Procom PCK110VT Owner's Manual page 22

MODELS PCK110VT, PCK160VT, PCK175VT AND PCK220VT
1
22
MOTOR AND PUMP ASSEMBLY
3
2
16
15
ITEM PART #
1 160001-01 Motor
2 160023-01 Rotor Insert
3 160003-01 Pump Rotor
4 160006-01 Pump Body
5 160088-01 Screw, 10-32 x .62
6 160007-01 Pump Cover
7 160009-01 Lint Filter
8 160008-01 Output Filter Assembly
9 160010-01 Intake Filter
10 160057-01 Filter End Cover
11 160106-01 Adjusting Screw
12 160024-01 Pipe Plug
13 160090-01 Screw, 10-32 x 1.0
14 160089-01 Screw, 10-32 x 1.12
15 160029-01 90° Nylon Elbow
16 160004-01 Pump Blade
PHOTOCELL ASSEMBLY
1
ITEM PART #
1 160041-03 Photocell Bracket
2 160092-02 Screw, 6-32 x .38
3 160016-01 Photocell Assembly
www.usaprocom.com
PARTS
4
5
6
7
14
DESCRIPTION
2
3
DESCRIPTION
8
9
10
11
12
13
QTY
1
1
1
1
2
1
1
1
1
1
1
1
3
6
1
4
QTY
1
2
1
160108-01B
