Internet Security Router User's Manual
9.6.2.1
Service List Configuration Parameters
Table 9.5 describes the available configuration parameters for firewall service list.
Field
Service Name
Protocol
Port
Access Service List Configuration Page – (Firewall è Advanced è Service)
9.6.2.2
Log into Configuration Manager as admin, click the Firewall menu, click the Advanced submenu and then
click the Service submenu. The Service List Configuration page displays, as shown in Figure 9.14.
Note that when you open the Service List Configuration page, a list of existing configured services is also
displayed at the bottom half of the configuration page such as those shown in Figure 9.14.
9.6.2.3
Add a Service
To add a service, follow the instructions below:
1. Open the Service List Configuration Page (see section 9.6.2.2 Access Service List Configuration
Page).
2. Select "Add New" from the service drop-down list.
3. Enter a desired name, preferably a meaningful name that signifies the nature of the service, in the
"Service Name" field. Note that only alphanumeric characters are allowed in a name.
4. Make changes to any or all of the following fields: public port and protocol. Please see Table 9.5
for explanation of these fields.
Service drop-down list
Edit icon
Figure 9.14. Service List Configuration Page
Table 9.5. Service List configuration parameters
Description
Enter the name of the Service to be added. Note that only alphanumeric
characters are allowed in a name.
Enter the type of protocol the service uses.
Enter the port number that is set for this service.
Chapter 9. Configuring Firewall/NAT Settings
63
