guide...
  • Page 39 Uses INVITE message to refresh the session timer. Force INVITE Default is No. Appends “100rel” attribute to the value of the required header of the initial signaling Enable 100rel messages. Default is No. P a g e HT801/HT802 Administration Guide...
  • Page 40 Permits the unit to send out the re-INVITE for T.38 or Fax Pass Through if a fax tone is Tone Detection detected. Mode Default is Enabled Jitter Buffer Type Selects jitter buffer type (Fixed or Adaptive) based on network conditions. P a g e HT801/HT802 Administration Guide...
  • Page 41 Polarity Reversal Reverses the polarity upon call establishment and termination. Default is No. Allows the traditional PBX used with HT801/HT802 to apply this method for signaling Loop Current call termination. Method initiates short voltage drop on the line when remote (VoIP) side Disconnect disconnects an active call.

  • Page 42: Nat Settings

    IP address, set this parameter to No. 3. NAT traversal (under FXS web page): Set this to Yes when gateway is behind firewall on a private network. DTMF Methods The HT801/HT802 support the following DTMF mode: • DTMF in-audio •...

  • Page 43: Preferred Vocoder (Codec)

    Select voice menu option 01 to enable HT801/HT802to use DHCP. • STATIC IP MODE Select voice menu option 01 to enable HT801/HT802 to use STATIC IP mode, then use option 02, 03, 04, 05 to set up IP address, Subnet Mask, Gateway and DNS server respectively. •...

  • Page 44: Register A Sip Account

    Register a SIP Account The HT801/HT802 supports 2 FXS ports which can be configured with 2 SIP accounts. Please refer to the following steps in order to register your accounts via web user interface : 1. Access your HT801/HT802 web UI by entering its IP address in your favorite browser.

  • Page 45: Figure 10: Sip Accounts Settings

    After applying your configuration, your account will register to your SIP Server, you can verify if it has been correctly registered with your SIP server from your HT801/HT802 web interface under Status > Port Status > Registration (If it displays Registered, it means that your account is fully registered, otherwise it will display Not Registered so in this case you must double check the settings or contact your provider).

  • Page 46: Call Features

    Call Features The HT801/HT802 support all the traditional and advanced telephony features. Table 10: HT801/HT802 Call Features Call features Forcing a Codec (per call) *027110 (PCMU), *027111 (PCMA), *02723 (G723), *02729 (G729), *027201 (iLBC). Disable LEC (per call) Dial “*03” + ”number”.

  • Page 47: Rebooting Ht801/Ht802 From Remote

    Hook Pressing pound sign will serve as Re-Dial key. Rebooting HT801/HT802 from Remote Press the “Reboot” button at the bottom of the configuration menu to reboot the ATA remotely. The web browser will then display a message window to confirm that reboot is underway. Wait 30 seconds to log in again.

  • Page 48: Upgrading And Provisioning

    UPGRADING AND PROVISIONING The HT801/HT802 can be upgraded via TFTP/HTTP/HTTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. Configure a valid URL for TFTP or HTTP/HTTPS; the server name can be FQDN or IP address.

  • Page 49: Upgrading Via Local Directory

    1. Download the firmware file from Grandstream web site; 2. Unzip it and copy the file in to a folder in your PC; 3. From the HT801/HT802 web interface (Advanced Settings page) you can browse your hard drive and select the folder you previously saved the file (HT802fw.bin);...

  • Page 50: Managing Firmware And Configuration File Download

    Password. For a detailed parameter list, please refer to the corresponding firmware release configuration template. When the HT801/HT802 boots up or reboots, it will send a request to download a file named "cfgxxxxxxxxxxxx” followed by a configuration XML file named "cfgxxxxxxxxxxxx.xml", where "xxxxxxxxxxxx"...

  • Page 51: Restore Factory Default Settings

    To reset default factory settings using the reset button please follow the steps above: 1. Unplug the Ethernet cable. 2. Locate the reset hole on the back panel of your HT801/HT802. 3. Insert a pin in this hole, and press for about 7 seconds.

  • Page 52: Reset From Web Interface (Reset Type)

    For example: if the MAC address is 000b8200e395, it should be keyed in as “0002228200333395”. Reset from Web Interface (Reset Type) 1. Access your HT801/HT802 UI by entering its IP address in your favorite browser. 2. Enter your admin password (default: admin).

  • Page 53: Experiencing Ht801/Ht802

    Thank you again for purchasing Grandstream analogue telephone adapter, it will be sure to bring convenience to both your business and personal life. P a g e HT801/HT802 Administration Guide...
