INSTRUCTIONS-PARTS LIST
This manual contains IMPORTANT
WARNINGS and INSTRUCTIONS READ
AND RETAIN FOR REFERENCE
HYDRA-CLEAN 2245, 3035, 3040
Pressure Washer
P/N 800–062, Series B
P/N 800–063, Series B
2200 psi (152 bar) OPERA TING PRESSURE
2600 psi (179 bar) MAXIMUM WORKING PRESSURE
P/N 800–065, Series C
P/N 800–335, Series A
3000 psi (207 bar) OPERA TING PRESSURE
3400 psi (234 bar) MAXIMUM WORKING PRESSURE
GRACO INC. P.O. Box 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1989, GRACO INC.
308–501
Rev A
Supersedes
801–642 &
801–643

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hydra Clean 2245 and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco Hydra Clean 2245

  • Page 1 This manual contains IMPORTANT WARNINGS and INSTRUCTIONS READ AND RETAIN FOR REFERENCE HYDRA-CLEAN 2245, 3035, 3040 Pressure Washer P/N 800–062, Series B P/N 800–063, Series B 2200 psi (152 bar) OPERA TING PRESSURE 2600 psi (179 bar) MAXIMUM WORKING PRESSURE P/N 800–065, Series C...
  • Page 2 Read and understand all instruction manuals before operating equipment. FLUID INJECTION HAZARD General Safety This pressure washer generates very high fluid pressure. Spray from the gun, leaks or ruptured components can inject fluid through your skin and into your body and cause extremely serious bodily injury including the need for amputation.
  • Page 3: Chemical Compatibility

    HANDLE AND ROUTE HOSES CAREFULL Y. Do not pull on hoses to move the pressure washer. Do not use chemicals which are not compatible with the inner tube and cover of the hose. DO NOT expose Graco hose to temperatures above 200 (–40...
  • Page 4 Moving parts can pinch or amputate fingers or other body parts. KEEP CLEAR of moving parts when starting or operating the pressure washer. NEVER operate the pressure washer without all guards and interlocks installed and functioning. Follow the TERMS WARNING: Alerts user to avoid or correct conditions that could cause bodily injury.
  • Page 5: Installation

    INSTALLATION HIGH PRESSURE HOSE HOSE RACK CONNECTION INLET WATER CONNECTION 3/4” GARDEN HOSE Figure 1 Check for Shipping Damage The unit should be checked for any damage that may have occurred in shipping. Any damage should be noted and the carrier notified immediately. Set Up If you are using a downstream chemical injector, install it between the pump unloader and the high pressure hose,...
  • Page 6 8. ALWAYS observe the following CAUTIONS to avoid costly damage to the pressure washer. CAUTION DO NOT allow the pressure washer to idle for more than 10 minutes. Doing so may cause the recirculating water to overheat and damage the pump. T...
  • Page 7: Trigger Safety Latch

    5. Tip holding holes are provided on the chassis. CAUTION To avoid blowing the o–ring out of the quick coupler, due to the high pressure in the system, never operate the pressure washer without a tip securely mounted in the quick coupler. Figure 3 ALWAYS follow the...
  • Page 8: Shutdown, Flushing And Storage

    Pressure Relief Procedure Warning before proceeding. 1. If the pressure washer will be exposed to freezing temperatures, drain all water out of the pump. If it must be stored in freezing temperatures, flush the unit with a 50% anti–freeze solution. Relieve pressure.
  • Page 9: Troubleshooting Chart

    TROUBLESHOOTING CHART To reduce the risk of serious bodily injury, including fluid injection, splashing in the eyes or on the skin or injury from moving parts, always follow the Pressure Relief Procedure Warning before proceeding. PROBLEM Engine will not start No gasoline in fuel tank or carburetor.
  • Page 10: Parts Drawing

    PARTS DRAWING 800–062 & 800–063 Hydra–Clean 2245 Pressure Washer 71 69...
  • Page 11: Parts List

    PARTS LIST 800–062 & 800–063 Hydra–Clean 2245 Pressure Washer PART DESCRIPTION 801–494 ENGINE, 11 HP, Briggs & Stratton I/C (For 800–063 only) 801–283 ENGINE, 11 HP, Wisconsin Robin (For 800–062 only) 800–326 PUMP ASSEMBLY, 2200 psi (see page 18) 800–067 CHASSIS 801–539...
  • Page 12 PARTS DRAWING 800–065 Hydra–Clean 3035 Pressure Washer 71 69...
  • Page 13 PARTS LIST 800–065 Hydra–Clean 3035 Pressure Washer PART DESCRIPTION 801–283 ENGINE, 11 HP, Wisconsin Robin 800–327 PUMP ASSEMBLY, 3000 psi (see page 14) 800–067 CHASSIS 801–539 BUMPER 801–541 HANDLE 801–556 AXLE 801–550 WHEEL & TIRE ASSEMBLY 800–160 FRONT LEG ASSEMBLY 801–531...
  • Page 14 PARTS DRAWING 800–335 Hydra–Clean 3040 Pressure Washer 71 69...
  • Page 15 PARTS LIST 800–335 Hydra–Clean 3040 Pressure Washer PART DESCRIPTION 803–158 ENGINE, 11 HP, Honda 800–327 PUMP ASSEMBLY, 3000 psi (see page 14) 800–067 CHASSIS 801–539 BUMPER 801–541 HANDLE 801–556 AXLE 801–550 WHEEL & TIRE ASSEMBLY 800–160 FRONT LEG ASSEMBLY 801–531 SCREW, Cap, hex hd 3/8–16 x 7...
  • Page 16 PARTS DRAWING 800–326 Pump Assembly, 2200 psi 800–327 Pump Assembly, 3000 psi...
  • Page 17 PARTS LIST 800–326 Pump Assembly, 2200 psi 800–327 Pump Assembly, 3000 psi REF PART NO. NO. DESCRIPTION 801–467 MANIFOLD, 2200 psi 801–647 MANIFOLD, 3000 psi 801–468 SCREW, Cap, hex hd 801–469 WASHER, Lock O–RING SEAT, Valve PLATE, Valve SPRING GUIDE, Valve O–RING VALVE ASSEMBLY 803–283...
  • Page 18: Pump Service

    PUMP SERVICE WARNING To reduce the risk of serious bodily injury including fluid injection, splashing in the eyes or on the skin, or injury from moving parts, always follow the Pressure Relief Procedure Warning before proceeding. NOTE: The following metric wrenches are needed: M10, M13 and M30.
  • Page 19: Technical Data

    801–666, 3035 uses 801–600, 3040 uses 803–107). ANTI–FREEZE FLUSH KIT 802–327 For flushing system with 50% anti–freeze solution prior to transporting or storing pressure washer in below freezing temperatures. INLET PRESSURE REGULATOR 800–258 Regulates inlet water pressure to 60 psi (4 bar) maximum.
  • Page 20 THE GRACO WARRANTY WARRANTY AND DISCLAIMERS Graco warrants all equipment manufactured by it and bearing its name to be free from defects in material and workmanship on the date of sale by an authorized Graco distributor to the original purchaser for use. As purchaser’s sole remedy for breach of this warranty, Graco will, for a period of twenty four months from date of sale, repair or replace any part of the equipment proven defective.
