Supero SUPERSERVER 6017R-TDF User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
S
S
UPER
ERVER
6017R-TDF
USER'S MANUAL
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPERSERVER 6017R-TDF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supero SUPERSERVER 6017R-TDF

Summary of Contents for Supero SUPERSERVER 6017R-TDF

  • Page 1 UPER ® UPER ERVER 6017R-TDF USER’S MANUAL...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 6017R-TDF. Installation and maintenance should be performed by experienced technicians only. The SuperServer 6017R-TDF is a high-end server based on the SC813TS-441CBP 1U rackmount chassis and the Super X9DRD-iF serverboard.
  • Page 4 You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6017R-TDF. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRD-iF serverboard, including the locations and functions of connections, headers and jumpers.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 6017R-TDF User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SATA ........................ 1-2 I/O Ports ......................1-2 Onboard Graphics ................... 1-2 Server Chassis Features ................1-3 System Power ....................
  • Page 7 Table of Contents Control Panel LEDs ..................3-2 Overheat/Fan Fail ................... 3-2 NIC1 ........................ 3-2 NIC2 ........................ 3-2 HDD ......................... 3-2 Power ......................3-3 Hard Drive Carrier LEDs ................. 3-3 Chapter 4 System Safety Electrical Safety Precautions ................4-1 General Safety Precautions ................4-2 ESD Precautions .....................
  • Page 8 UPER ERVER 6017R-TDF User's Manual Control Panel ....................6-2 System Fans ....................6-3 System Fan Failure ..................6-3 Drive Bay Installation/Removal ............... 6-5 Removing the Front Bezel ................6-5 Accessing the Drive Bays ................6-5 SATA Drive Installation ..................6-6 SATA Power Cables ...................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 6017R-TDF is a high-end server comprised of two main subsys- tems: the SC813TS-441CBP 1U chassis and the X9DRD-iF serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 10: Serverboard Features

    ERVER 6017R-TDF User's Manual Serverboard Features At the heart of the SuperServer 6017R-TDF lies the X9DRD-iF, a dual processor serverboard based on Intel's C600 chipset. Below are the main features of the X9DRD-iF (see Figure 1-1 for a block diagram of the chipset).

  • Page 11: Server Chassis Features

    Chapter 1: Introduction Server Chassis Features The following is a general outline of the main features of the SC813TS-441CBP chassis. System Power The SC813TS-441CBP chassis includes a single 440-480W power supply. Power must be removed from the system when removing the power supply. See Chapter 6 for details.
  • Page 12 UPER ERVER 6017R-TDF User's Manual Figure 1-1. Intel C600 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. (C,D) (A,B) (C,D) (A,B) (A,B) (A,B) (C,D) (A,B) (A,B) (C,D) PROCESSOR 2 (right) PROCESSOR 1 (left) W25Q128 PEG0 [0..3] AHCI...

  • Page 13: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 14 UPER ERVER 6017R-TDF User's Manual Notes...

  • Page 15: Chapter 2 Server Installation

    Precautions in the next section. Preparing for Setup The box the SuperServer 6017R-TDF was shipped in should include two sets of rail assemblies, six rail mounting brackets and the mounting screws you will need to install the system into the rack. Follow the steps in the order given to complete the installation process in a minimal amount of time.

  • Page 16: Choosing A Setup Location

    UPER ERVER 6017R-TDF User's Manual Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for suffi cient airfl ow and ease in servicing.This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like).

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation • Allow the hot plug SATA drives and power supply modules to cool before touch- ing them. • Always keep the rack's front door and all panels and components on the servers closed when not servicing to maintain proper cooling. Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera-...

