Summary of Contents for Zenoah EB4300
- Page 1 EB4300 115 39 99-73 (010) OWNER’S MANUAL BLOWER EB4300 GB-1...
-
Page 2: Table Of Contents
EB4300 SAFETY FIRST Contents Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken 1. Parts location ..........2 into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions 2. -
Page 3: Specifications
EB4300 2. Specification Model EB4300 Dimensions (LxWxH)** 335 x 454 x 495 Dry weight* Fuel tank capacity liter Engine type Air-cooled 2-cycle gasoline engine Piston displacement 41.5 Air filter Polyurethan form Carburetor Rotary valve type Ignition system C.D.I. Spark plug... -
Page 4: For Safe Operation
Operator’s manual. 10. Husqvar na Zenoah has a a) Keep your body warm. Never use policy of continuous product blower during rains. development and therefore re- b) Wear thick anti-vibration gloves. - Page 5 EB4300 5. For safe operation Limit the amount of time over 8. The ignition system of your unit which the product is to be used produces an electromagnetic continuously to somewhere field of a very low intensity. This around 30 ~ 40 minutes per ses-...
- Page 6 ZENOAH servic- ing dealer for assistance. Check- 6. The blower must not be used ing the fan is very important. If the while on a ladder or scaffolding.
- Page 7 5. When replacing the any other part, or any lubricant, always be sure to use only ZENOAH prod- ucts or products which have been certified by ZENOAH for use with the ZENOAH product.
-
Page 8: Set Up
EB4300 6. Set up BLOWER TUBES THROTTLE CABLEl 1. Connect the blower and swivel joint with the flexible • Use the band to fasten the colgate tube containing hose. Clamp both ends of the flexible hose securely the throttle cable and the power cable to the hose. -
Page 9: Fuel
2-cycle gasoline engine use. 2. Put fuel into the fuel tank to 80% of the full capacity. If Zenoah oil is not available, use an anti-oxidant added 3. Fasten the fuel cap securely and wipe up any fuel quality oil expressly labeled for air-cooled 2-cycle spillage around the unit. -
Page 10: Operation
EB4300 8. Operation 5. Once the engine is running, gradually open the choke STARTING ENGINE if it was set closed, and let the engine run at idle speed for a minute to warm it up. IMPORTANT • Avoid operating the blower with the flexible tube NOTE and swivel joint disconnected. -
Page 11: Maintenance
EB4300 9. Maintenance Maintenance, replacement, or repair of the emission control device and systems may be per- formed by any non-road engine repair establishment or individual. Daily Every Every Every System / Compronent Procedure 25 hours 50 hours 100 hours... - Page 12 EB4300 9. Maintenance SPARK PLUG • The spark plug may gather carbon deposits on its firing end with reasonable use. Remove and inspect the spark plug every 25 hours and clean the elec- trodes as necessary with a wire brush. The spark gap should be adjusted to .025 in (0.6~0.7mm).
-
Page 13: Storage
EB4300 HARNESS 9. Maintenance If the harness is damaged it may break during use, thus causing the product to fall and resulting in personal in- AIR INLET NET jury. Follow the instructions below to replace the harness with new one. -
Page 14: Troubleshooting Guide
→ clogged with dust → clean When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
