- Page 1 Enterprise Networking Solution Installation Guide L2 Managed Switch TL-SL3428/TL-SL3452...
-
Page 2: Fcc Statement
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2012 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. -
Page 3: Related Document
The User Guide and CLI Reference Guide of the product are provided on the resource To obtain the latest product information, please visit the official website: http://www.tp-link.com About this Installation Guide This Installation Guide describes the hardware characteristics, installation methods and the points that should be attended to during installation. - Page 4 Audience This Installation Guide is for: Network Engineer Network Administrator Conventions Due to the similarity in structure of the L2 managed Switch series, in this Installation Guide we take TL-SL3428 as an example to illustrate Chapter 2 Installation, Chapter 3 Lighting Protection, Chapter 4 Connection and Chapter 5 Configuration.
-
Page 5: Table Of Contents
Contents Chapter 1 Introduction ———————————— 01 Product Overview .........01 Appearance ..........01 Chapter 2 Installation ————————————— 04 Package Contents .........04 Safety Precautions ........04 Installation Tools ..........06 Product Installation ........06 Chapter 3 Lightning Protection ———————— 08 Cabling Reasonably ........08 Connect to Ground ........10 Equipotential Bonding ........11 Use Lightning Arrester ........12 Chapter 4 Connection —————————————... -
Page 6: Chapter 1 Introduction
L2 Managed Switch LEDs 10/100Mbps RJ45 Port 10/100/1000Mbps RJ45 Port SFP Port Console Port Figure 1-1 Front Panel of TL-SL3428 The front panel of TL-SL3452 is shown as the following figure. 28 29 100Mbps 1000Mbps 1000Base-X Console 10Mbps 10/100Mbps LEDs... - Page 7 SFP Port Console Port Port RJ45 Port TL-SL3428 TL-SL3452 10/100Mbps Port Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps. Each has a corresponding 10/100Mbps LED. 10/100/1000Mbps Port Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000Mbps.
- Page 8 For 100Mbps module, please select 100MFD while select 1000MFD for gigabit module. By default, the Speed and Duplex mode of SFP port is 1000MFD. For TL-SL3452, the SFP port can be only used with a gigabit module. ■ Rear Panel ■...
-
Page 9: Chapter 2 Installation
L2 Managed Switch ChaCter 1 Installation Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, please contact your distributor. One Switch One Power Cord, one Console This Installation Guide Cable and one Ground Cable Two mounting brackets and One Resource CD... - Page 10 L2 Managed Switch Please keep a proper temperature and humidity in the equipment room. Too high/low humidity may lead to bad insulation, electricity leakage, mechanical property changes and corrosions. Too high temperature may accelerate aging of the insulation materials and can thus significantly shorten the service life of the device. For normal temperature and humidity of the device, please check the following table.
-
Page 11: Installation Tools
L2 Managed Switch protection measures should be taken. Ensure the rack and device are well earthed. ■ Make sure the power socket has a good contact with the ground. ■ Keep a reasonable cabling system and avoid induced lightning. ■ Use the signal SPD (Surge Protective Device1 when wiring outdoor. -
Page 12: Rack Installation
L2 Managed Switch Turnover the device and attach the supplied rubber feet to the recessed areas on the bottom at each corner of the device. Feet Bottom of the Device Notch Figure 2-1 Desktop Installation Rack Installation ■ To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below: Check the grounding and stability of the rack. -
Page 13: Chapter 3 Lightning Protection
L2 Managed Switch ChaCter 2 Lightning Protection Cabling Reasonably In the actual network environment, you may need cable outdoors and indoors, and the requirements for cabling outdoors and indoors are different. A reasonable cabling system can decrease the damage of induced lightning to devices. Note: It’s not recommended using Ethernet cables outdoors. - Page 14 L2 Managed Switch Requirements for the distance between Ethernet cable and other pipelines are shown ■ in the table. Ethernet Cable Other Pipelines Min Parallel Net Length Min Parallel-overlapping Net Height L (mm1 H (mm1 Down-conductor 1000 Service pipe Compressed air pipe Thermal pipe (not wrapped1 500 Thermal pipe (wrapped1 Gas pipe...