  • Page 18: Rack Mounting Instructions

    UPER ERVER 6017R-TDF User's Manual Rack Mounting Instructions This section provides information on installing the SC813TS-441CBP chassis into a rack unit. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 19: Inner Rail Extension

    Chapter 2: Server Installation Figure 2-2. Identifying the Sections of the Rack Rails (right side rail shown) Inner Rail Extension SC813TS-441CBP chassis includes a set of inner rails which are in two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the cha`sis if you decide not to use a server rack.
  • Page 20 UPER ERVER 6017R-TDF User's Manual Secure to the Front of the Rack Secure to the Rear of the Rack Attach the Two Sections of the Outer Rail Together Figure 2-3. Assembling the Outer Rails Installing the Outer Rails to the Rack 1.
  • Page 21 Chapter 2: Server Installation Figure 2-4. Installing the Outer Rails to the Server Rack...
  • Page 22 UPER ERVER 6017R-TDF User's Manual Figure 2-5. Installing the Rack Rails Installing the Chassis into a Rack 1. Confi rm that chassis includes the inner rails (A) and rail extensions (B). Also, confi rm that the outer rails (C) are installed on the rack. 2.

  • Page 23: Installing The Chassis Into A Telco Rack

    Chapter 2: Server Installation Installing the Chassis into a Telco rack To install the chassis into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack.
  • Page 24 UPER ERVER 6017R-TDF User's Manual Notes 2-10...

  • Page 25: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the hard drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi...

  • Page 26: Control Panel Leds

    UPER ERVER 6017R-TDF User's Manual Control Panel LEDs The control panel located on the front of the SC813TS-441CBP chassis has fi ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 27: Power

    Chapter 3: System Interface Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Hard Drive Carrier LEDs Each drive carrier has two LEDs. • Green: When illuminated, the green LED on the drive carrier indicates drive activity.
  • Page 28 UPER ERVER 6017R-TDF User's Manual Notes...

  • Page 29: Chapter 4 System Safety

    System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6017R-TDF from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 30: General Safety Precautions

    UPER ERVER 6017R-TDF User's Manual • This product may be connected to an IT power system. In all cases, make sure that the unit is also reliably connected to Earth (ground). • Serverboard Battery: CAUTION - There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 4-1).

  • Page 31: Esd Precautions

    Chapter 4: System Safety • Remove any jewelry or metal objects from your body, which are excellent metal conductors that can create short circuits and harm you if they come into contact with printed circuit boards or areas where power is present. •...

  • Page 32: Operating Precautions

    UPER ERVER 6017R-TDF User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6017R- TDF is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed. Figure 4-1.

  • Page 33: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X9DRD-iF serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 34: Processor And Heatsink Installation

    UPER ERVER 6017R-TDF User's Manual Processor and Heatsink Installation Notes: • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components. Make sure that you install the processor into the CPU socket before you install the CPU heatsink. •...
  • Page 35 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate fi...
  • Page 36 UPER ERVER 6017R-TDF User's Manual Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU.

  • Page 37: Installing A Passive Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the serverboard and the heatsink bracket underneath.

  • Page 38: Connecting Cables

    UPER ERVER 6017R-TDF User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfi...

  • Page 39: I/O Ports

    Chapter 5: Advanced Serverboard Setup All JF1 wires have been bundled into single keyed ribbon cable to simplify their con- nection. Connect one end of this cable to JF1 and the other end to the Control Panel printed circuit board, located just behind the system status LEDs in the chassis. See the Connector Defi...

  • Page 40: Installing Memory

    UPER ERVER 6017R-TDF User's Manual Installing Memory Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with slots DIMM1A.
  • Page 41 Chapter 5: Advanced Serverboard Setup Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 P1-DIMMD1 CPU2 P2-DIMME1 P2-DIMMF1 P2-DIMMG1 P2-DIMMH1 Processor and Memory Module Population Number of CPU and Memory Population Confi guration Table CPUs+DIMMs (For optmnal performance, install DIMMs in pairs) 1 CPU &...

  • Page 42: Adding Pci Cards

    UPER ERVER 6017R-TDF User's Manual Adding PCI Cards PCI Expansion Slots One RSC-RR1U-E16 riser card is used to support a standard size expansion (add- on) card to the system. PCI Card Installation Before installing a PCI add-on card, make sure it is supported by the riser card. Begin by releasing the locking tab that corresponds to the slot you wish to populate.

