OWNER/OPERATOR MANUAL
MANUAL DEL PROPIETARIO/OPERADOR
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING
Before using our products, please
read this manual carefully to
understand the proper use of your
unit.
APPLICABLE SERIAL NUMBERS: 50804217 and up
BACKPACK BLOWER
SOPLADOR DE MOCHILA
EBZ8000/EBZ8000RH
ADVERTENCIA
Los gases de escape del motor de
este producto contienen sustancias
químicas conocidas por el Estado de
California como causantes de cáncer,
malformaciones en recién nacidos y
otros problemas de reproducción.
ADVERTENCIA
Antes de usar nuestros productos,
lea detenidamente este manual a fin
de familiarizarse con el uso correcto
de este aparato.
NÚMEROS DE SERIE APLICABLES: 50804217 y posteriores
848-L58-93A1 (605)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBZ8000/8000RH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zenoah EBZ8000/8000RH

Summary of Contents for Zenoah EBZ8000/8000RH

  • Page 1 OWNER/OPERATOR MANUAL MANUAL DEL PROPIETARIO/OPERADOR SOPLADOR DE MOCHILA EBZ8000/EBZ8000RH WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WARNING Before using our products, please read this manual carefully to understand the proper use of your unit.

  • Page 2: Table Of Contents

    English Contents SAFETY FIRST ………………………………………………3 WARNING LABELS ON THE MACHINE …………………4 SYMBOLS ON THE MACHINE ……………………………5 SAFETY PRECAUTIONS ……………………………………6 WORKING CONDITION WORKING CIRCUMSTANCE AVOID NOISE PROBLEM WORKING PLAN FUEL BEFORE STARTING THE ENGINE USING THE PRODUCT MAINTENANCE TRANSPORTATION STORAGE PARTS LOCATION …………………………………………13 SPECIFICATIONS …………………………………………14 ASSEMBLY …………………………………………………15 BLOWER TUBE...

  • Page 3: Safety First

    English SAFETY FIRST Instructions contained in warnings within this manual and warning seals marked with a symbol on the blower concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail.

  • Page 4: Warning Labels On The Machine

    English Warning labels on the machine (1) Read owner's manual before operating this machine. (2) Wear head, eye and ear protection. (3) Handling this machine improperly could result in accidents causing serious injury or death. Read this manual carefully and practice using the blower until you are fully acquainted with all operations and have learned to use it correctly.

  • Page 5: Symbols On The Machine

    English Symbols on the machine For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to make a mistake. (a) The port to refuel the "MIX GASOLINE" POSITION: FUEL TANK CAP (b) The direction to close the choke POSITION: AIR CLEANER COVER (c) The direction to open the choke...

  • Page 6: Safety Precautions

    English Safety Precautions @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ h ?
  • Page 7 English Safety Precautions 5. Wear rubber-soled shoes or shoes with some other form of anti-slip protection to help protect you against falling. 6. To reduce the risk of injury associated with objects being drawn into rotating parts, do not wear loose clothing, scarves, neck chains, unconfined long hair, and the like.

  • Page 8: Working Circumstance

    English Safety Precautions WORKING CIRCUMSTANCE 1. To reduce the risk of injury associated with exhaust fume inhalation, do not operate in unventilated area. The exhaust gases contain harmful carbon monoxide. 2. Avoid using the blower where stable footing and balance are not assured. AVOID NOISE PROBLEM @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ?

  • Page 9: Fuel

    English Safety Precautions FUEL WARNING To reduce the risk of fire and burn injury: a) Handle fuel with care. It is highly flammable. b) Do not smoke while handing fuel. c) Do not refuel a hot engine. d) Do not refuel a running engine. e) Avoid spilling fuel or oil.

  • Page 10: Maintenance

    English Safety Precautions rubber mount when it has become cracked or damaged may cause the engine to come loose from its frame during use, thus resulting in possible serious bodily injury. If cracked, be sure to replace without delay. WARNING To reduce the risk of injury associated with contacting rotating parts, stop the engine before...

  • Page 11: Maintenance

    English Safety Precautions surfaces or use mister attachment when water is available. c) Conserve water by using power blowers instead of hoses for many lawn and garden applications, including areas such as gutters, screens, patios, grills, porches and gardens. 4. Never to touch the spark plug or plug cord while the engine is in operation.

  • Page 12: Maintenance

    English Safety Precautions service to the blower fan and muffler could cause a hazardous failure. 5. When replacing the any other part, or any lubricant, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax product. 6.

