Page 1 TL-SL3428/TL-SL3452 JetStream L2 Managed Switch REV1.2.1 1910010929...
Page 2: Fcc Statement
COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
Page 3: Safety Information
Safety Information  When product has power button, the power button is one of the way to shut off the product; When there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source. ...
Page 4: Table Of Contents
CONTENTS Package Contents ..........................1 Chapter 1 About this Guide......................2 Intended Readers ......................2 Conventions........................2 Overview of This Guide ....................2 Chapter 2 Introduction ........................6 Overview of the Switch ....................6 Main Features.......................6 Appearance Description ....................7 2.3.1 Front Panel ......................7 2.3.2 Rear Panel ......................8 Chapter 3 Login to the Switch.......................9 Login..........................9 Configuration ........................9...
Page 5 5.1.1 Port Config .......................30 5.1.2 Port Mirror ......................31 5.1.3 Port Security ....................34 5.1.4 Port Isolation ....................36 5.1.5 Loopback Detection ..................37 LAG ..........................38 5.2.1 LAG Table ......................39 5.2.2 Static LAG ......................41 5.2.3 LACP Config ....................42 Traffic Monitor ......................44 5.3.1 Traffic Summary....................44 5.3.2 Traffic Statistics ....................45 MAC Address......................47...
Page 6 STP Security.......................85 7.4.1 Port Protect ......................85 7.4.2 TC Protect......................88 Application Example for STP Function ...............88 Chapter 8 Multicast........................93 IGMP Snooping ......................95 8.1.1 Snooping Config ....................96 8.1.2 Port Config .......................97 8.1.3 VLAN Config ....................98 8.1.4 Multicast VLAN ....................100 Multicast IP .......................104 8.2.1 Multicast IP Table ...................104 8.2.2...
Page 7 10.2.2 ACL Create ....................130 10.2.3 MAC ACL .......................131 10.2.4 Standard-IP ACL ....................132 10.2.5 Extend-IP ACL ....................132 10.3 Policy Config......................134 10.3.1 Policy Summary .....................134 10.3.2 Policy Create....................134 10.3.3 Action Create ....................135 10.4 Policy Binding ......................136 10.4.1 Binding Table ....................136 10.4.2 Port Binding ....................137 10.4.3 VLAN Binding....................137 10.5...
Page 8 12.3.1 History Control ....................181 12.3.2 Event Config ....................181 12.3.3 Alarm Config ....................182 Chapter 13 LLDP ........................185 13.1 Basic Config ......................188 13.1.1 Global Config ....................188 13.1.2 Port Config .....................189 13.2 Device Info........................190 13.2.1 Local Info .......................190 13.2.2 Neighbor Info ....................191 13.3 Device Statistics......................192 Chapter 14 Cluster........................195 14.1...
Page 9 15.4.1 Ping........................217 15.4.2 Tracert......................218 Chapter 16 System Maintenance via FTP ..................219 Appendix A: Specifications ......................224 Appendix B: Configuring the PCs ....................225 Appendix C: 802.1X Client Software ..................228 Appendix D: Glossary.........................236 VIII...
Page 10: Package Contents
One console cable  Two mounting brackets and other fittings  Installation Guide  Resource CD for TL-SL3428/TL-SL3452 switch, including:  This User Guide  Other Helpful Information Note: Make sure that the package contains the above items. If any of the listed items are damaged or...
Page 11: Chapter 1 About This Guide
The two devices of TL-SL3428 and TL-SL3452 are sharing this User Guide. For simplicity, we will take TL-SL3428 for example throughout the configuration chapters.TL-SL3428 and TL-SL3452 just differ in the number of LED indicators and ports and all ﬁgures in this guide are of TL-SL3428. Menu Name→Submenu Name→Tab page indicates the menu structure. System→System ...
Page 12 Chapter Introduction Chapter 4 System This module is used to configure system properties of the switch. Here mainly introduces: System Info: Configure the description, system time and network  parameters of the switch. User Management: Configure the user name and password for ...
Page 13 Chapter Introduction Chapter 9 QoS This module is used to configure QoS function to provide different quality service various network applications requirements. Here mainly introduces: DiffServ: Configure priorities, port priority, 802.1P priority and  DSCP priority. Bandwidth Control: Configure rate limit feature to control the ...
Page 14 Chapter Introduction Chapter 14 Cluster This module is used to configure cluster function to central manage the scattered devices in the network. Here mainly introduces: NDP: Configure NDP function to get the information of the directly  connected neighbor devices. NTDP: Configure NTDP function for the commander switch to ...
Page 15: Chapter 2 Introduction
Chapter 2 Introduction Thanks for choosing the TL-SL3428/TL-SL3452 JetStream L2 Managed Switch! 2.1 Overview of the Switch Designed for workgroups and departments, TL-SL3428/TL-SL3452 from TP-Link provides wire-speed performance and full set of layer 2 management features. It provides a variety of service features and multiple powerful functions with high security.
Page 16: Appearance Description
100Mbps or 1000Mbps. Each has a corresponding 1000Mbps LED.  SFP Ports: Designed to install the SFP module. TL-SL3428 features some SFP transceiver slots that are shared with the associated RJ45 ports. The associated two ports are referred as a “Combo” port, which means they cannot be used simultaneously, otherwise only SFP port works.
Page 17: Rear Panel
LED. For TL-SL3428, When using the SFP port with a 100M module or a gigabit module, you need to log on to the GUI (Graphical User Interface) of the switch and configure its corresponding Speed and Duplex mode on Switching→Port→Port Config page.
Page 18: Chapter 3 Login To The Switch
Chapter 3 Login to the Switch 3.1 Login 1) To access the configuration utility, open a web-browser and type in the default address http://192.168.0.1 in the address field of the browser, then press the Enter key. Figure 3-1 Web-browser Tips: To log in to the switch, the IP address of your PC should be set in the same subnet addresses of the switch.
Page 19 Figure 3-3 Main Setup-Menu Note: Clicking Apply can only make the new configurations effective before the switch is rebooted. If you want to keep the configurations effective even the switch is rebooted, please click Save Config. You are suggested to click Save Config before cutting off the power or rebooting the switch to avoid losing the new configurations.
Page 20: Chapter 4 System
Chapter 4 System The System module is mainly for system configuration of the switch, including four submenus: System Info, User Management, System Tools and Access Security. 4.1 System Info The System Info, mainly for basic properties configuration, can be implemented on System Summary, Device Description, System Time, Daylight Saving Time and System IP pages.
Page 21 Indicates the 1000Mbps port is not connected to a device. Indicates the 1000Mbps port is at the speed of 1000Mbps. Indicates the 1000Mbps port is at the speed of 10Mbps or 100Mbps. Indicates the SFP port is not connected to a device. Indicates the SFP port is at the speed of 1000Mbps.
Page 22: Device Description
Figure 4-3 Bandwidth Utilization Bandwidth Utilization  Select Rx to display the bandwidth utilization of receiving packets on this port. Select Tx to display the bandwidth utilization of sending packets on this port. 4.1.2 Device Description On this page you can configure the description of the switch, including device name, device location and system contact.
Page 23: System Time
Device Location: Enter the location of the switch. System Contact: Enter your contact information. 4.1.3 System Time System Time is the time displayed while the switch is running. On this page you can configure the system time and the settings here will be used for other time-based functions like ACL. You can manually set the system time, get UTC automatically if it has connected to an NTP server or synchronize with PC’s clock as the system time.
Page 24: Daylight Saving Time
Note: The system time will be restored to the default when the switch is restarted and you need to reconfigure the system time of the switch. When Get Time from NTP Server is selected and no time server is configured, the switch will get time from the time server of the Internet if it has connected to the Internet.
Page 25: System Ip
Date Mode: Specify the DST configuration in Date mode. This configuration is recurring in use:  Offset: Specify the time adding in minutes when Daylight Saving Time comes.  Start/End Time: Select starting time and ending time of Daylight Saving Time. Note: When the DST is disabled, the predefined mode, recurring mode and date mode cannot be configured.
Page 26: User Management
Management VLAN: Enter the ID of management VLAN, the only VLAN through which you can get access to the switch. By default VLAN1 owning all the ports is the Management VLAN and you can access the switch via any port on the switch. However, if another VLAN is created and set to be the Management VLAN, you may have to reconnect the management station to a port that is a member of the Management VLAN.
Page 27 settings without the right to configure the switch; the admin can configure all the functions of the switch. The Web management pages contained in this guide are subject to the admin’s login without any explanation. Choose the menu System→User Management→User Config to load the following page. Figure 4-9 User Config The following entries are displayed on this screen: User Info...
Page 28: System Tools
Operation: Click the Edit button of the desired entry, and you can edit the corresponding user information. After modifying the settings, please click the Modify button to make the modification effective. Access level and user status of the current user information can’t be modified.
Page 29: Firmware Upgrade
Figure 4-11 Config Backup The following entries are displayed on this screen: Config Backup  Backup Config: Click the Backup Config button to save the current configuration as a file to your computer. You are suggested to take this measure before upgrading.
Page 30: System Reboot
After upgrading, the device will reboot automatically. You are suggested to backup the configuration before upgrading. 4.3.4 System Reboot On this page you can reboot the switch and return to the login page. Please save the current configuration before rebooting to avoid losing the configuration unsaved. Choose the menu System→System Tools→System Reboot to load the following page.