  • Page 43: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-5. SUPER X9DRD-iF Layout USB2/3 USB0/1 COM2 JUIDB COM1 USB6 BMC CTRL FAN7 LAN2 LAN1 FAN8 LAN CTRL IPMI_LAN JPG1 JPB1 CTRL CLK CTRL JI2C1 JI2C2 X9DRD-iF Rev. 1.02 JBAT1 JITP1 JBT1 CPU2 BIOS CPU1...
  • Page 44 UPER ERVER 6017R-TDF User's Manual Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 C1/JI SMB to PCI-E Slots Off (Disabled) JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled) JWD1 Watch Dog Timer Enable/Disable Pins 1-2 (Reset)

  • Page 45: Connector Defi Nitions

    Chapter 5: Advanced Serverboard Setup Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions (JPW1) Pin# Defi nition Pin # Defi nition Power Connectors +3.3V +3.3V A 24-pin main power supply connector -12V +3.3V (JPW1), two 8-pin CPU power con- nectors (JPW2/3) and one 4-pin power PS_ON connectors (JPW5) are located on the...
  • Page 46 UPER ERVER 6017R-TDF User's Manual NIC1/NIC2 LED Indicators NIC1/2 LED Pin Defi nitions (JF1) The NIC (Network Interface Controller) Pin# Defi nition LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and the LED NIC 2 LED connection for LAN Port 2 is on pins 9 and 10.
  • Page 47 Chapter 5: Advanced Serverboard Setup Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily Power Button contacting both pins will power on/off the Pin Defi nitions (JF1) system. This button can also be confi g- Pin# Defi...
  • Page 48 UPER ERVER 6017R-TDF User's Manual LAN Port Pin Defi nitions Ethernet Ports Pin# Defi nition Two Ethernet ports (LAN1/LAN2) are TD0+ located next to the VGA port on the I/O Vcc19-LAN back panel. An IPMI Dedicated LAN port TD3+ Link 100 LED is also located above the USB0/1 ports.
  • Page 49 Chapter 5: Advanced Serverboard Setup Fan Headers The X9DRD-iF has eight fan headers (Fan1 ~ Fan8). These are all 4-pin fan headers, however pins 1-3 are backward Fan Header compatible with traditional 3-pin fans. Pin Defi nitions A fan speed control setting in the BIOS Pin# Defi...
  • Page 50 UPER ERVER 6017R-TDF User's Manual TPM/Port 80 Header Pin Defi nitions Trusted Platform Module Header Pin # Defi nition Pin # Defi nition The JTPM1 header is used to connect a LCLK Trusted Platform Module (TPM), available LFRAME# <(KEY)> separately from a third-party vendor. A LRESET# +5V (X) TPM is a security device that allows en-...
  • Page 51 Chapter 5: Advanced Serverboard Setup T-SGPIO 0/1 Headers Serial_Link-SGPIO Two T-SGPIO (Serial-Link General Pin Defi nitions Purpose Input/Output) headers are Pin# Defi nition Defi nition located near the SATA connectors on the serverboard. These headers are Ground DATA Out used to communicate with the enclosure Load Ground management chip in the system.

  • Page 52: Jumper Settings

    UPER ERVER 6017R-TDF User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used to choose between Connector optional settings. Jumpers create shorts Pins between two pins to change the function of the connector. Pin 1 is identifi ed with Jumper a square solder pad on the printed circuit board.
  • Page 53 Chapter 5: Advanced Serverboard Setup PCI Slot SMB Enable PCI Slot SMB Enable/Disable Use Jumpers JI C1/JI C2 to enable PCI Jumper Settings SMB (System Management Bus) support Jumper Setting Defi nition to improve system management for the Closed Enabled PCI slots.

  • Page 54: 5-10 Onboard Indicators

    UPER ERVER 6017R-TDF User's Manual 5-10 Onboard Indicators LAN1/LAN2 LEDs LAN LED Each Ethernet port has two LEDs. The Connection Speed Indicator yellow LED indicates activity when blink- LED State Defi nition ing while the other LED may be green, No connection or 10 Mb/s amber or off to indicate the speed of the Green...

  • Page 55: 5-11 Sata Drive Ports

    Chapter 5: Advanced Serverboard Setup 5-11 SATA Drive Ports SATA Port Pin Defi nitions (SATA0 ~ SATA5) SATA Ports/SCU Connectors Pin # Defi nition There are four SATA 2.0 (SATA2~SATA5) Ground and two SATA 3.0 (SATA0 -1) por ts located on the X9DRD-iF. In addition, four SCU connectors (SCU0~3) are also Ground provided on the board.