  • Page 13: Parts Location

    English Parts Location 1. Frame 2. Shoulder Strap 3. Spark Plug Cap 4. Throttle Lever 5. Stop Switch (behind) 6. Net 7. Choke Lever 8. Air Cleaner 9. Volute Case 10. “CAUTION” Label 11. Elbow 12. Fuel Tank 13. Recoil Starter 14.

  • Page 14: Specifications

    English Specifications MODEL EBZ8000/EBZ8000RH Dimensions (L x W x H) mm (in) EBZ8000 ...380x540x496 (16.3x21.3x19.6) EBZ8000RH ...380x490x496 (16.3x19.3x19.6) Dry Weight kg (lbs) ...11.3 (24.9) Fuel Tank Capacity liter (fl. oz) ...2.3 (77.7) Engine Type ...Air cooled 2-cycle gasoline engine Piston Displacement cm (cu.

  • Page 15: Waist Belt

    [EBZ8000RH] [EBZ8000RH] F4.1 F4.2 F4.3 English Assembly ■ BLOWER TUBES 1. Connect the blower and swivel joint with flexible hose. Clamp both ends of the flexible hose securely with the hardware supplied with the unit. 2. Align the protrusion and the groove provided on the tube ends and twist the tube until connection is locked up.

  • Page 16: Fuel

    • The RedMax/Komatsu Zenoah engines lubricated specially formulated for air-cooled 2-cycle gasoline engine use. If Komatsu Zenoah oil is not available, use an anti- oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use. (JASO FC GRADE OIL or ISO EGC GRADE) •...

  • Page 17: How To Mix Fuel

    English Fuel ■ HOW TO MIX FUEL IMPORTANT Pay attention to agitation. 1. Measure out the quantities of gasoline and oil to be mixed. 2. Put some of the gasoline into a clean, approved fuel container. 3. Pour in all of the oil and agitate well. 4.
  • Page 18 English Fuel can cause spark plug fouling, exhaust port blocking, or piston ring sticking. 4. Mixed fuels which have been left unused for a period of one month or more may clog the carburetor and result in the engine failing to operate properly.

  • Page 19: Operation

    [EBZ8000] [EBZ8000] [EBZ8000RH] [EBZ8000] English Operation ■ CONTROL ARM [EBZ8000] • Hold the upper end of the control arm in hand and, while pulling it away from the unit, rotate arm forward (anti-clockwise as the arrow direction) until it clicks. (The first position) And if you want, you can rotate arm more forward until it clicks.

  • Page 20: Adjusting Idle Speed

    [EBZ8000] [EBZ8000RH] English Operation 6. Once the engine is running, gradually open the choke if it was set closed, and let the engine run at idle speed for a minute to warm it up. NOTE When the engine fails to start after several attempts due to overchoking, open the choke and repeat pulling the rope.

  • Page 21: Fuel Filter

    System/Compornent Air Filter Prefilter Paper Filter Fuel Leaks Fuel Filter Fuel Line Spark Plug Muffler Muffler Spark Arrester Cooling System Screws/Nuts/Bolts Cylinder Exhaust Port Sistema/Componente Prefiltro Filtro de aire Filtro de papel Fugas de combustible Filtro de combustible Línea de combustible Bujía de encendido Silenciador Amortiguador de chispas del silenciador...

  • Page 22: Air Cleaner

    English Maintenance CLEANING AIR FILTER: 1. Unscrew 2 knob bolts and remove the air cleaner cover. Then remove a prefilter mounted inside the air cleaner cover. (1) Knob Bolt (2) Prefilter (3) Inner Case (4) Paper Filter 2. Wash the prefilter in fresh, non flammable cleaning solution (ex.

  • Page 23: Muffler

    English Maintenance ■ MUFFLER WARNING • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, do not use the blower and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire.

  • Page 24: Spark Plug

    English Maintenance ■ AIR INLET NET IMPORTANT • Blowing air is taken in from the air inlet net. When air flow has dropped down during operation, stop the engine and inspect the air inlet net for blocking by obstacles. • Note that failure to remove any such obstacles may result in the engine becoming overheated and damaged.