-
Page 15: Connect To Ground
L2 Managed Switch Connect to Ground Connecting the device to ground is to quickly release the lightning over-voltage and over-current of the device, which is also a necessary measure to protect the body from electric shock. In different environments, the device may be grounded differently. The following will instruct you to connect the device to the ground in two ways, connecting to the grounding bar or connecting to the ground via the power cord. -
Page 16: Equipotential Bonding
L2 Managed Switch Note: The figure is to illustrate the application and principle. The power cord you get from ■ the package and the socket in your situation will comply with the regulation in your country, so they may differ from the figure above. If you intend to connect the device to the ground via the PE (Protecting Earth1 cable ■... -
Page 17: Use Lightning Arrester
L2 Managed Switch Use Lightning Arrester Power lightning arrester and signal lightning arrester are used for lighting protection. Power lightning arrester is used for limiting the voltage surge due to a lightning. If an outdoor AC power cord should be directly connected to the device, please use a power lightning arrester. -
Page 18: Chapter 4 Connection
TL-SL3428 supports 100/1000Base-FX SFP module at full-duplex mode. When ■ using a SFP module, you need log on to the GUI of the Switch and configure the corresponding Speed and Duplex mode on Switching→Port→Port Config page. TL-SL3452 only supports 1000Base-X SFP module at full-duplex mode. ■ Connection... -
Page 19: Console Port
L2 Managed Switch Console Port CLI (Command Line Interface1 enables you to manage the Switch, thus you can load the CLI after connecting the PCs or Terminals to the console port on the Switch via the provided cable. Connect the console port of the device with your computer by the console cable as the following figure shown. -
Page 20: Initialization
L2 Managed Switch Figure 4-4 Connecting to Power Supply Note: The figure is to illustrate the application and principle. The power cord you get from the package and the socket in your situation will comply with the regulation in your country, so they may differ from the figure above. Initialization After the device is powered on, it begins the Power-On Self-Test. -
Page 21: Chapter 5 Configuration
L2 Managed Switch ChaCter 4 Configuration Configure the Switch via GUI To access the GUI of the Switch, open a web browser and type the default management address http://192.168.0.1 in the address field of the browser, then press the Enter key. Figure 5-1 Web Browser Note: To log on to the GUI of the Switch, the IP address of your PC should be set in... -
Page 22: Configure The Switch Using Cli
L2 Managed Switch Figure 5-3 Main Page of the Switch Configure the Switch Using CLI You can log on to the Switch and access the CLI by the following two methods: Log on to the Switch by the console port on the Switch. ■... - Page 23 L2 Managed Switch The Connection Description Window will prompt as Figure 5-5. Enter a name into the Name field and click OK. Figure 5-5 Connection Description Select the port to connect in Figure 5-6, and click OK. Figure 5-6 Select the port to connect Configure the port selected in the step above as the following Figure 5-7 shown.
- Page 24 Type the User name and Password in the Hyper Terminal window, the factory default value for both of them is admin. The DOS prompt” TP-LINK>” will appear after pressing the Enter button as Figure 5-8 shown. It indicates that you can use the CLI now.
- Page 25 L2 Managed Switch Figure 5-9 Open the Run window Type cmd in the prompt Run window as Figure 5-10 and click OK. Figure 5-10 Run Window Type telnet 192.168.0.1 in the command prompt shown as Figure 5-11, and press the Enter button.
- Page 26 L2 Managed Switch Type the User name and Password (the factory default value for both of them is admin1 and press the Enter button, then you can use the CLI now, which is shown as Figure 5-12. Figure 5-12 Log in the Switch For detailed CLI configuration instructions, please refer to the CLI Reference Guide on the resource CD.
-
Page 27: Appendix A Troubleshooting
L2 Managed Switch ACCendiA A Troubleshooting What could I do if I forgot the username and Cassword of the Switch? Connect the console port of the PC to the console port of the Switch and open hyper terminal. Power off and restart the Switch. When you are prompted that “Press CTRL-B to enter the bootUtil”... -
Page 28: Appendix B Hardware Specifications
L2 Managed Switch ACCendiA B Hardware SCecifications Item Content IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX/100Base-FX Standards IEEE 802.3ab 1000Base-T IEEE 802.3z 1000Base-X IEEE 802.3x Flow Control 10Base-T: UTP/STP of Cat. 3 or above (maximum 100m1 100Base-TX: 2-pair UTP/STP of Cat. 5 or above (maximum 100m1 Transmission Medium 100Base-FX: MMF or SMF SFP Module (Optional1... -
Page 29: Appendix C Technical Support
L2 Managed Switch ACCendiA C Technical SuCCort For more help, please go to: http://www.tp-link.com/en/support/faq ■ To download the latest Firmware, Driver, Utility and User Guide, go to: ■ http://www.tp-link.com/en/support/download For all other technical support, please contact us by using the following details: ■... - Page 30 L2 Managed Switch Russian Federation Tel: 8 (4991 754-55-60 8 (8001 250-55-60 (toll-free call from any RF region1 E-mail: support.ru@tp-link.com Service time: From 10:00 to 18:00 (Moscow time1 *Except weekends and holidays in Russian Federation Ukraine Tel: 0-800-505-508 E-mail: support.ua@tp-link.com...
- Page 32 Website: http://www.tp-link.com Tel: +86 755 26504400 E-mail: support@tp-link.com 7106503968 Rev: 1.2.0...