  • Page 56: 5-12 Installing Drivers

    UPER ERVER 6017R-TDF User's Manual 5-12 Installing Drivers After all the hardware and operating system have been installed, you need to install certain drivers. The necessary drivers are all included on the Supermicro CD that came packaged with your serverboard. After inserting this CD into your CD-ROM drive, the display shown in Figure 5-6 should appear.

  • Page 57: Superdoctor Iii

    Chapter 5: Advanced Serverboard Setup SuperDoctor III ® The SuperDoctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program included on the CD-ROM that came with your serverboard allows you to monitor the environment and operations of your system.
  • Page 58 UPER ERVER 6017R-TDF User's Manual SuperDoctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User's Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend using SuperDoctor II. 5-26...

  • Page 59: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform main- tenance on the SC813TS-441CBP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 60: Control Panel

    UPER ERVER 6017R-TDF Manual Figure 6-1. Chassis: Front and Rear Views Slim Floppy Drive System LEDs Control Panel Slim CD-ROM Drive SATA Drive Bays System Reset Main Power Power Supply Module Dedicated IPMI LAN VGA Port PCI Expansion Slot COM Port USB Ports LAN Ports Control Panel...

  • Page 61: System Fans

    Chapter 6: Advanced Chassis Setup System Fans Two 10-cm blower fans provide all the cooling needed for the SuperServer 6017R- TDF. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.
  • Page 62 UPER ERVER 6017R-TDF Manual Figure 6-2. Accessing the Inside of the System Release buttons Figure 6-3. Removing System Cooling Fans...

  • Page 63: Drive Bay Installation/Removal

    Chapter 6: Advanced Chassis Setup Drive Bay Installation/Removal Removing the Front Bezel If your system has the optional front bezel attached to the chassis, you must fi rst remove it to gain access to the drive bays. 1. First unlock the front of the chassis then press the release knob (see Figure 6-4).

  • Page 64: Sata Drive Installation

    UPER ERVER 6017R-TDF Manual SATA Drive Installation The SATA drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airfl ow for the Serial ATA drive bays. For this reason, even empty carriers without drives installed must remain in the chassis.

  • Page 65: Sata Power Cables

    Chapter 6: Advanced Chassis Setup Figure 6-6. Mounting a SATA Drive in a Carrier SATA Power Cables Serial ATA power cables should be routed so that they do not block the airfl ow through the chassis. See the serverboard layout diagram for the location of the cable connections.

  • Page 66: Cd-Rom And Floppy Drive Installation

    UPER ERVER 6017R-TDF Manual CD-ROM and Floppy Drive Installation The top cover of the chassis must be opened to gain full access to the CD-ROM and fl oppy drive bays. The 6017R-TDF accomodates only slim CD-ROM drives. Side mounting brackets are needed to mount a slim CD-ROM drive in the 6017R- TDF server.

  • Page 67: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply The SuperServer 6017R-TDF has a single 440-480 watt power supply, which is auto-switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. Power Supply Failure If the power supply unit fails, the system will shut down and you will need to replace the unit.
  • Page 68 UPER ERVER 6017R-TDF Manual Figure 6-7. Removing/Replacing the Power Supply Note: power supply shown may be different than the model included in the 6017R- TDF. 6-10...

  • Page 69: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X9DRD-iF. It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. Starting BIOS Setup Utility To enter the AMI BIOS Setup utility screens, press the <Del>...

  • Page 70: Starting The Setup Utility

    UPER ERVER 6017R-TDF User's Manual Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re- covery User Guide posted @http://www.supermicro.com/support/manuals/. Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <F2> key to enter the main menu of the AMI BIOS Setup utility.
  • Page 71 Chapter 7: BIOS The AMI BIOS main menu displays the following information: System Date This item displays the system date in Day MM/DD/YY format (e.g. Wed 10/12/2011). System Time This item displays the system time in HH:MM:SS format (e.g. 15:32:52). Supermicro X9DRD-iF Version This item displays the SMC version of the BIOS ROM used in this system.