Page 31 Choose the menu System→Access Security→Access Control to load the following page. Figure 4-15 Access Control The following entries are displayed on this screen: Access Control Config  Control Mode: Select the control mode for users to log on to the Web management page.
Page 32: Ssl Config
Port: The field can be available for configuration only when Port-based mode is selected. Only the users connected to these ports you set here are allowed for login. Session Config  Session Timeout: If you do nothing with the Web management page within the timeout time, the system will log out automatically.
Page 33: Ssh Config
Figure 4-16 SSL Config The following entries are displayed on this screen: Global Config  SSL: Select Enable/Disable the SSL function on the switch. Certificate Download  Certificate File: Select the desired certificate to download to the switch. The certificate must be BASE64 encoded. Key Download ...
Page 34 an insecure network environment. It can encrypt all the transmission data and prevent the information in a remote management being leaked. Comprising server and client, SSH has two versions, V1 and V2 which are not compatible with each other. In the communication, SSH server and client can auto-negotiate the SSH version and the encryption algorithm.
Page 35 Key Download  Key Type: Select the type of SSH key to download. The switch supports three types: SSH-1 RSA, SSH-2 RSA and SSH-2 DSA. Key File: Select the desired key file to download. Download: Click the Download button to download the desired key file to the switch.
Page 36 Application Example 2 for SSH: Network Requirements  1. Log on to the switch via password authentication using SSH and the SSH function is enabled on the switch. 2. PuTTY client software is recommended. Configuration Procedure  1. Select the key type and key length, and generate SSH key. Note: The key length is in the range of 256 to 3072 bits.
Page 37 2. On the Web management page of the switch, download the public key file saved in the computer to the switch. Note: The key type should accord with the type of the key file. The SSH key downloading can not be interrupted. Download the private key file to SSH client software.
Page 38 3. After the public key and private key are downloaded, please log on to the interface of PuTTY and enter the IP address for login. 4. After successful authentication, please enter the login user name. If you log on to the switch without entering password, it indicates that the key has been successfully downloaded.
Page 39: Chapter 5 Switching
Chapter 5 Switching Switching module is used to configure the basic functions of the switch, including four submenus: Port, LAG, Traffic Monitor and MAC Address. 5.1 Port The Port function, allowing you to configure the basic features for the port, is implemented on the Port Config, Port Mirror, Port Security, Port Isolation and Loopback Detection pages.
Page 40: Port Mirror
The parameters of the port members in a LAG should be set as the same. For TL-SL3428, when using the SFP port with a 100M module or a gigabit module, you need to configure its corresponding Speed and Duplex mode. For 100M module, please select 100MFD while select 1000MFD for gigabit module.
Page 41 Figure5-2 Mirror Group List The following entries are displayed on this screen: Mirror Group List  Group: Displays the mirror group number. Mirroring: Displays the mirroring port number. Mode: Displays the mirror mode. Mirrored Port: Displays the mirrored ports. Operation: Click Edit to configure the mirror group.
Page 42 Figure 5-3 Port Mirror Config The following entries are displayed on this screen. Mirror Group  Number: Select the mirror group number you want to configure. Mirroring Port  Mirroring Port: Select a port from the pull-down list as the mirroring port. When Disable is selected, the Port Mirror feature will be disabled.
Page 43: Port Security
Egress: Select Enable/Disable the Egress feature. When the Egress is enabled, the outgoing packets sent by the mirrored port will be copied to the mirroring port. LAG: Displays the LAG number which the port belongs to. The LAG member can not be selected as the mirrored port or mirroring port. Note: The LAG member can not be selected as the mirrored port or mirroring port.
Page 44 Figure 5-4 Port Security The following entries are displayed on this screen: Port Security  Select: Select the desired port for Port Security configuration. It is multi-optional. Port: Displays the port number. Max Learned MAC: Specify the maximum number of MAC addresses that can be learned on the port.
Page 45: Port Isolation
Note: The Port Security function is disabled for the LAG port member. Only the port is removed from the LAG, will the Port Security function be available for the port. The Port Security function is disabled when the 802.1X function is enabled. 5.1.4 Port Isolation Port Isolation provides a method of restricting traffic flow to improve the network security by forbidding the port to forward packets to the ports that are not on its forward portlist.
Page 46: Loopback Detection
Forward Portlist: Select the port that to be forwarded to. Port Isolation List  Port: Display the port number. Forward Portlist: Display the forwardlist. 5.1.5 Loopback Detection With loopback detection feature enabled, the switch can detect loops using loopback detection packets.
Page 47: Lag
Global Config  LoopbackDetection Here you can enable or disable loopback detection function Status: globally. Detection Interval: Set a loopback detection interval between 1 and 1000 seconds. By default, it’s 30 seconds. Automatic Recovery Time after which the blocked port would automatically recover to Time : normal status.
Page 48: Lag Table
For the member ports in an aggregation group, their basic configuration must be the same. The basic configuration includes STP, QoS, GVRP, VLAN, port attributes, MAC Address Learning mode and other associated settings. The further explains are following: If the ports, which are enabled for the GVRP, 802.1Q VLAN, Voice VLAN, STP, QoS, Port ...
Page 49 Figure 5-7 LAG Table The following entries are displayed on this screen: Global Config  Hash Algorithm: Select the applied scope of Aggregate Arithmetic, which results in choosing a port to transfer the packets.  SRC MAC + DST MAC: When this option is selected, the Aggregate Arithmetic will apply to the source and destination MAC addresses of the packets.
Page 50: Static Lag
Figure 5-8 Detail Information 5.2.2 Static LAG On this page, you can manually configure the LAG. The LACP feature is disabled for the member ports of the manually added Static LAG. Choose the menu Switching→LAG→Static LAG to load the following page. Figure 5-9 Manually Config The following entries are displayed on this screen: LAG Config...
Page 51: Lacp Config
Description: Displays the description of the LAG. LAG Table  Member Port: Select the port as the LAG member. Clearing all the ports of the LAG will delete this LAG. Tips: The LAG can be deleted by clearing its all member ports. A port can only be added to a LAG.
Page 52 Figure 5-10 LACP Config The following entries are displayed on this screen: Global Config  System Priority: Specify a System Priority for the port. The System Priority and the Admin Key constitute the aggregation ID. A dynamic aggregation group will only be formed between ports having the same aggregation LACP Config ...
Page 53: Traffic Monitor
preferred one. If the two port priorities are equal; the port with smaller port number is preferred. Specify the LACP mode for your selected port. Mode： Status: Enable/Disable the LACP feature for your selected port. LAG: Displays the LAG number which the port belongs to. 5.3 Traffic Monitor The Traffic Monitor function, monitoring the traffic of each port, is implemented on the Traffic Summary and Traffic Statistics pages.
Page 54: Traffic Statistics
Refresh Rate: Enter a value in seconds to specify the refresh interval. Traffic Summary  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Port: Displays the port number. Packets Rx: Displays the number of packets received on the port.
Page 55 The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Allows you to Enable/Disable refreshing the Traffic Summary automatically. Refresh Rate: Enter a value in seconds to specify the refresh interval. Statistics  Port: Enter a port number and click the Select button to view the traffic statistics of the corresponding port.
Page 56: Mac Address
5.4 MAC Address The main function of the switch is forwarding the packets to the correct ports based on the destination MAC address of the packets. Address Table contains the port-based MAC address information, which is the base for the switch to forward packets quickly. The entries in the Address Table can be updated by auto-learning or configured manually.
Page 57 Figure 5-13 Address Table The following entries are displayed on this screen: Search Option  MAC Address: Enter the MAC address of your desired entry. VLAN ID: Enter the VLAN ID of your desired entry. Port: Select the corresponding port number of your desired entry. Type: Select the type of your desired entry.
Page 58: Static Address
Address Table  MAC Address: Displays the MAC address learned by the switch. VLAN ID: Displays the corresponding VLAN ID of the MAC address. Port: Displays the corresponding Port number of the MAC address. Type: Displays the Type of the MAC address. Aging Status: Displays the Aging status of the MAC address.
Page 59: Dynamic Address
Search Option  Search Option: Select a Search Option from the pull-down list and click the Search button to find your desired entry in the Static Address Table.  MAC Address: Enter the MAC address of your desired entry.  VLAN ID: Enter the VLAN ID number of your desired entry.
Page 60 Figure 5-15 Dynamic Address The following entries are displayed on this screen: Aging Config  Auto Aging: Allows you to Enable/Disable the Auto Aging feature. Aging Time: Enter the Aging Time for the dynamic address. Search Option  Search Option: Select a Search Option from the pull-down list and click the Search button to find your desired entry in the Dynamic Address Table.
Page 61: Filtering Address
Dynamic Address Table  Select: Select the entry to delete the dynamic address or to bind the MAC address to the corresponding port statically. It is multi-optional. MAC Address: Displays the dynamic MAC address. VLAN ID: Displays the corresponding VLAN ID of the MAC address. Port: Displays the corresponding port number of the MAC address.
Page 62 The following entries are displayed on this screen: Create Filtering Address  MAC Address: Enter the MAC address to be filtered. VLAN ID: Enter the corresponding VLAN ID of the MAC address. Search Option  Search Option: Select a Search Option from the pull-down list and click the Search button to find your desired entry in the Filtering Address Table.
