Appendix D – DC Power Specifications
D.1
DC Power Source
Input voltage:
Minimum voltage:
Maximum voltage:
Maximum operating current:
Maximum input surge current:
The DC power source must be:
electrically isolated from any AC source
reliably connected to earth
capable of providing up to 100 Watts of continuous power
D.2
Overcurrent Protection
Overcurrent protection requirements:
10 Amp trip
double pole
fast trip
DC rated
Overcurrent protection devices (e.g., circuit breakers) must be provided as
part of each equipment rack, and are not included with the ConsoleServer.
The device must be located between the DC power source and the
ConsoleServer.
D.3
DC Supply Connector
The supply input connectors are provided with each ConsoleServer. However,
the conductors are not. See below for conductor specifications.
Conductor material:
Wire gauge:
Insulation rating:
Branch circuit cable insulation color:
-48 VDC
-40 VDC
-60 VDC
1.5 A
5 A
copper only
16 AWG
75°C minimum, low smoke fume,
flame retardant
per applicable national electrical
codes
60