  • Page 25: Parts List

    NOTE: 1. Use KOMATSU ZENOAH genuine parts as specified in the parts list for repair and/or replacement. 2. KOMATSU ZENOAH does not warrant the machines, which have been damaged by the use of any parts other than those specified by the company.
  • Page 26 Parts List : EBZ8000/EBZ8000RH Fig.1 BLOWER GROUP (S/N 50804217 and up)
  • Page 27 EBZ8000/EBZ8000RH Fig.1 BLOWER GROUP Key# Part Number Description 1 848-L58-55A4 VOLUTE CASE 4 848-L58-55Z0 VOLUTE COVER 5 848-L58-55G0 BRACKET 2750-72230 CLAMP (RH Only) T4970-52510 SCREW TORX T4970-51410 SCREW TORX 9 848-L58-55C0 ELBOW 07000-12100 O-RING T4960-57030 SCREW TORX 3310-53331 13 848-L58-55D4 COVER INLET 14 848-8K4-0010 CLAMP...
  • Page 28 Parts List : EBZ8000/EBZ8000RH Fig.2 ENGINE GROUP (S/N 50804217 and up)
  • Page 29 EBZ8000/EBZ8000RH Fig.2 ENGINE GROUP Key# Part Number Description 848-H00-12A3 CYLINDER 848-H00-12B1 GASKET, BASE 4820-12130 BOLT TORX 4 848-H00-12G0 PLATE, CYL T4960-50810 SCREW TORX 848-H00-14A0 INSULATOR 848-815-2001 BOLT TORX 848-H00-14B2 GASKET, INSU 9 848-H00-14C1 GASKET, CARB 10 848-H00-12C0 COVER, TR-S 11 848-H00-12D0 COVER, TR-F 4820-72150 BOLT TORX 848-H00-12E1 GASKET TR 848-H00-1511 MUFFLER ASSY...
  • Page 30 Parts List : EBZ8000/EBZ8000RH Fig.3 CARBURETOR COMPONENTS Key# Part Number Description T1108-81450 BODY ASSY – SCREEN – VALVE – SPRING – SCREW – – LEVER 1850-81490 BODY 1850-81520 COVER 1751-81510 PUMP 5500-81160 WASHER 1881-81140 SWIVEL 1751-81130 RING 4810-81410 GASKET 1065-81420 DIAPHRAGM 1850-81470 GASKET 4810-81260 DIAPHRAGM 1752-81110 SCREW...
  • Page 31 Parts List : EBZ8000/EBZ8000RH Fig.4 LEVER SET [EBZ8000] (S/N 50804217 and up) Key# Part Number Description 848-L58-3300 LEVER SET T4012-25100 • LEVER 3310-53331 • NUT 01642-20508 • WASHER T4012-25211 • ARM T4012-25311 • BRACKET 3495-25410 • BOLT 3495-25420 • SPRING 3495-25440 •...

  • Page 32: California Emission Control Warranty Statement Your Warranty Rights And Obligations

    KOMATSU ZENOAH recommends that you retain all receipts covering maintenance on your small off-road engine, but KOMATSU ZENOAH can not deny warranty solely for the lack of receipts or for your failure to ensure the performance of all scheduled maintenance.
  • Page 33 DECLARACIÓN DE GARANTÍA DE CONTROL DE EMISIONES DE CALIFORNIA SUS DERECHOS Y OBLIGACIONES DE ACUERDO CON ESTA GARANTÍA La Comisión de Recursos del Aire de California y KOMATSU ZENOAH tienen el agrado de explicar la garantía del sistema de control de emisiones para motores “todo terreno” modelo 1995 y posteriores.

  • Page 34: Limited Warranty

    EMISSION-RELATED PARTS, FOR TWO (2) YEARS FROM THE DATE OF ORIGINAL DELIVERY OF THE UNIT, KOMATSU ZENOAH AMERICA INC. (THE COMPANY), THROUGH ANY RedMax DEALER, WILL REPAIR OR REPLACE, FREE OF CHARGE, FOR THE ORIGINAL AND EACH SUBSEQUENT PURCHASER, ANY PART OR PARTS FOUND TO BE DEFECTIVE IN MATERIAL AND/OR WORKMANSHIP.

  • Page 35: Garantía Limitada

    ZENOAH AMERICA INC. LLAMANDO AL (770)-381-5147. IMPORTANTE: RECIBIRÁ UNA TARJETA DE REGISTRO DE GARANTÍA EN EL MOMENTO DE LA COMPRA. LLENE LA TARJETA Y ENVÍELA A RedMax / KOMATSU ZENOAH AMERICA DENTRO DE SIETE (7) DÍAS. ASEGÚRESE DE CONSERVAR UNA COPIA PARA SUS REGISTROS.
  • Page 36 ZENOAH AMERICA INC. au (770)-381-5147 Note importante: vous recevrez une carte d'enregistrement de garantie au moment de l'achat. Veuillez la remplir et l'adresser à RedMax / KOMATSU ZENOAH AMERICA sous sept (7) jours en prenant soin de conserver une copie pour vous.