Page 63: Chapter 6 Vlan
Chapter 6 VLAN The traditional Ethernet is a data network communication technology basing on CSMA/CD (Carrier Sense Multiple Access/Collision Detect) via shared communication medium. Through the traditional Ethernet, the overfull hosts in LAN will result in serious collision, flooding broadcasts, poor performance or even breakdown of the Internet.
Page 64: Q Vlan
VLANs. The switch can analyze the received untagged packets on the port and match the packets with the Protocol VLAN and 802.1Q VLAN in turn. If a packet is matched, the switch will add a corresponding VLAN tag to it and forward it in the corresponding VLAN. 6.1 802.1Q VLAN VLAN tags in the packets are necessary for the switch to identify packets of different VLANs.
Page 65 （2） TRUNK: The TRUNK port can be added in multiple VLANs, and the egress rule of the port is TAG. The TRUNK port is generally used to connect the cascaded network devices for it can receive and forward the packets of multiple VLANs. When the packets are forwarded by the TRUNK port, its VLAN tag will not be changed.
Page 66: Vlan Config
IEEE 802.1Q VLAN function is implemented on the VLAN Config and Port Config pages. 6.1.1 VLAN Config On this page, you can view the current created 802.1Q VLAN. Choose the menu VLAN→802.1Q VLAN→VLAN Config to load the following page. Figure 6-3 VLAN Table To ensure the normal communication of the factory switch, the default VLAN of all ports is set to VLAN1.
Page 67 Figure 6-4 Create or Modify 802.1Q VLAN The following entries are displayed on this screen: VLAN Config  VLAN ID: Enter the ID number of VLAN. Description: Give a description to the VLAN for identification. Check: Click the Check button to check whether the VLAN ID you entered is valid or not.
Page 68: Port Config
Egress Rule: Select the Egress Rule for the VLAN port member. The default egress rule is UNTAG.  TAG: All packets forwarded by the port are tagged. The packets contain VLAN information.  UNTAG: Packets forwarded by the port are untagged. LAG: Displays the LAG to which the port belongs.
Page 69 Select the Link Type from the pull-down list for the port. Link Type:  ACCESS: The ACCESS port can be added in a single VLAN, and the egress rule of the port is UNTAG. The PVID is same as the current VLAN ID. If the current VLAN is deleted, the PVID will be set to 1 by default.
Page 70: Protocol Vlan
Step Operation Description Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config page, click the Create button to create a VLAN. Enter the VLAN ID and the description for the VLAN. Meanwhile, specify its member ports. Modify/View VLAN. Optional. On the VLAN→802.1Q VLAN→VLAN Config page, click the Edit/Detail button to modify/view the information of the corresponding VLAN.
Page 71: Protocol Vlan
If the Protocol VLAN is created, please set its enabled port to be the member of corresponding 802.1Q VLAN so as to ensure the packets forwarded normally. 6.2.1 Protocol VLAN On this page, you can create Protocol VLAN and view the information of the current defined Protocol VLANs.
Page 72: Port Enable
Figure 6-8 Create and View Protocol Template The following entries are displayed on this screen: Create Protocol Template  Protocol Name: Give a name for the Protocol Template. Ether Type: Enter the Ethernet protocol type field in the protocol template. Protocol Template Table ...
Page 73: Gvrp
Figure 6-9 Enable Protocol VLAN for Port Port Enable: Select your desired port for Protocol VLAN feature. All the ports are disabled by default. Configuration Procedure: Step Operation Description Set the link type for port. Required. On the VLAN→802.1Q VLAN→Port Config page, set the link type for the port basing on its connected device.
Page 74 GARP  GARP provides the mechanism to assist the switch members in LAN to deliver, propagate and register the information among the members. GARP itself does not work as the entity among the devices. The application complied with GARP is called GARP implementation, and GVRP is the implementation of GARP.
Page 75 including VLAN members, ports through which the VLAN members can be reached, and so on. The switch also propagates the local VLAN registration information to other switches so that all the switching devices in the same switched network can have the same VLAN information. The VLAN registration information includes not only the static registration information configured locally, but also the dynamic registration information, which is received from other switches.
Page 76 Note: If the GVRP feature is enabled for a member port of LAG, please ensure all the member ports of this LAG are set to be in the same status and registration mode. The following entries are displayed on this screen: Global Config ...
Page 77: Application Example For 802.1Q Vlan
Configuration Procedure: Step Operation Description Set the link type for port. Required. On the VLAN→802.1Q VLAN→Port Config page, set the link type of the port to be TRUNK. Enable GVRP function. Required. On the VLAN→GVRP page, enable GVRP function. Configure the registration Required.
Page 78: Application Example For Protocol Vlan
Step Operation Description Create VLAN10 Required. On VLAN→802.1Q VLAN→VLAN Config pa ge, create a VLAN with its VLAN ID as 10, owning Port 2 and Port 3. Create VLAN20 Required. On VLAN→802.1Q VLAN→VLAN Config pag e, create a VLAN with its VLAN ID as 20, owning Port 3 and Port 4. Confi gure Switch ...
Page 79 Configuration Procedure  Co figure Switc  S tep Operation Description Configure Required. On VLAN→802.1Q VLAN→Port Config page, configure the Link T ype of the link type of Port 11 and Po rt 13 as ACCESS, and configure the link type ports of Port 12 as GENERAL.
Page 80: Chapter 7 Spanning Tree
Chapter 7 Spanning Tree STP (Spanning Tree Protocol), subject to IEEE 802.1D standard, is to disbranch a ring network in the Data Link layer in a local network. Devices running STP discover loops in the network and block ports by exchanging information, in that way, a ring network can be disbranched to form a tree-topological ring-free network to prevent packets from being duplicated and forwarded endlessly in the network.
Page 81 Port: Port 3 is the root port of switch B and port 5 is the root port of switch C; port 1 is the  designated port of switch A and port 4 is the designated port of switch B; port 6 is the blocked port of switch C.
Page 82 STP Generation  In the beginning  In the beginning, each switch regards itself as the root, and generates a configuration BPDU for each port on it as a root, with the root path cost being 0, the ID of the designated bridge being that of the switch, and the designated port being itself.
Page 83 Tips： In an STP with stable topology, only the root port and designated port can forward data, and the other ports are blocked. The blocked ports only can receive BPDUs. RSTP (Rapid Spanning Tree Protocol), evolved from the 802.1D STP standard, enable Ethernet ports to transit their states rapidly.
Page 84 Figure 7-2 Basic MSTP diagram MSTP  MSTP divides a network into several MST regions. The CST is generated between these MST regions, and multiple spanning trees can be generated in each MST region. Each spanning tree is called an instance. As well as STP, MSTP uses BPDUs to generate spanning tree. The only difference is that the BPDU for MSTP carries the MSTP configuration information on the switches.
Page 85: Stp Config
Figure 7-3 Port roles The Spanning Tree module is mainly for spanning tree configuration of the switch, including four submenus: STP Config, Port Config, MSTP Instance and STP Security. 7.1 STP Config The STP Config function, for global configuration of spanning trees on the switch, can be implemented on STP Config and STP Summary pages.
Page 86 Figure 7-4 STP Config The following entries are displayed on this screen: Global Config  STP: Select Enable/Disable STP function globally on the switch. Version: Select the desired STP version on the switch.  STP: Spanning Tree Protocol.  RSTP: Rapid Spanning Tree Protocol. ...
Page 87: Stp Summary
Max Hops: Enter a value from 1 to 40 to set the maximum number of hops that occur in a specific region before the BPDU is discarded. The default value is 20 hops. Note: The forward delay parameter and the network diameter are correlated. A too small forward delay parameter may result in temporary loops.
Page 88: Port Config
Figure 7-5 STP Summary 7.2 Port Config On this page you can configure the parameters of the ports for CIST Choose the menu Spanning Tree→Port Config to load the following page.
Page 89 Figure 7-6 Port Config The following entries are displayed on this screen: Port Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for STP configuration. It is multi-optional. Port: Displays the port number of the switch.
Page 90: Mstp Instance
 Designated Port: Indicates the port that forwards packets to a downstream network segment or switch.  Master Port: Indicates the port that connects a MST region to the common root. The path from the master port to the common root is the shortest path between this MST region and the common root.
Page 91: Instance Config
Figure 7-7 Region Config The following entries are displayed on this screen: Region Config  Region Name: Create a name for MST region identification using up to 32 characters. Revision: Enter the revision from 0 to 65535 for MST region identification. 7.3.2 Instance Config Instance Configuration, a property of MST region, is used to describe the VLAN to Instance mapping configuration.
Page 92: Instance Port Config
The following entries are displayed on this screen: Instance Table  Instance ID Select: Click the Select button to quick-select the corresponding Instance ID based on the ID number you entered. Select: Select the desired Instance ID for configuration. It is multi-optional. Instance: Displays Instance ID of the switch.
Page 93 Figure 7-9 Instance Port Config The following entries are displayed on this screen: Port Config  Instance ID: Select the desired instance ID for its port configuration. Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered.
Page 94: Stp Security
Note: The port status of one port in different spanning tree instances can be different. Global configuration Procedure for Spanning Tree function: Step Operation Description Make clear roles the switches Preparation. play spanning tree instances: root bridge designated bridge Globally configure MSTP Required.
Page 95 Root Protect  A CIST and its secondary root bridges are usually located in the high-bandwidth core region. Wrong configuration or malicious attacks may result in configuration BPDU packets with higher priorities being received by the legal root bridge, which causes the current legal root bridge to lose its position and network topology jitter to occur.