  • Page 72: Advanced Setup Confi Gurations

    UPER ERVER 6017R-TDF User's Manual Advanced Setup Confi gurations Use the arrow keys to select Advanced Setup and press <Enter> to access the following submenu items. Boot Features Quiet Boot This feature allows the user to select bootup screen display between POST mes- sages and the OEM logo.
  • Page 73 Chapter 7: BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 74 UPER ERVER 6017R-TDF User's Manual • CPU Stepping • Maximum CPU Speed • Minimum CPU Speed • Processor Cores • Intel HT (Hyper-Threading) Technology • Intel VT-x Technology • Intel SMX Technology • L1 Data Cache • L1 Code Cache •...
  • Page 75 Chapter 7: BIOS Limit CPUID Maximum This feature allows the user to set the maximum CPU ID value. Enable this function to boot the legacy operating systems that cannot support processors with extended CPUID functions. The options are Enabled and Disabled (for the Windows OS). Execute-Disable Bit (Available if supported by the OS &...
  • Page 76 UPER ERVER 6017R-TDF User's Manual Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent parti- tions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.
  • Page 77 Chapter 7: BIOS CPU C6 Report (Available when Power Technology is set to Custom) Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to the operating system. During the CPU C6 State, the power to all cache is turned off.

  • Page 78: North Bridge

    UPER ERVER 6017R-TDF User's Manual Short Duration Power Limit This item displays the time period during which short duration power is main- tained. Chipset Confi guration North Bridge This feature allows the user to confi gure the settings for the Intel North Bridge. Integrated IO Confi...
  • Page 79 Chapter 7: BIOS CPU1 Slot5 PCI-E 3.0 x8 Link Speed This feature allows the user to set the PCI-Exp bus speed for the slot specifi ed above. The options are Gen1 (Generation 1), Gen2 and Gen3. IIO 2 PCIe Port Bifurcation Control This submenu confi...
  • Page 80 UPER ERVER 6017R-TDF User's Manual Mirroring This item displays if memory mirroring is supported by the motherboard. Memory mirroring creates a duplicate copy of the data stored in the memory to enhance data security. Sparing This item displays if memory sparing is supported by the motherboard. Memory sparing enhances system performance.
  • Page 81 Chapter 7: BIOS Demand Scrub Demand Scrubbing is a process that allows the CPU to correct correctable memory errors found on a memory module. When the CPU or I/O issues a demand-read command, and the read data from memory turns out to be a correctable error, the error is corrected and sent to the requestor (the original source).
  • Page 82 UPER ERVER 6017R-TDF User's Manual Legacy USB Support (Available when USB Functions is not Disabled) Select Enabled to support legacy USB devices. Select Auto to disable legacy sup- port if USB devices are not present. Select Disable to have USB devices available for EFI (Extensive Firmware Interface) applications only.
  • Page 83 Chapter 7: BIOS Aggressive Link Power Management Select Enabled to enable Aggressive Link Power Management support for Cougar Point B0 stepping and beyond. The options are Enabled and Disabled. Port 0~5 Hot Plug Select Enabled to enable hot-plug support for a particular port, which will allow the user to change a hardware component or device without shutting down the system.
  • Page 84 UPER ERVER 6017R-TDF User's Manual PCIe/PCI/PnP Confi guration PCI ROM Priority Use this feature to select the Option ROM to boot the system when there are mul- tiple Option ROMs available in the system. The options are EFI Compatible ROM and Legacy ROM.
  • Page 85 Chapter 7: BIOS CPU1 Slot 3 PCI-E 3.0 x8 OPROM/CPU1 Slot 4 PCI-E 3.0 x8 OPROM/CPU1 Slot 5 PCI-E 3.0 x8 OPROM/CPU2 Slot 6 PCI-E 3.0 x16 OPROM/CPU2 Slot 7 PCI-E 3.0 x8 OPROM Select Enabled to enable Option ROM support to boot the computer using a network interface from the slots specifi...

