Instructions/Parts
AirPro
Spray Gun
Conventional, HVLP, HiTEch, and LVMP automatic guns for small component finishing
applications. For professional use only.
100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure
100 psi (0.7 MPa, 7 bar) Maximum Working Air Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
See page 2 for model information.
Guns with manifold
EFX Automatic
TI14428A
Guns without manifold
II 2 G c IIB T6
313869B
ENG
TI14427A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirPro 313869B and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco AirPro 313869B

  • Page 1 Instructions/Parts ™ AirPro Spray Gun Conventional, HVLP, HiTEch, and LVMP automatic guns for small component finishing applications. For professional use only. 100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure 100 psi (0.7 MPa, 7 bar) Maximum Working Air Pressure Important Safety Instructions Read all warnings and instructions in this manual.
  • Page 2: Table Of Contents

    Models Contents Models ........2 Warnings ....... . . 3 Selection Charts .
  • Page 3: Warnings

    Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equip- ment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
  • Page 4 Warnings EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest •...
  • Page 5 TOXIC FLUID OR FUMES HAZARD Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swallowed. Read MSDSs to know the specific hazards of the fluids you are using. • Store hazardous fluid in approved containers, and dispose of it according to appli- •...
  • Page 6: Selection Charts

    Selection Charts Selection Charts TERMS Light Fluid: Up to 18 seconds with No. 2 Zahn cup (20 centipoise) Medium Fluid:19 to 28 seconds with No. 2 Zahn cup (20-64 centipoise) Heavy Fluid: Greater than 28 seconds with No. 2 Zahn cup (greater than 64 centipoise) -- 2.8 Volatile Organic Compounds, High-solid Polyurethanes, Heavy Waterborne Enamels Gun Selection...
  • Page 7: Models With Manifolds

    Models With Manifolds Needle/ Assembly Nozzle Kit Part No. Type Part No. 24B857 Conventional 24D177 24B858 Conventional 24C198 24B859 Conventional 24C199 24B860 Conventional 24C200 24B861 Conventional 24D178 24B862 HVLP 24D302 24B863 HVLP 24D179 24B864 HVLP 24D305 24B865 HVLP 24D306 24B866 HiTEch 24D303 24B867...
  • Page 8: Air Caps

    Selection Charts Air Caps Nozzle Orifice Air Cap Part No. Type 24C182 Conventional 0.028-0.059 0.7-1.5 24C183 HVLP 0.020-0.051 0.5-1.3 24D703 HiTEch 0.028-0.039 0.7-1.0 24D704 HiTEch 0.059 24C184 LVMP 0.020-0.059 0.5-1.5 24D705 Air Brush 0.028 Maximum compliant HVLP inlet pressure. Sample Pattern Sizes and Shapes Nozzle Air Cap Orifice...
  • Page 9 Selection Charts 313869B...
  • Page 10: Installation

    Installation Installation This spray gun can spray most coatings or fin- ishes currently being used for small compo- nent plastic, wood and metal finishing applications, while easily operating from paint delivery systems, such as pressure pots or remote pumps for production line operation. The air regulator must have a minimum air flow capacity of 30 scfm at 100 psi (0.7 MPa, 7.0 bar) air pressure.
  • Page 11: Ground System

    Guns without Manifold The gun is shipped ready for use in a circulat- ing system, with a fitting installed in each fluid port. Connect the fluid supply line to one fluid inlet fitting (15) and the fluid return line to the other.
  • Page 12: Mount Gun

    Installation Mount Gun Reciprocating Arm Rod Mount To mount the gun on a reciprocating arm rod [0.75 in. (19 mm) diameter maximum], insert the bar (A) through the hole in the manifold as shown in F . 3. NOTE: Use the 1/8 in. alignment slot (P) to assist in orienting the gun.
  • Page 13: Setup

    Setup Connect Air Line NOTE: If your regulated air source does not • have a filter, install an air filter (G) on each air line to ensure a dry, clean air supply to the gun. Dirt and moisture can ruin the appearance of your finished workpiece.
  • Page 14 Setup . 6: Remote Air Regulation using Solenoid (Guns with Manifold) . 7: Remote Air Regulation using Solenoid (Guns without Manifold) Air regulator ATOMIZING AIR 2-way solenoid valve CYLINDER AIR 3-way solenoid valve FAN AIR 2-way solenoid valve FAN AIR 2-way solenoid valve CYLINDER AIR...
  • Page 15: Connect Fluid Hose

    Connect Fluid Hose NOTE: Before connecting the fluid line, blow it • out with air and flush it with solvent. Use solvent that is compatible with the fluid to be sprayed. Install a fluid regulator (L) on the fluid • line to control fluid pressure to the gun.
  • Page 16: Flush Spray Gun

    Setup Flush Spray Gun Before running any paint through the spray gun: 1. Flush the gun with a solvent that is compat- ible with the fluid to be sprayed, using the lowest possible fluid pressure and a grounded metal container. See Clean and Flush Gun, page 20.
  • Page 17 . 11: Fluid Pressure Regulator NOTE: A larger fluid nozzle at a reduced fluid pressure will maintain the same flow rate, but the fluid stream (velocity) will slow down. When air is applied, the lower velocity allows the air to act on the fluid longer, which improves atomization.
  • Page 18: Operation