Page 96 Figure 7-10 Port Protect The following entries are displayed on this screen: Port Protect  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for port protect configuration. It is multi-optional.
Page 97: Tc Protect
7.4.2 TC Protect When TC Protect is enabled for the port on Port Protect page, the TC threshold and TC protect cycle need to be configured on this page. Choose the menu Spanning Tree→STP Security→TC Protect to load the following page. Figure 7-11 TC Protect The following entries are displayed on this screen: TC Protect...
Page 98 Network Diagram  Configuration Procedure  Configure Switch A:  Step Operation Description Configure ports On VLAN→802.1Q VLAN page, configure the link type of the related ports as Trunk, and add the ports to VLAN 101-VLAN 106. The detailed instructions can be found in the section 802.1Q VLAN.
Page 99 Step Operation Description Configure the region name and On Spanning Tree→MSTP Instance→Region Config the revision of MST region page, configure the region as TP-LINK and keep the default revision setting. Configure VLAN-to-Instance Spanning Tree→MSTP Instance→Instance mapping table of the MST region Config page, configure VLAN-to-Instance mapping table.
Page 100 Step Operation Description Enable STP function On Spanning Tree→STP Config→STP Config page, enable STP function and select MSTP version. On Spanning Tree→STP Config→Port Config page, enable MSTP function for the port. Configure the region name and On Spanning Tree→MSTP Instance→Region Config the revision of MST region page, configure the region as TP-LINK and keep the default revision setting.
Page 101 Enable Loop Protect function for the non-edge ports.  Enable BPDU Protect function or BPDU Filter function for the edge ports which are connected to the PC and server. Return to CONTENTS...
Page 102: Chapter 8 Multicast
Chapter 8 Multicast Multicast Overview  In the network, packets are sent in three modes: unicast, broadcast and multicast. In unicast, the source server sends separate copy information to each receiver. When a large number of users require this information, the server must send many pieces of information with the same content to the users.
Page 103 Multicast Address  1. Multicast IP Address: As specified by IANA (Internet Assigned Numbers Authority), Class D IP addresses are used as destination addresses of multicast packets. The multicast IP addresses range from 224.0.0.0~239.255.255.255. The following table displays the range and description of several special multicast IP addresses.
Page 104: Igmp Snooping
VLAN ID Multicast IP Port Figure 8-3 Multicast Address Table IGMP Snooping  In the network, the hosts apply to the near Router for joining (leaving) a multicast group by sending IGMP (Internet Group Management Protocol) messages. When the up-stream device forwards down the multicast data, the switch is responsible for sending them to the hosts.
Page 105: Snooping Config
it will be added to the multicast address table with its member port time specified; if the receiving port is already a member port, its member port time will be directly reset. 3. IGMP Leave Message The host, running IGMPv1, does not send IGMP leave message when leaving a multicast group, as a result, the switch can not get the leave information of the host momentarily.
Page 106: Port Config
Figure 8-4 Basic Config The following entries are displayed on this screen: Global Config  IGMP Snooping: Select Enable/Disable IGMP Snooping function globally on the switch. Unknown Multicast: Select the operation for the switch to process unknown multicast, Forward or Discard. IGMP Snooping Status ...
Page 107: Vlan Config
Figure 8-5 Port Config The following entries are displayed on this screen: Port Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for IGMP Snooping feature configuration. It is multi-optional.
Page 108 Choose the menu Multicast→IGMP Snooping→VLAN Config to load the following page. Figure 8-6 VLAN Config The following entries are displayed on this screen: VLAN Config  VLAN ID: Enter the VLAN ID to enable IGMP Snooping for the desired VLAN. Router Port Time: Specify the aging time of the router port.
Page 109: Multicast Vlan
Leave Time: Displays the leave time of the VLAN. Router Port: Displays the router port of the VLAN. Note: The settings here will be invalid when multicast VLAN is enabled. Configuration procedure: Step Operation Description Enable IGMP Snooping Required. Enable IGMP Snooping globally on the switch function port Multicast→IGMP...
Page 110 Figure 8-7 Multicast VLAN The following entries are displayed on this screen: Multicast VLAN  Multicast VLAN: Select Enable/Disable Multicast VLAN feature. VLAN ID: Enter the VLAN ID of the multicast VLAN. Router Port Time: Specify the aging time of the router port. Within this time, if the switch doesn’t receive IGMP query message from the router port, it will consider this port is not a router port any more.
Page 111 Configuration procedure: Step Operation Description Enable IGMP Snooping Required. Enable IGMP Snooping globally on the switch function port Multicast→IGMP Snooping→Snooping Config and Port Config page. Create a multicast VLAN Required. Create a multicast VLAN and add all the member ports and router ports to the VLAN on the VLAN→802.1Q VLAN page.
Page 112 Network Diagram  Configuration Procedure  Step Operation Description Create VLANs Create three VLANs with the VLAN ID 3, 4 and 5 respectively, and specify the description of VLAN3 as Multicast VLAN on VLAN→802.1Q VLAN page. Configure ports On VLAN→802.1Q VLAN function pages. For port 3, configure its link type as GENERAL and its egress rule as TAG, and add it to VLAN3, VLAN4 and VLAN5.
Page 113: Multicast Ip
8.2 Multicast IP In a network, receivers can join different multicast groups appropriate to their needs. The switch forwards multicast streams based on multicast address table. The Multicast IP can be implemented on Multicast IP Table, Static Multicast IP page. 8.2.1 Multicast IP Table On this page you can view the multicast IP table on the switch.
Page 114: Static Multicast Ip
Note: If the configuration on VLAN Config page and multicast VLAN page is changed, the switch will clear up the dynamic multicast addresses in multicast address table and learn new addresses. 8.2.2 Static Multicast IP Static Multicast IP table, isolated from dynamic multicast group and multicast filter, is not learned by IGMP Snooping.
Page 115: Multicast Filter
Static Multicast IP Table  Select: Select the desired entry to delete the corresponding static multicast IP. It is multi-optional. Multicast IP: Displays the multicast IP. VLAN ID: Displays the VLAN ID of the multicast group. Forward Port: Displays the forward port of the multicast group. 8.3 Multicast Filter When IGMP Snooping is enabled, you can specified the multicast IP-range the ports can join so as to restrict users ordering multicast programs via configuring multicast filter rules.
Page 116: Port Filter
IP-Range Table  IP-Range ID Select: Click the Select button to quick-select the corresponding IP-range ID based on the ID number you entered. Select: Select the desired entry to delete or modify the corresponding IP-range. It is multi-optional. IP-Range ID: Displays IP-range ID.
Page 117: Packet Statistics
Action Mode: Select the action mode to process multicast packets when the multicast IP is in the filtering IP-range.  Permit: Only the multicast packets whose multicast IP is in the IP-range will be processed.  Deny: Only the multicast packets whose multicast IP is not in the IP-range will be processed.
Page 118 Packet Statistics Figure 8-12 The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Select Enable/Disable auto refresh feature. Refresh Period: Enter the time from 3 to 300 in seconds to specify the auto refresh period. IGMP Statistics ...
Page 119: Chapter 9 Qos
Chapter 9 QoS QoS (Quality of Service) functions to provide different quality of service for various network applications and requirements and optimize the bandwidth resource distribution so as to provide a network service experience of a better quality.  This switch classifies the ingress packets, maps the packets to different priority queues and then forwards the packets according to specified scheduling algorithms to implement QoS function.
Page 120 2. 802.1P Priority Figure 9-2 802.1Q frame As shown in the figure above, each 802.1Q Tag has a Pri field, comprising 3 bits. The 3-bit priority field is 802.1p priority in the range of 0 to 7. 802.1P priority determines the priority of the packets based on the Pri value.
Page 121 Figure 9-4 SP-Mode WRR-Mode: Weight Round Robin Mode. In this mode, packets in all the queues are sent in order based on the weight value for each queue and every queue can be assured of a certain service time. The weight value indicates the occupied proportion of the resource. WRR queue overcomes the disadvantage of SP queue that the packets in the queues with lower priority can not get service for a long time.
Page 122: Diffserv
The QoS module is mainly for traffic control and priority configuration, including three submenus: DiffServ, Bandwidth Control and Voice VLAN. 9.1 DiffServ This switch classifies the ingress packets, maps the packets to different priority queues and then forwards the packets according to specified scheduling algorithms to implement QoS function. This switch implements three priority modes based on port, on 802.1P and on DSCP, and supports four queue scheduling algorithms.
Page 123: Dscp Priority
Note: To complete QoS function configuration, you have to go to the Schedule Mode page to select a schedule mode after the configuration is finished on this page. Configuration Procedure: Step Operation Description Log on to the Port Priority page Select the desired ports for Select the desired ports.
Page 124: Configuration Procedure
Figure 9-7 DSCP Priority The following entries are displayed on this screen: DSCP Priority Config  DSCP Priority: Select Enable or Disable DSCP Priority. Priority Level  DSCP: Indicates the priority determined by the DS region of IP datagram. It ranges from 0 to 63. Priority Level: Indicates the priority level the packets with tag are mapped to.
Page 125: P/Cos Mapping
Step Operation Description Map the DSCP priority to the Required. Select DSCP priority and the corresponding priority level priority level. Select a schedule mode Required. Log on to the Schedule Mode page to select a schedule mode. 9.1.3 802.1P/CoS Mapping On this page you can configure the mapping relation between the 802.1P priority tag-id/CoS-id and the TC-id.