  • Page 86: Serial Port Console Redirection

    UPER ERVER 6017R-TDF User's Manual Change Settings Use this feature to set the optimal Environment_Control_Interface (PECI) setting for a serial port specifi ed. The default setting is Auto, which will allow the AMI BIOS to automatically select the best setting for the PECI platform. Device Mode Use this feature to select the desired mode for a serial port specifi...

  • Page 87: Console Redirection Settings

    Chapter 7: BIOS Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type This feature allows the user to select the target terminal emulation type for Con- sole Redirection.
  • Page 88 UPER ERVER 6017R-TDF User's Manual VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Enabled and Disabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.

  • Page 89: Tpm Enable Status

    Chapter 7: BIOS High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback, reducing the de- pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc- tion embedded in the CPU.
  • Page 90 UPER ERVER 6017R-TDF User's Manual Intel TXT (LT-SX) Confi guration Intel TXT (LT-SX) Hardware Support This feature indicates if the following hardware components support the Intel Trusted Execution Technology. CPU: TXT (Trusted Execution Technology) Feature Chipset: TXT (Trusted Execution Technology) Feature Intel TXT (LT-SX) Confi...
  • Page 91 Chapter 7: BIOS NIC Confi guration Link Speed Use this feature to change the link speed and duplex for the current port. The op- tions are AutoNeg, 10Mbps Half, 10Mbps Full, 100Mbps Half, and 100Mbps full. Blink LEDs This feature allows the user to specify the duration for LEDs to blink. The range is from 0 ~ 15 seconds.

  • Page 92: Event Logs

    UPER ERVER 6017R-TDF User's Manual Event Logs Use this feature to confi gure Event Log settings.  Change SMBIOS Event Log Settings This feature allows the user to confi gure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 93 Chapter 7: BIOS Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes, Next reset, and Yes, Every reset. When Log is Full Select Erase Immediately to immediately erase SMBIOS error event logs that ex- ceed the limit when the SMBIOS event log is full.

  • Page 94: Ipmi

    UPER ERVER 6017R-TDF User's Manual IPMI Use this feature to confi gure Intelligent Platform Management Interface (IPMI) settings.  System Event Log Enabling/Disabling Options SEL Components Select Enabled for all system event logging at bootup. The options are Enabled and Disabled. Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot.
  • Page 95 Chapter 7: BIOS Customize EFI Logging Options Log EFI Status Codes Select Enabled to log EFI (Extensible Firmware Interface) Status Codes, Error Codes or Progress Codes. The options are Enabled and Disabled. Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.

  • Page 96: Boot

    UPER ERVER 6017R-TDF User's Manual Boot This submenu allows the user to confi gure the following boot settings for the system. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot. The op- tions are Enabled, Disabled, and Auto.

  • Page 97: Security

    Chapter 7: BIOS Security This menu allows the user to confi gure the following security settings for the system. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3-characters to 8-characters long.

  • Page 98: Save & Exit

    UPER ERVER 6017R-TDF User's Manual Save & Exit This submenu allows the user to confi gure the Save and Exit settings for the system. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system confi...
  • Page 99 Chapter 7: BIOS Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.
  • Page 100 UPER ERVER 6017R-TDF User's Manual Notes 7-32...

  • Page 101: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 102 UPER ERVER 6017R-TDF User's Manual Notes...

  • Page 103: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors ® ® Dual Intel Xeon E5-2600 Series processors in LGA 2011 sockets Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C600 Memory Capacity Eight DIMM sockets that can support up to 256 GB of registered DDR3- 1600/1333/1066/800 RDIMM memory...
  • Page 104 UPER ERVER 6017R-TDF User's Manual System Cooling Two 10-cm blower fans System Input Requirements AC Input Voltage: 100-240V AC auto-range Rated Input Current: 5.5 - 4A (100-140V) to 3.5 - 2.5A (180-240V) Rated Input Frequency: 50 to 60 Hz Power Supply Rated Output Power: 440W (Part# PWS-441P-1H) Rated Output Voltages: +3.3V (15A), +5V (18A), +12V (38.8 at 100-140V, 39.1A at 180-240V), +5Vsb (3A)
  • Page 105 Appendix B: System Specifi cations Disclaimer (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
  • Page 106 UPER ERVER 6017R-TDF User's Manual Notes...