    Operation Operation Pressure Relief Procedure 1. Turn off all bleed type air valves and all other air and fluid supplies to the gun. 2. Trigger the gun into a grounded metal waste container to relieve fluid pressure. . 13: Pressure Relief Apply Fluid The gun does not have an air shutoff.
  • Page 19: Daily Gun Care

    Daily Gun Care NOTICE Methylene chloride with formic or propionic acid is not recommended as a flushing or cleaning solvent with this gun as it will damage aluminum and nylon components. Solvent left in gun air passages could result in a poor quality paint finish. Do not use any cleaning method which may allow solvent into the gun air passages.
  • Page 20: General System Maintenance

    Operation General System Maintenance Follow the Pressure Relief Procedure, • page 18. Clean the fluid and air line filters daily. • Check for any fluid leakage from the gun • and fluid hoses. Tighten fittings or replace equipment as needed. Flush the gun before changing colors and •...
  • Page 21 Operation 313869B...
  • Page 22: Troubleshooting

    Troubleshooting Troubleshooting Problem Spray Pattern Right Spray Pattern Wrong Heavy top or bottom Spray Pattern Wrong Split pattern Spray Pattern Wrong Cause Normal pattern. Dirty or damaged air cap or fluid nozzle. Fan pressure too high for vis- cosity of material being sprayed.
  • Page 23 Problem Gun spitting. Will not spray. Excessive air blowing back. Gun fluid pressure is too high with gun triggered (cannot achieve desired flow rate). Using a low fluid pressure set- ting, the fluid flow is too high, making it necessary to restrict needle travel to reduce fluid flow.
  • Page 24: Service

    Service Service NOTE: Numbers in parenthesis in the text refer to the reference numbers in the figures and in the parts list. Disassembly 1. Follow the Pressure Relief Procedure, page 18. 2. Remove gun for service: a. With Manifold: Use the 4 mm allen wrench supplied to unscrew the two Torque to 155-165 in-lb (18-19 N•m).
  • Page 25: Reassembly

    6. Use a 1/16 hex wrench to loosen the fluid needle set screw (7a). Remove the needle (6) from the piston (7). 7. Check the fluid needle (6) for damage or excessive wear. Replace the needle if nec- essary. NOTICE The needle and tip are permanently bonded.
  • Page 26: Parts

    Parts Parts Guns with Manifold Guns without Manifold Ultra-precision knob Indexing knob Lock ring and cap ti14447a ti14448a ti14945a 313869B...
  • Page 27 Parts in Common Ref. Part Description ----- BODY 24C205 FLUID PACKING ASSEMBLY 111457 O-RING (included with Part 4) See Table NOZZLE, fluid (includes Part 3) See Table AIR CAP ASSEMBLY (includes Parts 5a-5d) ----- AIR CAP 5b✓ ----- O-RING 5c✓ ----- WASHER, UMHWPE ----- PIN, alignment...
  • Page 28: Repair Kits

    Repair Kits Repair Kits Gun Part Number With Without Spray Type Manifold Manifold Conventional 24B857 24B877 Conventional 24B858 24B878 Conventional 24B859 24B879 Conventional 24B860 24B880 Conventional 24B861* ----- HVLP 24B862 ----- HVLP 24B863 24B881 HVLP 24B864 24B882 HVLP 24B865 24B883 HiTEch 24B866 24B884...
  • Page 29: Dimensions

    Dimensions Guns with Manifold 4.9 in. (124.5 mm) with Ultra-Precision knob 4.1 in. (104.1 mm) with indexing knob 3.5 in. (88.9 mm) with lock ring and cap 1.3 in. (33.0 mm) 0.75 in. (19.1 mm) 1.4 in. mounting hole (35.6 mm) .
  • Page 30: Mounting Hole Layouts

    Mounting Hole Layouts Mounting Hole Layouts Guns with Manifold 0.43 in. (10.9 mm) 0.86 in. (21.8 mm) 1.22 in. (31.0 mm) . 22 0.95 in (24.1 mm) 1.4 in (35.6 mm) 3 x M8 x 1.25 ti14441a 1.27 in (32.3 mm) ti14700a 0.34 in.
  • Page 31 Mounting Hole Layouts Guns without Manifold 1.76 in. (44.7 mm) M8 x 1.25 T 0.35 in. (8.9 mm) deep 0.95 in. (24.1 mm) 0.13 slot (3.3 mm) ti14701a . 23 313869B...
  • Page 32: Technical Data

    Technical Data Technical Data Maximum working fluid pressure ....100 psi (0.7 MPa, 7 bar) Maximum working air pressure ..... 100 psi (0.7 MPa, 7 bar) Maximum HVLP Inbound Air Pressure.
  • Page 33 Sound Data Conventional Measured at 43 psi (0.30 MPa, 3.0 bar) atomizing air and fan air pressure Sound Power....... . Sound Pressure .
  • Page 34: Air Flow

    Air Flow Air Flow See the chart to determine air consumption. Add the air consumption values shown for the atom- izing air and fan air to get the total air consumption. For example, air cap 24C182 with 35 psi inlet pressure uses 3.9 scfm atomizing air and 5.4 scfm fan air for a total of 9.3 scfm air consumption.
  • Page 35: Spray Pattern Test Report

    Spray Pattern Test Report Every AirPro EFX gun must pass a spray pattern test. The test report is printed and shipped in the box with the gun. A sample is reproduced here, with explanatory notes. Test Number: Operator: Width: the distance from Date: one end of the pattern to the other along the spray...
  • Page 36: Graco Standard Warranty

    Graco Standard Warranty Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