Page 126: Schedule Mode
Note: To complete QoS function configuration, you have to go to the Schedule Mode page to select a schedule mode after the configuration is finished on this page. Configuration Procedure: Step Operation Description Configure mapping Required. On QoS→DiffServ→802.1P/CoS mapping relation between the 802.1P page, configure the mapping relation between the priority Tag/CoS and the TC 802.1P priority Tag/CoS and the TC.
Page 127: Bandwidth Control
Equ-Mode: Equal-Mode. In this mode, all the queues occupy the bandwidth equally. The weight value ratio of all the queues is 1:1:1:1. 9.2 Bandwidth Control Bandwidth function, allowing you to control the traffic rate and broadcast flow on each port to ensure network in working order, can be implemented on Rate Limit and Storm Control pages.
Page 128: Storm Control
Ingress Rate(Kbps): Configure the bandwidth for receiving packets on the port. You can select a rate from the dropdown list or select "Manual" to set Ingress rate, the system will automatically select integral multiple of 64Kbps that closest to the rate you entered as the real Ingress rate.
Page 129: Voice Vlan
Figure 9-11 Storm Control The following entries are displayed on this screen:  Storm Control Config Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for Storm Control configuration. It is multi-optional.
Page 130 configuration for voice data, ensuring the transmission priority of voice data stream and voice quality. OUI Address (Organizationally unique identifier address)  The switch can determine whether a received packet is a voice packet by checking its source MAC address. If the source MAC address of a packet complies with the OUI addresses configured by the system, the packet is determined as voice packet and transmitted in voice VLAN.
Page 131: Global Config
Port Voice VLAN Voice Link type of the port and processing mode Mode Stream Type Automatic Mode voice ACCESS: Not supported. stream TRUNK: Supported. The default VLAN of the port can not be voice VLAN. GENERAL: Supported. The default VLAN of the port can not be voice VLAN and the egress rule of the access port in the voice VLAN should be TAG.
Page 132: Port Config
The following entries are displayed on this screen: Global Config  Voice VLAN: Select Enable/Disable Voice VLAN function. VLAN ID: Enter the VLAN ID of the voice VLAN. Aging Time: Specifies the living time of the member port in auto mode after the OUI address is aging out.
Page 133: Oui Config
The following entries are displayed on this screen: Port Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for voice VLAN configuration. It is multi-optional.
Page 134 Figure 9-14 OUI Configuration The following entries are displayed on this screen: Create OUI  OUI: Enter the OUI address of the voice device. Mask: Enter the OUI address mask of the voice device. Description: Give a description to the OUI for identification. OUI Table ...
Page 135 Step Operation Description Configure Required. QoS→Voice VLAN→Port Config page, parameters of the ports configure the parameters of the ports in voice VLAN. in voice VLAN Enable Voice VLAN Required. On QoS→Voice VLAN→Global Config page, configure the global parameters of voice VLAN. Return to CONTENTS...
Page 136: Chapter 10 Acl
Chapter 10 ACL ACL (Access Control List) is used to filter packets by configuring match rules and process policies of packets in order to control the access of the illegal users to the network. Besides, ACL functions to control traffic flows and save network resources. It provides a flexible and secured access control policy and facilitates you to control the network security.
Page 137: Time-Range Create
10.1.2 Time-Range Create On this page you can create time-ranges. Choose the menu ACL→Time-Range→Time-Range Create to load the following page. Figure 10-2 Time-Range Create The following entries are displayed on this screen: Create Time-Range  Name: Enter the name of the time-range for time identification. Holiday: Select Holiday you set as a time-range.
Page 138: Holiday Config
10.1.3 Holiday Config Holiday mode is applied as a different secured access control policy from the week mode. On this page you can define holidays according to your work arrangement. Choose the menu ACL→Time-Range→Holiday Config to load the following page. Figure 10-3 Holiday Configuration The following entries are displayed on this screen: Create Holiday...
Page 139: Acl Summary
10.2.1 ACL Summary On this page, you can view the current ACLs configured in the switch. Choose the menu ACL→ACL Config→ACL Summary to load the following page. Figure 10-4 ACL Summary The following entries are displayed on this screen: Search Option ...
Page 140: Mac Acl
10.2.3 MAC ACL MAC ACLs analyze and process packets based on a series of match conditions, which can be the source MAC addresses, destination MAC addresses, VLAN ID, and EtherType carried in the packets. Choose the menu ACL→ACL Config→MAC ACL to load the following page. Figure 10-6 Create MAC Rule The following entries are displayed on this screen: Create MAC ACL...
Page 141: Standard-Ip Acl
10.2.4 Standard-IP ACL Standard-IP ACLs analyze and process data packets based on a series of match conditions, which can be the source IP addresses and destination IP addresses carried in the packets. Choose the menu ACL→ACL Config→Standard-IP ACL to load the following page. Figure 10-7 Create Standard-IP Rule The following entries are displayed on this screen: Create Standard-IP ACL...
Page 142 Figure 10-8 Create Extend-IP Rule The following entries are displayed on this screen: Create Extend-IP ACL  ACL ID: Select the desired Extend-IP ACL for configuration. Rule ID: Enter the rule ID. Operation: Select the operation for the switch to process packets which match the rules.
Page 143: Policy Config
10.3 Policy Config A Policy is used to control the data packets those match the corresponding ACL rules by configuring ACLs and actions together for effect. The operations here include stream mirror, stream condition, QoS remarking and redirect. The Policy Config can be implemented on Policy Summary, Police Create and Action Create pages.
Page 144: Action Create
Figure 10-10 Create Policy The following entries are displayed on this screen: Create Policy  Policy Name: Enter the name of the policy. 10.3.3 Action Create On this page you can add ACLs and create corresponding actions for the policy. Choose the menu ACL→Policy Config→Action Create to load the following page.
Page 145: Policy Binding
S-Condition: Select S-Condition to limit the transmission rate of the data packets in the policy.  Rate: Specify the forwarding rate of the data packets those match the corresponding ACL.  Out of Band: Specify the disposal way of the data packets those are transmitted beyond the rate.
Page 146: Port Binding
10.4.2 Port Binding On this page you can bind a policy to a port. Choose the menu ACL→Policy Binding→Port Binding to load the following page. Figure 10-13 Bind the policy to the port The following entries are displayed on this screen: Port-Bind Config ...
Page 147: Application Example For Acl
VLAN-Bind Config  Policy Name: Select the name of the policy you want to bind. VLAN ID: Enter the ID of the VLAN you want to bind. VLAN-Bind Table  Index: Displays the index of the binding policy. Policy Name: Displays the name of the binding policy.
Page 148 Network Diagram  Configuration Procedure  Step Operation Description Configure On ACL→Time-Range page, create a time-range named work_time. Time-range Select Week mode and configure the week time from Monday to Friday. Add a time-slice 08:00~18:00. Configure On ACL→ACL Config→ACL Create page, create ACL 11. requirement 1 On ACL→ACL Config→MAC ACL page, select ACL 11, create Rule 1, configure the operation as Permit, configure the S-MAC as...
Page 149 Step Operation Description Configure On ACL→ACL Config→ACL Create page, create ACL 100. requirement On ACL→ACL Config→Standard-IP ACL page, select ACL 100, and 4 create Rule 1, configure operation as Deny, configure S-IP as 10.10.70.0 and mask as 255.255.255.0, configure D-IP as 10.10.50.0 and mask as 255.255.255.0, configure the time-range as No Limit.
Page 150: Chapter 11 Network Security
Chapter 11 Network Security Network Security module is to provide the multiple protection measures for the network security, including five submenus: IP-MAC Binding, ARP Inspection, DoS Defend and 802.1X. Please configure the functions appropriate to your need. 11.1 IP-MAC Binding The IP-MAC Binding function allows you to bind the IP address, MAC address, VLAN ID and the connected Port number of the Host together.
Page 151: Manual Binding
The following entries are displayed on this screen: Search Option  Source: Select a Source from the pull-down list and click the Search button to view your desired entry in the Binding Table.  All: All the bound entries will be displayed. ...
Page 152 Figure 11-2 Manual Binding The following entries are displayed on this screen: Manual Binding Option  Host Name: Enter the Host Name. IP Address: Enter the IP address of the Host. MAC Address: Enter the MAC address of the Host. VLAN ID: Enter the VLAN ID.
Page 153: Arp Scanning
11.1.3 ARP Scanning ARP (Address Resolution Protocol) is used to analyze and map IP addresses to the corresponding MAC addresses so that packets can be delivered to their destinations correctly. IP address is the address of the Host on Network layer. MAC address, the address of the Host on Data link layer, is necessary for the packet to reach the very device.
Page 154: Dhcp Snooping
Figure 11-4 ARP Scanning The following entries are displayed on this screen: Scanning Option  Start IP Address: Specify the Start IP address. End IP Address: Specify the End IP address. VLAN ID: Enter the VLAN ID. If blank, the switch will send the untagged packets for scanning.
Page 155 network configuration protocol optimized and developed basing on the BOOTP, functions to solve the above mentioned problems. DHCP Working Principle  DHCP works via the “Client/Server” communication mode. The Client applies to the Server for configuration. The Server assigns the configuration information, such as the IP address, to the Client, so as to reach a dynamic employ of the network source.
