Top Panel

Microphone Gain Knob This knob controls
11
the volume for the Microphone input when set-
ting recording levels.
Guitar Gain Knob This knob controls the vol-
12
ume for the Guitar/Line input when setting re-
cording levels.
Mic Gain Guitar Gain
11 12
13
for the front-panel Headphone output and back-
panel Line outputs.
Output
13
Output Knob This knob controls the volume
For more information, refer to Chapter 5,
"Using Recording Studio."
Chapter 2: Controls and Connectors 5