Page 156 Figure 11-6 Interaction between a DHCP client and a DHCP server （1） DHCP-DISCOVER Stage: The Client broadcasts the DHCP-DISCOVER packet to find the DHCP Server. （2） DHCP-OFFER Stage: Upon receiving the DHCP-DISCOVER packet, the DHCP Server selects an IP address from the IP pool according to the assigning priority of the IP addresses and replies to the Client with DHCP-OFFER packet carrying the IP address and other information.
Page 157 Option 82 can contain 255 sub-options at most. If Option 82 is defined, at least a sub-option should be defined. This switch supports two sub-options: Circuit ID and Remote ID. Since there is no universal standard about the content of Option 82, different manufacturers define the sub-options of Option 82 to their need.
Page 158 Choose the menu Network Security→IP-MAC Binding→DHCP Snooping to load the following page. Figure 11-8 DHCP Snooping Note: If you want to enable the DHCP Snooping feature for the member port of LAG, please ensure the parameters of all the member ports are the same. The following entries are displayed on this screen: DHCP Snooping Config ...
Page 159 Global Flow Control: Select the value to specify the maximum amount of DHCP messages that can be forwarded by the switch per second. The excessive massages will be discarded. Decline Threshold: Select the value to specify the minimum transmission rate of the Decline packets to trigger the Decline protection for the specific port.
Page 160: Arp Inspection
11.2 ARP Inspection According to the ARP Implementation Procedure stated in 11.1.3 ARP Scanning, it can be found that ARP protocol can facilitate the Hosts in the same network segment to communicate with one another or access to external network via Gateway. However, since ARP protocol is implemented with the premise that all the Hosts and Gateways are trusted, there are high security risks during ARP Implementation Procedure in the actual complex network.
Page 161 Figure 11-10 ARP Attack – Cheating Gateway As the above figure shown, the attacker sends the fake ARP packets of Host A to the Gateway, and then the Gateway will automatically update its ARP table after receiving the ARP packets. When the Gateway tries to communicate with Host A in LAN, it will encapsulate this false destination MAC address for packets, which results in a breakdown of the normal communication.
Page 162 Figure 11-11 ARP Attack – Cheating Terminal Hosts As the above figure shown, the attacker sends the fake ARP packets of Host A to Host B, and then Host B will automatically update its ARP table after receiving the ARP packets. When Host B tries to communicate with Host A, it will encapsulate this false destination MAC address for packets, which results in a breakdown of the normal communication.
Page 163 Figure 11-12 Man-In-The-Middle Attack Suppose there are three Hosts in LAN connected with one another through a switch. Host A: IP address is 192.168.0.101; MAC address is 00-00-00-11-11-11. Host B: IP address is 192.168.0.102; MAC address is 00-00-00-22-22-22. Attacker: IP address is 192.168.0.103; MAC address is 00-00-00-33-33-33. First, the attacker sends the false ARP response packets.
Page 164: Arp Detect
The IP-MAC Binding function allows the switch to bind the IP address, MAC address, VLAN ID and the connected Port number of the Host together when the Host connects to the switch. Basing on the predefined IP-MAC Binding entries, the ARP Inspection functions to detect the ARP packets and filter the illegal ARP packet so as to prevent the network from ARP attacks.
Page 165: Arp Defend
Configuration Procedure: Step Operation Description Bind the IP address, MAC Required. On the IP-MAC Binding page, bind the IP address, VLAN ID and the address, MAC address, VLAN ID and the connected Port connected Port number of number of the Host together via Manual Binding, ARP the Host together.
Page 166: Arp Statistics
The following entries are displayed on this screen: ARP Defend  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select your desired port for configuration. It is multi-optional. Port: Displays the port number.
Page 167: Dos Defend
Figure 11-15 ARP Statistics The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the Auto Refresh feature. Refresh Interval: Specify the refresh interval to display the ARP Statistics. Illegal ARP Packet  Port: Displays the port number. Trusted Port: Indicates the port is an ARP Trusted Port or not.
Page 168 DoS Attack Type Description Scan SYNFIN The attacker sends the packet with its SYN field and the FIN field set to 1. The SYN field is used to request initial connection whereas the FIN field is used to request disconnection. Therefore, the packet of this type is illegal. The switch can defend this type of illegal packet.
Page 169 Config  DoS Protection: Allows you to Enable/Disable DoS Defend function. Defend Table  Select: Select the entry to enable the corresponding Defend Type. Defend Type: Displays the Defend Type name. Tips: You are suggested to take the following further steps to ensure the network security. It’s recommended to inspect and repair the system vulnerability regularly.
Page 170 An 802.1X authentication is initiated when a user launches client program on the supplicant system. Note that the client program must support the 802.1X authentication protocol. （2） Authenticator System: The authenticator system is usually an 802.1X-supported network device, such as this TP-LINK switch. It provides the physical or logical port for the supplicant system to access the LAN and authenticates the supplicant system.
Page 171 Figure 11-18 EAP-MD5 Authentication Procedure A supplicant system launches an 802.1X client program via its registered user name and password to initiate an access request through the sending of an EAPOL-Start packet to the switch. The 802.1X client program then forwards the packet to the switch to start the authentication process.
Page 172 The supplicant system can also terminate the authenticated state by sending EAPOL-Logoff packets to the switch. The switch then changes the port state from accepted to rejected. （2） EAP Terminating Mode In this mode, packet transmission is terminated at authenticator systems and the EAP packets are mapped into RADIUS packets.
Page 173: Global Config
Guest VLAN  Guest VLAN function enables the supplicants that do not pass the authentication to access the specific network resource. By default, all the ports connected to the supplicants belong to a VLAN, i.e. Guest VLAN. Users belonging to the Guest VLAN can access the resources of the Guest VLAN without being authenticated.
Page 174: Port Config
Auth Method: Select the Authentication Method from the pull-down list.  EAP-MD5: IEEE 802.1X authentication system uses extensible authentication protocol (EAP) to exchange information between the switch and the client. protocol packets with 　 authentication data can be encapsulated in the advanced protocol (such as RADIUS) packets to be transmitted to the authentication server.
Page 175 Figure 11-21 Port Config The following entries are displayed on this screen: Port Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select your desired port for configuration. It is multi-optional. Port: Displays the port number.
Page 176: Radius Server
Authorized: Displays the authentication status of the port. LAG: Displays the LAG to which the port belongs to. 11.4.3 Radius Server RADIUS (Remote Authentication Dial-In User Service) server provides the authentication service for the switch via the stored client information, such as the user name, password, etc, with the purpose to control the authentication and accounting status of the clients.
Page 177 Note: The 802.1X function takes effect only when it is enabled globally on the switch and for the port. The 802.1X function can not be enabled for LAG member ports. That is, the port with 802.1X function enabled can not be added to the LAG. The 802.1X function should not be enabled for the port connected to the authentication server.
Page 178: Chapter 12 Snmp
Chapter 12 SNMP SNMP Overview  SNMP (Simple Network Management Protocol) has gained the most extensive application on the UDP/IP networks. SNMP provides a management frame to monitor and maintain the network devices. It is used for automatically managing the various network devices no matter the physical differences of the devices.
Page 179 SNMP v1: SNMP v1 adopts Community Name authentication. The community name is used to define the relation between SNMP Management Station and SNMP Agent. The SNMP packets failing to pass community name authentication are discarded. The community name can limit access to SNMP Agent from SNMP NMS, functioning as a password.
Page 180: Snmp Config
The User configured in an SNMP Group can manage the switch via the client program on management station. The specified User Name and the Auth/Privacy Password are used for SNMP Management Station to access the SNMP Agent, functioning as the password. SNMP module is used to configure the SNMP function of the switch, including three submenus: SNMP Config, Notification and RMON.
Page 181: Snmp View
Note: The amount of Engine ID characters must be even. 12.1.2 SNMP View The OID (Object Identifier) of the SNMP packets is used to describe the managed objects of the switch, and the MIB (Management Information Base) is the set of the OIDs. The SNMP View is created for the SNMP management station to manage MIB objects.
Page 182: Snmp Group
12.1.3 SNMP Group On this page, you can configure SNMP Group to control the network access by providing the users in various groups with different management rights via the Read View, Write View and Notify View. Choose the menu SNMP→SNMP Config→SNMP Group to load the following page. Figure 12-5 SNMP Group The following entries are displayed on this screen: Group Config...
Page 183: Snmp User
writing only and changes can be made to the assigned SNMP View. The View defined both as the Read View and the Write View can be read and modified. Notify View: Select the View to be the Notify View. The management station can receive messages of the assigned SNMP view notification...
Page 184 Figure 12-6 SNMP User The following entries are displayed on this screen: User Config  User Name: Enter the User Name here. User Type: Select the type for the User.  Local User: Indicates that the user is connected to a local SNMP engine.
Page 185: Snmp Community
User Table  Select: Select the desired entry to delete the corresponding User. It is multi-optional. User Name: Displays the name of the User. User Type: Displays the User Type. Group Name: Displays the Group Name of the User. Security Model: Displays the Security Model of the User.
Page 186  read-only: Management right of the Community is restricted to read-only, and changes cannot be made to the corresponding View.  read-write: Management right of the Community is read-write and changes can be made to the corresponding View. MIB View: Select the MIB View for the community to access.
Page 187: Notification
Step Operation Description Create SNMP View. Required. On the SNMP→SNMP Config→SNMP View page, create SNMP View of the management agent. The default View Name is viewDefault and the default OID is 1. Create SNMP Required alternatively. Community Create SNMP Community directly. ...
Page 188 Figure 12-8 Notification Config The following entries are displayed on this screen: Create Notification  IP Address: Enter the IP address of the management Host. UDP Port: Enter the number of the UDP port used to send notifications. The UDP port functions with the IP address for the notification sending.
Page 189: Rmon
Notification Table  Select: Select the desired entry to delete the corresponding management station. IP Address: Displays the IP address of the management host. UDP Port: Displays the UDP port used to send notifications. User: Displays the User name of the management station. Security Model: Displays the Security Model of the management station.
Page 190: History Control
The RMON Groups can be configured on the History Control, Event Config and Alarm Config pages. 12.3.1 History Control On this page, you can configure the History Group for RMON. Choose the menu SNMP→RMON→History Control to load the following page. Figure 12-9 History Control The following entries are displayed on this screen: History Control Table...
Page 191: Alarm Config
Figure 12-10 Event Config The following entries are displayed on this screen: Event Table  Select: Select the desired entry for configuration. Index: Displays the index number of the entry. User: Enter the name of the User or the community to which the event belongs.
Page 192 Figure 12-11 Alarm Config The following entries are displayed on this screen: Alarm Table  Select: Select the desired entry for configuration. Index: Displays the index number of the entry. Variable: Select the alarm variables from the pull-down list. Port: Select the port on which the Alarm entry acts.
Page 193 Interval: Enter the alarm interval time in seconds. Owner: Enter the name of the device or user that defined the entry. Status: Select Enable/Disable the corresponding alarm entry. Note: When alarm variables exceed the Threshold on the same direction continuously for several times, an alarm event will only be generated on the first time, that is, the Rising Alarm and Falling Alarm are triggered alternately for that the alarm following to Rising Alarm is certainly a Falling Alarm and vice versa.
Page 194: Chapter 13 Lldp
Chapter 13 LLDP LLDP (Link Layer Discovery Protocol) is a Layer 2 protocol that is used for network devices to advertise their own device information periodically to neighbors on the same IEEE 802 local area network. The advertised information, including details such as device identification, capabilities and configuration settings, is represented in TLV (Type/Length/Value) format according to the IEEE 802.1ab standard, and these TLVs are encapsulated in LLDPDU (Link Layer Discovery Protocol Data Unit).
Page 195  Disable: the port cannot transmit or receive LLDPDUs. LLDPDU transmission mechanism  If the ports are working in TxRx or Tx mode, they will advertise local information by sending LLDPDUs periodically.  If there is a change in the local device, the change notification will be advertised. To prevent a series of successive LLDPDUs transmissions during a short period due to frequent changes in local device, a transmission delay timer is set by network management to ensure that there is a defined minimum time between successive LLDP...
Page 196 TLV Type TLV Name Description Usage in LLDPDU Time To Live Indicates the number of seconds that the Mandatory neighbor device is to regard the local information to be valid. Port Description Identifies the description string of the port. Optional System Name Identifies the system name.
Page 197: Basic Config
System Name TLV The System Name TLV allows network management to advertise the system's assigned name, which should be the system's fully qualified domain name. Management Address The Management Address TLV identifies an address associated with the local LLDP agent that may be used to reach higher entities to assist discovery by network management.
Page 198: Port Config
Figure 13-1 Global Configuration The following entries are displayed on this screen: Global Config  LLDP: Enable/disable LLDP function globally. Parameters Config  Transmit Interval: Enter the interval for the local device to transmit LLDPDU to its neighbors. The default value is 30 seconds. Hold Multiplier: Enter a multiplier on the Transmit Interval.
Page 199: Device Info
Figure 13-2 Port Configuration The following entries are displayed on this screen: LLDP Port Config  Port Select: Select the desired port to configure. Admin Status: Select the port’s LLDP operating mode: Tx&Rx: Send and receive LLDP frames.  Rx_Only: Only receive LLDP frames. ...
Page 200: Neighbor Info
Figure 13-3 Local Information The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the auto refresh function. Refresh Rate: Specify the auto refresh rate. Local Info  Enter the desired port number and click Select to display the information of the corresponding port.
Page 201: Device Statistics
The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the auto refresh function. Refresh Rate: Specify the auto refresh rate. Neighbor Info  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Local Port: Displays the local port number connecting to the neighbor device.
Page 202 Figure 13-5 Device Statistics The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the auto refresh function. Refresh Rate: Specify the auto refresh rate. Global Statistics  Last Update: Displays latest update time of the statistics. Total Inserts: Displays the number of neighbors inserted till last update time.
Page 203 Receive Total: Displays the number of LLDPDUs received by this port. Discards: Displays the number of LLDPDUs discarded by this port. Errors: Displays the number of error LLDPDUs received by this port. Ageouts: Displays the number of overtime neighbors linking to this port. TLV Discards: Displays the number of TLVs dropped by this port.
Page 204: Chapter 14 Cluster
Chapter 14 Cluster With the development of network technology, the network scale is getting larger and more network devices are required, which may result in a more complicated network management system. As a large number of devices need to be assigned different network addresses and every management device needs to be respectively configured to meet the application requirements, manpower are needed.
Page 205: Ndp
The commander switch discovers and determines candidate switches by collecting related  information. After being added to the cluster, the candidate switch becomes to be the member switch.  After being removed from the cluster, the member switch becomes to be the candidate switch. ...
Page 206: Ndp Summary
The following entries are displayed on this screen: Neighbor  Search Option: Select the information the desired entry should contain and then click the Search button to display the desired entry in the following Neighbor Information table. Neighbor Info  Native Port: Displays the port number of the switch.
Page 207 Figure 14-3 NDP Summary The following entries are displayed on this screen: Global Config  NDP: Displays the global NDP status (enabled or disabled) for the switch. Aging Time: Displays the period for the neighbor switch to keep the NDP packets from this switch.
Page 208: Ndp Config
Click the Detail button to view the complete information collected Detail： for the port. 14.1.3 NDP Config On this page you can configure the NDP function for the switch. Choose the menu Cluster→NDP→NDP Config to load the following page. Figure 14-4 NDP Config The following entries are displayed on this screen: Global Config ...
Page 209: Ntdp
NDP: Displays NDP status of the current port. Enable: Click the Enable button to enable NDP for the port you select. Disable: Click the Disable button to disable NDP for the port you select. Note: NDP function is effective only when NDP function is enabled globally and for the port. The aging time should be set over the hello time value, otherwise the neighbor information table of NDP ports will not take effect.
Page 210: Ntdp Summary
Device Table  Device Type: Displays the device description collected through NTDP. Device MAC: Displays the MAC address of this device. Cluster Name: Displays the cluster name of this device. Role: Displays the role this device plays in the cluster. ...
Page 211 Figure 14-7 NTDP Summary The following entries are displayed on this screen: Global Config  NTDP: Displays the NTDP status (enabled or disabled) of the switch globally. NTDP Interval Time: Displays the interval to collect topology information. NTDP Hops: Displays the hop count the switch topology collects. NTDP Hop Delay: Displays the time between the switch receiving NTDP request packets and the switch forwarding NTDP request packets for the...
Page 212: Ntdp Config
Port Status  Port: Displays the port number of the switch. NTDP: Displays NTDP status (enabled or disabled) of the current port. 14.2.3 NTDP Config On this page you can configure NTDP globally. Choose the menu Cluster→NTDP→NTDP Config to load the following page. Figure 14-8 NTDP Config The following entries are displayed on this screen: Global Config...
Page 213: Cluster
NTDP Hops: Enter the hop count the switch topology collects. The default is 3 hops. NTDP Hop Delay: Enter the time between the switch receiving NTDP request packets and the switch forwarding NTDP request packets for the first time. The default is 200 milliseconds. NTDP Port Delay: Enter the time between the port forwarding NTDP request packets and its adjacent port forwarding NTDP request packets over.
Page 214 The following entries are displayed on this screen: Global  Cluster: Displays the cluster status (enabled or disabled) of the switch. Cluster Role: Displays the role the switch plays in the cluster. For a member switch, the following page is displayed: ...
Page 215: Cluster Config
Cluster Role: Displays the role the switch plays in the cluster. 14.3.2 Cluster Config On this page you can configure the status of the cluster the switch belongs to. Choose the menu Cluster→Cluster→Cluster Config to load the following page. For a candidate switch, the following page is displayed. ...
Page 216: Application Example For Cluster Function
 Three switches form cluster, one commander switch(Here take TP-LINK TL-SL5428E as an example) and two member switches(Here take TP-LINK TL-SL3428/TL-SL3452 as an example). The administrator manages all the switches in the cluster via the commander switch. Port 1 of the commander switch is connecting to the external network, port 2 is connecting to ...
Page 217 Network Diagram  Figure 14-15 Network diagram Configuration Procedure  Configure the member switch  Step Operation Description Enable NDP function on the On Cluster→NDP→NDP Config page, enable NDP switch and for port 1 function. Enable NTDP function on the On Cluster→NTDP→NTDP Config page, enable switch and for port 1 NTDP function.
Page 218 Step Operation Description Configure the member switch On Cluster→Cluster→Member Config page, select the member switch and click the Manage button to log on to its Web management page. Cluster→Cluster→Cluster Topology page, double-click the switch icon to view its detailed information; click the switch icon and click the Manage button to log on to the Web management page.
Page 219: Chapter 15 Maintenance
Chapter 15 Maintenance Maintenance module, assembling the commonly used system tools to manage the switch, provides the convenient method to locate and solve the network problem. （1） System Monitor: Monitor the utilization status of the memory and the CPU of switch. （2）...
Page 220: Memory Monitor
Click the Monitor button to enable the switch to monitor and display its CPU utilization rate every four seconds. 15.1.2 Memory Monitor Choose the menu Maintenance→System Monitor→Memory Monitor to load the following page. Figure 15-2 Memory Monitor Click the Monitor button to enable the switch to monitor and display its Memory utilization rate every four seconds.
Page 221: Log Table
informational Informational messages Debug-level messages debugging Table 15-1 Log Level The Log function is implemented on the Log Table, Local Log, Remote Log and Backup Log pages. 15.2.1 Log Table The switch supports logs output to two directions, namely, log buffer and log file. The information in log buffer will be lost after the switch is rebooted or powered off whereas the information in log file will be kept effective even the switch is rebooted or powered off.
Page 222: Local Log
15.2.2 Local Log Local Log is the log information saved in switch. By default, all system logs are saved in log buffer and the logs with severities from level_0 to level_4 are saved in log file meanwhile. On this page, you can set the output channel for logs.
Page 223: Backup Log
Figure 15-5 Log Host The following entries are displayed on this screen: Log Host  Select: Select the desired entry to configure the corresponding log host. Index: Displays the index of the log host. The switch supports 4 log hosts. Host IP: Configure the IP for the log host.
Page 224: Device Diagnostics
Figure 15-6 Backup Log The following entry is displayed on this screen: Backup Log  Backup Log: Click the Backup Log button to save the log as a file to your computer. Note: It will take a few minutes to backup the log file. Please wait without any operation. 15.3 Device Diagnostics This switch provides Cable Test and Loopback functions for device diagnostics.
Page 225: Loopback
Pair: Displays the Pair number. Status: Displays the connection status of the cable connected to the port. The test results of the cable include normal, close, open, short, impedance or unknown. Length: If the connection status is normal, here displays the length range of the cable.
Page 226: Network Diagnostics
Loopback Port  Loopback Port: Select the desired port for loopback test. Test: Click the Test button to start the loopback test for the port. 15.4 Network Diagnostics This switch provides Ping test and Tracert test functions for network diagnostics. 15.4.1 Ping Ping test function, testing the connectivity between the switch and one node of the network, facilitates you to test the network connectivity and reachability of the host so as to locate the...
Page 227: Tracert
15.4.2 Tracert Tracert test function is used to test the connectivity of the gateways during its journey from the source to destination of the test data. When malfunctions occur to the network, you can locate trouble spot of the network with this tracert test. Choose the menu Maintenance→Network Diagnostics→Tracert to load the following page.
Page 228: Chapter 16 System Maintenance Via Ftp
Chapter 16 System Maintenance via FTP The firmware can be downloaded to the switch via FTP function. FTP (File Transfer Protocol), a protocol in the application layer, is mainly used to transfer files between the remote server and the local PCs. It is a common protocol used in the IP network for files transfer. If there is something wrong with the firmware of the switch and the switch can not be launched, the firmware can be downloaded to the switch again via FTP function.
Page 229 Figure 16-2 Open Hyper Terminal 2） The Connection Description Window will prompt shown as Figure 16-3. Enter a name into the Name field and click OK. Figure 16-3 Connection Description 3） Select the port to connect in Figure 16-4 and click OK.
Page 230 Figure 16-4 Select the port to connect 4） Configure the port selected in the step above shown as the following Figure 16-5. Configure Bits per second as 38400, Data bits as 8, Parity as None, Stop bits as 1, Flow control as None, and then click OK. Figure 16-5 Port Settings 3.
Page 231 Figure 16-6 bootUtil Menu As the prompt is displayed for a short time, you are suggested not to release the CTRL-B key until you enter into bootUtil menu after powering on the switch. 3） After entering into bootUtil menu, please firstly configure the IP parameters of the switch. The format is: ifconfig ip xxx.xxx.xxx.xxx mask 255.255.255.0 gateway xxx.xxx.xxx.xxx.
Page 232 Start ..◀ * * * * * * * * * * * * * * * * * * User Access Login * * * * * * * * * * * * * * * * * User: When you forget the login user name and password, you can enter reset command after entering into bootUtil menu to reset the system.
Page 233: Appendix A: Specifications
Appendix A: Specifications IEEE802.3 10Base-T Ethernet IEEE802.3u 100Base-TX/100Base-FX Fast Ethernet IEEE802.3ab 1000Base-T Gigabit Ethernet IEEE802.3z 1000Base-X Gigabit Ethernet Standards IEEE802.3x Flow Control IEEE802.1p QoS IEEE802.1q VLAN IEEE802.1X Port-based Access Authentication Ethernet: 10Mbps HD，20Mbps FD Transmission Rate Fast Ethernet: 100Mbps HD，200Mbps FD Gigabit Ethernet: 2000Mbps FD 10Base-T: UTP/STP of Cat.
Page 234: Appendix B: Configuring The Pcs
Appendix B: Configuring the PCs In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows 2000. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if necessary. Configure TCP/IP component On the Windows taskbar, click the Start button, and then click Control Panel. Click the Network and Internet Connections icon, and then click on the Network Connections tab in the appearing window.
Page 235 Figure B-2 The following TCP/IP Properties window will display and the IP Address tab is open on this window by default.
Page 236 Figure B-3 Select Use the following IP address. And the following items will be available. If the switch's IP address is 192.168.0.1, specify IP address as 192.168.0.x (x is from 2 to 254), and the Subnet mask as 255.255.255.0. Now: Click OK to save your settings.
Page 237: Appendix C: 802.1X Client Software
In 802.1X mechanism, the supplicant Client should be equipped with the corresponding client software complied with 802.1X protocol standard for 802.1X authentication. When the switch TL-SL3428 works as the authenticator system, please take the following instructions to install the TpSupplicant provided on the attached CD for the supplicant Client.
Page 238 Figure C-3 Welcome to the InstallShield Wizard To continue, choose the destination location for the installation files and click Next on the following screen. Figure C-4 Choose Destination Location By default, the installation files are saved on the Program Files folder of system disk. Click the Change button to modify the destination location proper to your need.
Page 239 Figure C-5 Install the Program The InstallShield Wizard is installing TpSupplicant shown as the following screen. Please wait. Figure C-6 Setup Status On the following screen, click Finish to complete the installation.
Page 240 Figure C-7 InstallShield Wizard Complete Note: Please pay attention to the tips on the above screen. If you have not installed WinPcap 4.0.2 or the higher version on your computer, the 802.1X Client Software TpSupplicant can not work. It’s recommended to go to http://www.winpcap.org to download the latest version of WinPcap for installation.
Page 241 Then the following screen will appear. If you want to stop the remove process, click Cancel. Figure C-9 Preparing Setup On the continued screen, click Yes to remove the application from your PC. Figure C-10 Uninstall the Application Click Finish to complete. Figure C-11 Uninstall Complete Configuration After completing installation, double click the icon...
Page 242 Figure C-12 TP-LINK 802.1X Client Enter the Name and the Password specified in the Authentication Server. The length of Name and Password should be less than 16 characters. Click the Properties button on Figure C-12 to load the following screen for configuring the connection properties.
Page 243 To continue, click Connect button after entering the Name and Password on Figure C-12. Then the following screen will appear to prompt that the Radius server is being searched. Figure C-14 Authentication Dialog When passing the authentication, the following screen will appear. Figure C-15 Successfully Authenticated Double click the icon on the right corner of desktop, and then the following connection...
Page 244 A1: It’s because the supported DLL file is missing. You are suggested to go to http://www.winpcap.org to download WinPcap 4.0.2 or the higher version for installation, and run the client software again. Q2: Is this TP-LINK 802.1X Client Software compliable with the switches of the other manufacturers? A2: No.
Page 245: Appendix D: Glossary
Appendix D: Glossary Access Control List (ACL) ACLs can limit network traffic and restrict access to certain users or devices by checking each packet for certain IP or MAC (i.e., Layer 2) information. Boot Protocol (BOOTP) BOOTP is used to provide bootup information for network devices, including IP address information, the address of the TFTP server that contains the devices system files, and the name of the boot file.
Page 246 Generic Multicast Registration Protocol (GMRP) GMRP allows network devices to register end stations with multicast groups. GMRP requires that any participating network devices or end stations comply with the IEEE 802.1p standard. Group Attribute Registration Protocol (GARP) See Generic Attribute Registration Protocol. IEEE 802.1D Specifies a general method for the operation of MAC bridges, including the Spanning Tree Protocol.
Page 247 Layer 2 Data Link layer in the ISO 7-Layer Data Communications Protocol. This is related directly to the hardware interface for network devices and passes on traffic based on MAC addresses. Link Aggregation See Port Trunk. Link Aggregation Control Protocol (LACP) Allows ports to automatically negotiate a trunked link with LACP-configured ports on another device.
Page 248 Secure Shell (SSH) A secure replacement for remote access functions, including Telnet. SSH can authenticate users with a cryptographic key, and encrypt data connections between management clients and the switch. Simple Network Management Protocol (SNMP) The application protocol in the Internet suite of protocols which offers network management services.
